Related Manuals for Philips 32B1U3900
Summary of Contents for Philips 32B1U3900
- Page 1 Business Monitor 3000 Series 32B1U3900 User manual Customer care and warranty Troubleshooting and FAQs Register your product and get support at www.philips.com/welcome...
- Page 2 6.1 Resolution & Preset Modes ..21 7� Power Management ������������������ 23 8� Customer care and warranty ��� 24 8.1 Philips’ Flat Panel Monitors Pixel Defect Policy ......... 24 8.2 Customer Care & Warranty ..27 9� Troubleshooting & FAQs ����������� 28 9.1 Troubleshooting ......
- Page 3 Keep the display away from oil. Oil may damage the plastic cover of the display and void the warranty. This electronic user’s guide is intended for anyone who uses the Philips • Remove any object that could fall monitor. Take time to read this user into ventilation holes or prevent manual before you use your monitor.
- Page 4 damage will not be covered under • Oil-based cleaning solutions may warranty. damage the plastic parts and void the warranty. • Do not knock or drop the monitor during operation and/or • Unplug the monitor if you are not transportation. going to use it for an extensive period.
- Page 5 1.2 Notational Descriptions • “Burn-in”, “after-imaging”, or “ghost imaging” is a well-known The following subsections describe the phenomenon in LCD panel notational conventions used in this technology. In most cases, the document. “burn-in”, “after-imaging” or “ghost imaging” will disappear gradually Notes, Cautions, and Warnings over some time after the power has Throughout this guide, blocks of text...
- Page 6 From the planning, design, and production stages, Philips emphasizes the importance of making products that can easily be recycled. At Philips, end-of-life management primarily This marking on the product or its entails participation in national take-...
- Page 7 Package contents Business Monitor 3000 Series 32B1U3900 Quick Start Register your product and get support at www.philips.com/welcome 2. Hold the stand with both hands. (1) Gently attach the base to the Power stand. (2) Use your fingers to tighten the...
- Page 8 HDMI 2 input availability of the most updated DisplayPort input driver. USBC Note RJ45 input Please contact Philips service hotline for Mac address clone tool as necessary. USB downstream USB downstream/USB fast charger Audio Out Kensington anti-theft lock...
- Page 9 HDD, for example� The display must be powered ON at all times to be able to use this function� Some selected Philips displays may not Power or Charge your device when it enters “Sleep/Standby” mode (White power LED blinking). In that case, please enter to OSD Menu and select “USB...
- Page 10 What is On-Screen Display (OSD)? Description of the control buttons On-Screen Display (OSD) is a feature in all Philips LCD monitors. It allows an end user to adjust screen performance or select functions of the monitors directly through an on-screen instruction window.
- Page 11 Physical Function Main menu Sub menu LowBlue Mode 1, 2, 3, 4 Off Tilt Input 1 HDMI 2.0 2 HDMI 2.0 DisplayPort USB C 25° On, Off Auto Picture SmartImage EasyRead, Office, Photo, Movie, Game, Economy, LowBlue Mode, Off Picture Format Wide Screen, 4:3 Brightness 0~100...
- Page 12 2.3 Remove the Base Assembly Pivot for VESA Mounting Before you start disassembling the monitor base, please follow the instructions below to avoid any possible damage or injury. 1. Place the monitor face down on a smooth surface. Pay attention not to scratch or damage the screen.
- Page 13 -5° complex multi-tasking work a breeze. * Display design may differ from those Why do I need it? illustrated. With the ultra high resolution Philips Warning MultiView display, you can experience a • To avoid potential screen damage, world of connectivity in a comfortable such as panel peeling, ensure that way in the office or at home.
- Page 14 [PBP]: Picture by Picture Open up a sub-window side-by-side of another (main) signal source. When the sub source is ...
- Page 15 • PIP Position: When PIP is activated, there are four sub-window positions to choose. Top-Left Top-Right (main) (main) Bottom-Left Bottom-Right (main) (main) • Swap: The main picture source and the sub picture source swapped on the display. Swap A and B source in [PIP] mode: ↔...
- Page 16 Office, Photo, Movie, Game, Economy, brightness, contrast, color and sharpness LowBlue Mode, Off. in real time. Whether you're working with text applications, displaying images or watching a video, Philips SmartImage delivers great optimized monitor performance. Why do I need it? ...
- Page 17 • Off: No optimization by SmartImage. Note Philips LowBlue mode, mode 2 compliance with TUV Low Blue Light certification, you can have this mode by simply press the hotkey , then press to select LowBlue Mode, see above SmartImage selection steps.
- Page 18 What is it? brightness value of the monitor. You may adjust the brightness value Smart Power is an exclusive Philips manually to increase power delivery technology that provides flexible power from this monitor. delivery options for various devices.
- Page 19 • Reposition your screen to appropriate height and angle syndrome (CVS) according to your height. 4. Choose Philips monitor for easy-on- Philips monitor is designed to prevent eyes. eye strain caused by prolonged computer use. • Anti-glare screen: Anti-glare...
- Page 20 6. Technical Specifications Picture/Display Monitor Panel Type Backlight W-LED Panel Size 31.5" W (80 cm) Aspect Ratio 16:9 Pixel Pitch 0.18159 (H) mm x 0.18159 (V) mm Contrast Ratio(typ.) 3500:1 Native Resolution 3840 x 2160 @ 60 Hz Maximum Resolution 3840 x 2160 @ 60 Hz Viewing Angle 178°...
- Page 21 English, German, Spanish, Greek, French, Italian, Hungarian, Dutch, Portuguese, Brazil Portuguese, Polish, OSD Languages Russian, Swedish, Finnish, Turkish, Czech, Ukranian, Simplified Chinese, Traditional Chinese, Japanese, Korean Other Convenience VESA mount (100 x 100 mm), Kensington Lock Plug & Play Compatibility DDC/CI, sRGB, Windows 11/10, Mac OS X Stand Tilt...
- Page 22 100% PVC BFR free housing Cabinet Color Black Finish Texture For more information, please refer to Chapter 6.1 on Display Input Format. Note 1. This data is subject to change without notice. Go to www.philips.com/support to download the latest version of leaflet.
- Page 23 6.1 Resolution & Preset Modes H. freq (kHz) Resolution V. freq (Hz) 31.47 720x400 70.09 31.47 640x480 59.94 35.00 640x480 66.67 37.86 640x480 72.81 37.50 640x480 75.00 35.16 800x600 56.25 37.88 800x600 60.32 48.08 800x600 72.19 46.88 800x600 75.00 47.73 832x624 74.55 48.36...
- Page 24 Display Input Format 422/420 444/RGB 422/420 444/RGB 422/420 444/RGB USBC@High USBC@High USBC@High USBC@High (HDMI2.0) (HDMI2.0) (DP1.4) (DP1.4) Data Speed Resolution Data Speed Resolution 3840 x 2160 60Hz, 10bits 3840 x 2160 60Hz, 8bits 3840 x 2160 30Hz, 10bits 3840 x 2160 30Hz, 8bits lower resolutions 8bits/10bits Note In order for the monitor to function properly,you PC's graphics card must support...
- Page 25 7. Power Management If you have VESA DPM compliance display card or software installed in your PC, the monitor can automatically reduce its power consumption when not in use. If an input from a keyboard, mouse or other input device is detected, the monitor will 'wake up' automatically.
- Page 26 Other combinations of Pixel Defect Policy lit and dark sub pixels appear as single pixels of other colors. Philips strives to deliver the highest quality products. We use some of the Types of Pixel Defects industry's most advanced manufacturing...
- Page 27 Black Dot Defects the warranty period, a TFT Monitor Black dot defects appear as pixels or sub panel in a Philips flat panel monitor pixels that are always dark or 'off'. That must have pixel or sub pixel defects is, a dark dot is a sub-pixel that stands...
- Page 28 BRIGHT DOT DEFECTS ACCEPTABLE LEVEL 1 lit subpixel 2 adjacent lit subpixels 3 adjacent lit subpixels (one white pixel) Distance between two bright dot defects* >15mm Total bright dot defects of all types BLACK DOT DEFECTS ACCEPTABLE LEVEL 1 dark subpixel 3 or fewer 2 adjacent dark subpixels 2 or fewer...
- Page 29 Please contact our Philips Customer Service Representative or local contact center (by Consumer care number) for more details. Philips Customer Care Center number listed below.
- Page 30 • Contact with Philips customer service • First, ensure that the power button representative immediately. on the front of the monitor is in the...
- Page 31 For further assistance, refer to the Service • Uninterrupted display of still or contact information listed in Important static images over an extended Information Manual and contact Philips period may cause "burn-in", also customer service representative. known as "after-imaging" or "ghost * Functionality different according to imaging", on your screen.
- Page 32 Shut down your computer, monitor, make sure that there is disconnect your old monitor and no pressure or force applied to reconnect your Philips LCD monitor. the panel surface side. This may • Turn on your monitor and then turn affect your warranty conditions.
- Page 33 PC, workstation or Mac? repaired. The damage mentioned above is not covered under your warranty. Ans.: Yes. All Philips LCD monitors are fully compatible with standard Q12: Why is my Display not showing PCs, Macs and workstations.
- Page 34 9.3 Multiview FAQs Ans.: Important Information Manual can be download on the Philips Can I enlarge the PIP sub website support page. window? Q15: Why I cannot automatically Ans.: Yes, there are 3 sizes to select: switch to the connected input [Small], [Middle], [Large].
- Page 35 This product has been manufactured by and is sold under the responsibility of Top Victory Investments Ltd., and Top Victory Investments Ltd. is the warrantor in relation to this product. Philips and the Philips Shield Emblem are registered trademarks of Koninklijke Philips N.V. and are used under license.
