NX-5800SA
UHF DIGITAL TRANSCEIVER
USER GUIDE
This User Guide covers only the basic operations of your radio. Ask
your dealer for information on any customized features they may
have added to your radio. For using details instruction manual (User
Manual), refer to the following URL.
http://manual.kenwood.com/en_contents/search/keyword
TM
TM
•
SD
and microSD
or other countries.
•
The Bluetooth
®
word mark and logos are registered trademarks owned
by Bluetooth SIG, Inc. and any use of such marks by JVC KENWOOD
Corporation is under license. Other trademarks and trade names are those of
their respective owners.
are trademarks of SD-3C, LLC in the United States. and/
B5A-1193-00 (M)
