Kenwood NX-5200 Service Manual

Vhf digital transceiver

Hide thumbs Also See for NX-5200:

User manual (224 pages)

Common function reference (476 pages)

Function reference (190 pages)

100

101

102

103

104

105

106

107

108

109

110

111

112

113

114

115

116

117

118

119

120

121

122

123

124

125

126

page of 126

/ 126
Bookmarks

Quick Links

Summary of Contents for Kenwood NX-5200

Page 1: Table Of Contents
TROUBLESHOOTING ..............1-94 REVISED This service manual has been revised due to the addition of NX-5200 type E, E2. This product complies with the RoHS directive for the European market.
Page 2 Neither is any liability assumed for damages resulting from the use of the information contained herein. JVC KENWOOD Corporation reserves the right to make changes to any products herein at any time for improvement purposes. Firmware Copyrights The title to and ownership of copyrights for firmware embedded in KENWOOD product memories are reserved for JVC KENWOOD Corporation.
Page 3 SPECIFICATION (F2,F3,K2,K3 TYPE) GENERAL Frequency Range 136 ~ 174 MHz Max. Channels per Radio 1024 (Up to 4000 CH with option) Number of Zones Max. Channels per Zone Channel Spacing Analog 12.5 / 15 / 20 / 25* / 30* kHz Digital 6.25 / 12.5 kHz Operating Voltage...
Page 4 *25 and 30 kHz are not included in the models sold in the USA or US territories. Analog measurements made per TIA 603 and specifications shown are typical. P25 Digital measurements made per TIA 102CAAA and specifications shown are typical. JVC KENWOOD Corporation reserves the right to change specifications without prior notice or obligation. 1-4 (No.RA018<Rev.002>)
Page 5 SPECIFICATION (E,E2 TYPE) GENERAL Frequency Range 136 ~ 174 MHz Max. Channels per Radio 1024 (Up to 4000 CH with option) Number of Zones Max. Channels per Zone Channel Spacing Analogue 12.5 / 20 / 25 kHz Digital 6.25 / 12.5 kHz Operating Voltage 7.5V DC±20% Battery Life 5-5-90...
Page 6 Analogue measurements made per EN standards or TIA/EIA 603 and specifications shown are typical. P25 Digital measurements made per TIA 102CAAA and specifications shown are typical. JVC KENWOOD Corporation reserves the right to change specifications without prior notice or obligation. 1-6 (No.RA018<Rev.002>)
Page 7: Precaution
SPECIFIC SERVICE INSTRUCTIONS SYSTEM SET-UP Merchandise received Frequency range (MHz) RF power Type DTMF keypad TX/RX 136~174 NX-5200 F2 NX-5200 F3 Choose the type of transceiver NX-5200 K2 NX-5200 K3 NX-5200 E NX-5200 E2 A personal computer, programming interface (KPG-36U/36X), and FPU (programming software) are required for programming.
Page 8 REALIGNMENT Mode Operation 2.2.1 Modes Firmware programming • [AUX (Orange)] + Power ON mode*2 • [ ] + Power ON User mode Select the “Firmware Prog” using the [] / [] key. Panel tuning mode Panel test mode Press the [ ] key.
Page 9 ] or [*] key, 2.2.6.3 Programming “CLONE MODE” displayed if the entered password is (1) Start up the firmware programming software (KENWOOD correct. If password is incorrect, “Input Password” is re- Firmware Loader). The KFL.exe exists in the KPG-D1/D1N displayed.
Page 10 procedure, “CLONE MODE” is displayed if entered pass- 2.2.8.1 Enter to the Front panel programming mode. word is correct. If the password is incorrect, “Input Pass- Enter to the Menu Mode by pressing [Front Panel Mode] PF key word” is redisplayed. or [Menu] key.
Page 11 • Key operation Key\Item Zone Select Channel RX Frequency TX Frequency Channel Channel RX Signaling TX Signaling Select Type Spacing Decision Decision Decision Decision Decision Decision Decision Decision Unused Back to the Back to the pre- Back Back to the Back to the Back to the Back to the...
Page 12 • Direct enter mode Key\Item Channel Frequency Frequency Signaling Signaling Name Decision Character/Channel name decision Delete Unused Exit panel program mode [] Unused Character selection (upper case char- acter → lower-case character → digit → upper case character...) [] Character selection (upper case char- acter →...
Page 13 • Front panel programming mode flow chart Input Password Clone/Front Panel Password Enter the Front panel programming mode by using section "2.2.2 How to Enter Each Mode". Front panel Programming mode ] or [ Keep This Change? Zone Select Channel Name Channel Select ] or [ ] or [...
Page 14 (F3K-0004-XX) (X42-3330-XX) (G13-2179-XX) (G13-2178-XX) Note: Supplied accessories with * mark are not used for the NX-5200. 2.3.3 INSTALLING THE MODULE IN THE TRANSCEIVER ATTENTION: When installing the module, please take measures to prevent static electricity. (1) Remove the VOID sheet.
Page 15 2.4.1 Overview The NX-5200 is a VHF Analog FM & Digital Portable transceiver designed to operate in the frequency range of 136 to 174MHz. The unit consists of a receiver, a transmitter, a phase-locked loop (PLL) frequency synthesizer, a digital control unit, and a power sup- ply circuit.
Page 16 2.4.3.3 Audio Amplifier Circuit Audio processing (high-pass filter, low-pass filter, de-emphasized and so on) at Analog FM mode and decoding at Digital mode are processed by DSP. SSI signal from DSP is converted to audio signal at IC902. The signal goes to amplifier (IC904 or IC905). While INTAMT is High, IC904 is activated and audio is heard from internal speaker.
Page 17 2.4.5 PLL Frequency Synthesizer 2.4.5.1 TCXO (X700) TCXO (X700) generates a reference frequency of 19.2MHz for the PLL frequency synthesizer. This reference signal is buffered by Q700 and IC700. And it is distributed to TX PLL (IC100), RX PLL (IC200), IF IC (IC600), GPS/Bluetooth (IC850), and IC702. The frequency adjustment is achieved by adjusting a D/A converter (IC901) output in the voltage of the control terminal of TCXO.
Page 18 2.4.6.5 Low Battery Warning The battery voltage is divided using R40 and R41 and is detected by A/D converter (IC900). When the battery voltage falls below the voltage set by the Low battery warning adjustment, the red LED blinks to notify the operator that it is time to replace the battery. If the battery voltage falls even more (approx.
Page 19 (3.15A) Battery Final Amp, APC, Drive Amp IC31 IC32 MPU/DSP RTC 31BU 12BU BackUp Battery SCM Board IC33 MPU/DSP Core, MPU/DSP PLL IC34 MPU/DSP 1.8V I/O, mDDR2, LCD Module I/O IC701 Flash ROM I/O, 18M_3 AudioCodec DVDD IC37 BT & GPS I/O 18BT IC38 BT &...
Page 20 KEY Back Light, 3Color LED, IC82 8bit/16ch ADC, Universal I/F IC801 Universal Option IC36 PLL, IF, VCO IC60 ASSIST 130C IC360 ANTSW ANTSW IC63 50VCO Q110 TX VCO Q210 RX VCO IC65 TX circuit IC64 RX circuit 8bit ADC (1A) Int AF Amp 53AF Ext AF Amp...
Page 21 2.4.9 Bluetooth/GPS Circuit The main component of the BT/GPS circuit is BT/GPS IC (IC850). The clocks of BT/GPS IC require 19.2MHz for core and 32.768kHz slow clock (X850) for UART. 19.2MHz clock (X700) is shared with MPU/DSP (IC702), and is supplied through the clock buffer IC (IC700). The BT/GPS IC communicates to the MPU/DSP (IC702) on the HCI UART.
Page 22 2.4.9.2 GPS Circuit The RF signal is received by the antenna matched by the matching circuit. The matching circuit consists of L905, C948 and C883. And this signal applied to a high-pass filter. The filter consists of C882, C881, C880, L859 and L858. The filtered RF signal is then applied to a SAW filter (L857).
Page 23 Ref. No. Part Name Description Ref. No. Part Name Description IC901 D/A converter Diode Overvoltage protection IC902 CODEC Diode DC SW IC903 D/A converter Diode Backup battery charge IC904,905 IC Audio AMP Diode DC/DC converter IC906 Logic control D100 Zener diode Overvoltage protection Transistor DC SW...
Page 24 TERMINAL FUNCTION Pin No. Name Function 2.6.1 Main unit (XC1-0331-80, XC1-0360-10) - GND Pin No. Name Function ENC1 I Rotary switch input - GND LEDK3 I LCD backlight (Cathode) ENC2 I Rotary switch input LEDK2 I LCD backlight (Cathode) ENC3 I Rotary switch input LEDK1 I LCD backlight (Cathode)
Page 25 Pin No. Name Function Pin No. Name Function I/O Serial data output/USB DP O 5V power supply output DAT2 I/O Data 2 - GND CD/DAT3 I/O Data 3 I MIC identification I/O Command input/output I Programmable function key input O 3.3V output I PTT input O Clock output - MIC GND...
Page 26 Rating and Condition Pin No. Name I/O Signal Type Function Parameter Min Typ Unit - Power 5V power supply output Output Voltage(Iout = 100mA) 4.9 5.0 Maximum Current O Digital Serial data output VOH(Io=-5mA) VOL(Io=5mA) Baud Rate 1.1875 Mbps USB_DP IO Analog USB DP Baud Rate (Full-Speed)
Page 27: Disassembly
SECTION 3 DISASSEMBLY Precautions for Waterproof (2) Remove the selector knob spring <2>. • Do not remove the black sheet from the reverse side of the Note: transceiver (refer to the illustration below). Removal of this Use minimal contact with your fingers on the knob sheet decreases the waterproof efficiency of the transceiver spring.
Page 28 <3> <3> • Regarding VOID, confirm the service policy of the NX- (4) Remove the LCD shielding case from the Main unit. <4> 5200 to KENWOOD (or authorized distributor). <1> <1> VOID seal 3.2.5 Remove the holder ASSY from the chassis (1) Remove the two hooks on the holder ASSY from the chas- sis.
Page 29 (4) Remove the six screws <6>. 3.2.9 Removing the stopper of the selector circle nut and volume circle nut Note: (1) Remove the stopper <1> using a pair of tweezers. When you remove two screws (black), the battery termi- nal block is removed. (5) Anchor the screw hole of the Main unit using the tip of a pair <1>...
Page 30 (4) Move the selector and volume switches and then remove Note: them both from the holes in the chassis. Push evenly on the top cover and be careful that you do not bend it as you install it on the shield cover. 3.2.11 Remove the top cover from the shield cover (1) There are four shield covers (GPS, IF, VCO RX, and VCO Precautions for Reassembly...
Page 31 (6) Press the packing evenly to the base of the chassis. (3) Insert the universal connector FPC into the connector (CN12). <3> Note: (4) Insert the PTT FPC into the connector (CN8). <4> To prevent doing any damage, do not press forcefully on (5) Insert the VOL/SEL/MIC FPC into the connector (CN4).
Page 32 3.3.3 Mounting the chassis onto the case 3.3.4 Changing the channel selector from 16-channel oper- (1) Place the key top on the chassis. Then, fit the chassis tight- ation to free ly into the groove of the key top. <1> (1) Remove the channnel selector knob <1>.
Page 33 Main Parts Assembled Sheet/ Cushion Part Name Part Number Part Name Part Number Remark Plastic Cabinet (F3,K3,E) A0C-0001-00 Badge B4D-0002-00 “KENWOOD” is printed. Plastic Cabinet (F2,K2,E2) A0C-0002-00 Fibrous Sheet (SP) G1A-0001-00 Sheet (LCD) G1B-0074-00 Spacer (2CH) J3K-0003-00 Knob (2CH) K2K-0013-00...
Page 34: Adjustment
SECTION 4 ADJUSTMENT F2,F3,K2,K3 TYPE Controls Power switch/Volume control Selector knob Auxiliary (orange) key Transmit/ Receive/ Battery low indicator Lever switch Side 1 key PTT (Push To Talk) switch Universal connector Side 2 key Side 3 key 4.1.1 Preparations for checking/tuning the transceiver "FNC"...
Page 35 "FNC" appears on the sub LCD display "FNC" appears on the sub LCD display Function Display Function Display Function off [Selector] Compander on/off icon appears [] Talk Around on/off icon appears Function off [] Analog/Phase1/Phase2/ Analog: "A" NXDN P25 phase1: "P1" [AUX For production P25 phase2: "P2"...
Page 36 (2) Test signaling Analog mode signaling STTP-OB-1031-1 0 Burst Pattern STTP-OB-1031 Symmetrical STTP-IB1031-1 None None Tone Pattern (Half rate) STTP-IB1031-1 None Square Wave Silence Pattern STP-IB-1 + LTR Data LTR Data (Half Rate) Silence Pattern (Half Rate) QT:67.0Hz QT:67.0Hz Audio Test Pattern STTP-IB1031-1 + Audio QT:151.4Hz QT:151.4Hz...
Page 37 4.3.2 Key operation Receive Assist, Transmit Assist Function Tuning point Display RX (MHz) TX (MHz) Push Hold (1 second) Low 1 136.05000 136.10000 [Selector] - Low 2 140.80000 140.85000 [  ] Adjustment value up Continuation up Low 3 145.55000 145.60000 [ ...
Page 38 Adjustment Item Description Adjustment Item Description DQT Deviation DQT deviation is adjusted. RSSI Reference The minimum RSSI level for scan stop is adjusted. LTR Deviation LTR deviation is adjusted. Open Squelch The squelch level at level “1” is adjusted. DTMF Deviation DTMF deviation is adjusted.
Page 39 Order Adjusutment Main Sub LCD As *2 Adjust item display (Analog (Analog (Analog (P25 (P25 (NXDN (NXDN item display Wide) Wide 4k) Narrow) Phase1) Phase2) Nar- Very Number row) Nar- row) Adjustment range NXDN High NDEV Transmitter Deviation Section 10 1~1024 QT Deviation 5 *2...
Page 40 4.3.6 Panel tuning mode flow chart Note: * In this Panel tuning mode flow chart, the Adjustment item name is modified. Panel Test Mode Adjustment Item N/W/VN Adjustment Point LCD Display LCD Display ]hold For all adjustment items, press the [ ] key RX Assist 9 reference level...
Page 41 BER (Bit Error Rate) Measurement (1) The Panel Test Mode is used to measure the BER (Refer "4.2.1 Test mode operation features"). (2) Select "10" (P25 Phase1), "7" (P25 Phase2) and "7" (NXDN Mode) for test signaling (Refer to "4.2.3 Frequency and Signaling"...
Page 42 Nut wrench In order to turn the volume nut and the channel selector nut, use a recommendation tool. KENWOOD part No.: W05-1123-00 Battery Jig (W3F-0001-00) Connect the power cable properly between the battery jig installed in the transceiver and the power supply, and be sure output voltage and the power supply polarity prior to switching the power supply ON, otherwise over voltage and reverse connection may damage the transceiver, or the power supply or both.
Page 43  *PC tuning 100 10V PCB layout Connect the wires to the PCB in the connector case of interface cable. AF Voltmeter 100 10V For output the wires out of the connector case, need to process the connector case. 10 10V KPG-36U/36X Audio generator Shield...
Page 44 Item Condition Measurement Adjustment Specifica- tions Panel test PC test mode Test- Unit Terminal Unit Parts Method /Remarks mode equipment 1)CH-Sig: 1-1 1)Test Channel Deviation Panel ANT Adjust AG 12.5mV AG: 1kHz Channel: 1 meter Univer- input to get ±5.8mV sensitivity PTT: ON Test Signaling Mode: Analog...
Page 45 Item Condition Measurement Adjustment Specifications /Remarks Panel tuning PC test mode Test- Unit Ter- Unit Parts Method mode equip- minal ment 1) Adj item: 1) Adj item: Panel [Panel [PC test mode] 2.0V±0.1V Transmit [TAST] [Transmit Assist] tuning [Automatic Adjust- [Automatic Ad- Assist Adjust:[****]...
Page 46 Item Condition Measurement Adjustment Specifications /Remarks Panel tuning PC test mode Test- Unit Ter- Unit Parts Method mode equip- minal ment 1) Adj item: 1) Adj item: Fre- Panel TEST [Panel [Panel tuning mode] Remaks: POINT quency tuning [RTC] [RTC Correction] Press [ ] key to store Change the adjust-...
Page 47 Item Condition Measurement Adjustment Specifica- tions Panel tuning PC test mode Test- Unit Ter- Unit Parts Method /Remarks mode equip- minal ment 1) Adj item: 1) Adj item: Power Panel ANT Panel [Panel [PC test mode] Ramp [RAMPD] [Ramp Down Off- meter tuning [Automatic Adjust-...
Page 48 Adjust:[****] button. (Same as TK-5210, the value after all PTT : ON Press [Apply All] old model of NX-5200). adjustment Press [ ] key to button to store the Press [AUX(Orange)] points have store the adjust- adjustment value.
Page 49 Item Condition Measurement Adjustment Specifica- tions Panel tuning PC test mode Test- Unit Ter- Unit Parts Method /Remarks mode equip- minal ment [Analog 1) Adj item: 1) Adj item: Devia- Panel ANT Panel [Panel Write fixed value “503” 2050~2150Hz Narrow] [An ADEV] [Maxmum Devia- tion...
Page 50 Item Condition Measurement Adjustment Specifica- tions Panel tuning PC test mode Test- Unit Ter- Unit Parts Method /Remarks mode equip- minal ment 1) Adj item: 1) Adj item: Devia- Panel ANT Panel [Panel Write fixed value “505” 2995~3117Hz NXDN [Nn NDEV] [NXDN High Devia- tion tuning...
Page 51 Item Condition Measurement Adjustment Specifica- tions Panel tuning PC test mode Test- Unit Ter- Unit Parts Method /Remarks mode equip- minal ment [Analog 1) Adj item: 1) Adj item: Devia- Panel ANT Panel [Panel Write the value as fol- 0.35kHz±0.05 Narrow] [An QT] [QT Deviation (An-...
Page 52 Item Condition Measurement Adjustment Specifica- tions Panel tuning PC test mode Test- Unit Ter- Unit Parts Method /Remarks mode equip- minal ment 13. LTR 1) Adj item: 1) Adj item: Devia- Panel ANT Panel [Panel Write the value as fol- 1.00kHz±0.05 Devia- [Aw LTR]...
Page 53 Item Condition Measurement Adjustment Specifica- tions Panel tuning PC test mode Test- Unit Ter- Unit Parts Method /Remarks mode equip- minal ment [Analog 1) Adj item: 1) Adj item: Devia- Panel ANT Panel [Panel Write the value as fol- 1.25kHz±0.05 Narrow] [An DTMF] [DTMF Deviation...
Page 54 Item Condition Measurement Adjustment Specifica- tions Panel tuning PC test mode Test- Unit Ter- Unit Parts Method /Remarks mode equip- minal ment 16. MSK 1) Adj item: 1) Adj item: Devia- Panel ANT Panel [Panel Write the value as fol- 3.00kHz±0.05 Devia- [Aw MSK]...
Page 55 Item Condition Measurement Adjustment Specifica- tions Panel tuning PC test mode Test- Unit Ter- Unit Parts Method /Remarks mode equip- minal ment 1) Adj item: 1) Adj item: Power Panel ANT Press the PTT switch or Battery [BATT] [Battery Warning meter BATT [Transmit] button on the...
Page 56 Item Condition Measurement Adjustment Specifica- tions Panel tuning PC test mode Test- Unit Ter- Unit Parts Method /Remarks mode equip- minal ment * The Internal 1) Adj item: [Internal Panel [PC test mode] Internal Microphone Gain Microphone Gain ] Micro- adjustment can [Automatic phone...
Page 57 4.9.1 Necessary Deviation adjustment item for each signaling and mode The following shows the necessary adjustment items for each signaling deviation. Please read the following table like the following example. In the case of the signaling “QT (Analog Wide)”, this signaling is composed of three elements [Balance, Maximum Deviation (Analog Wide) and QT Deviation (Analog Wide)].
Page 58 4.10 Receiver Section Item Condition Measurement Adjustment Specifi- cations Panel tuning mode PC test mode Test- Unit Ter- Unit Parts Method /Remarks equip- minal ment [Panel test mode] 1) Test Channel Panel ANT Panel Vol- Turn the Volume knob to 0.90V AF level 1) CH-Sig: 1-1...
Page 59 Item Condition Measurement Adjustment Specifi- cations Panel tuning mode PC test mode Test- Unit Ter- Unit Parts Method /Remarks equip- minal ment 5. Open 1) Adj item: 1) Adj item: Panel ANT Panel [Panel tuning mode] Squelch [Aw SQL] [Open Squelch (An- Distor- Uni- After input signal from...
Page 60 Item Condition Measurement Adjustment Specifi- cations Panel tuning mode PC test mode Test- Unit Ter- Unit Parts Method /Remarks equip- minal ment [P25 1) Adj item: 1) Adj item: Panel ANT Panel [Panel tuning mode] (LSM)] [P1 SQL] [Open Squelch (P25 Distor- Uni- After input signal from...
Page 61 Item Condition Measurement Adjustment Specifi- cations Panel tuning mode PC test mode Test- Unit Ter- Unit Parts Method /Remarks equip- minal ment 1) Adj item: 1) Adj item: Panel ANT Panel [Panel tuning mode] [An LRSSI] [Low RSSI (Analog Uni- After input signal from RSSI Adjust:[***]...
Page 62 4.11 E, E2 TYPE Controls Power switch/Volume control Selector knob Auxiliary (orange) key Transmit/ Receive/ Battery low indicator Lever switch Side 1 key PTT (Push To Talk) switch Universal connector Side 2 key Side 3 key 4.11.1 Preparations for checking/tuning the transceiver "FNC"...
Page 63 "FNC" appears on the sub LCD display "FNC" appears on the sub LCD display Function Display Function Display Function off [Selector] Compander on/off icon appears [] Talk Around on/off icon appears Function off [] Analog/Phase1/Phase2/ Analog: "A" NXDN P25 phase1: "P1" [AUX For production P25 phase2: "P2"...
Page 64 (2) Test signaling Analog mode signaling STTP-OB-1031-1 0 Burst Pattern STTP-OB-1031 Symmetrical STTP-IB1031-1 None None Tone Pattern (Half rate) STTP-IB1031-1 None Square Wave Silence Pattern STP-IB-1 + LTR Data LTR Data (Half Rate) Silence Pattern (Half Rate) QT:67.0Hz QT:67.0Hz Audio Test Pattern STTP-IB1031-1 + Audio QT:151.4Hz QT:151.4Hz...
Page 65 4.13.2 Key operation Receive Assist, Transmit Assist Function Tuning point Display RX (MHz) TX (MHz) Push Hold (1 second) Low 1 136.05000 136.10000 [Selector] - Low 2 140.80000 140.85000 [  ] Adjustment value up Continuation up Low 3 145.55000 145.60000 [ ...
Page 66 Adjustment Item Description Adjustment Item Description DQT Deviation DQT deviation is adjusted. RSSI Reference The minimum RSSI level for scan stop is adjusted. LTR Deviation LTR deviation is adjusted. Open Squelch The squelch level at level “1” is adjusted. DTMF Deviation DTMF deviation is adjusted.
Page 67 Order Adjusutment Main Sub LCD Adjust item display (Analog (Analog (Analog (P25 (P25 (NXDN (NXDN item display Wide 5k) Wide 4k) Narrow) Phase1) Phase2) Nar- Very Number row) Nar- row) Adjustment range NXDN High NDEV Transmitter Deviation Section 10 1~1024 QT Deviation Transmitter Section 11...
Page 68 4.13.6 Panel tuning mode flow chart Note: * In this Panel tuning mode flow chart, the Adjustment item name is modified. Panel Test Mode Adjustment Item N/W/VN Adjustment Point LCD Display LCD Display ]hold For all adjustment items, press the [ ] key RX Assist 9 reference level...
Page 69 4.14 BER (Bit Error Rate) Measurement (1) The Panel Test Mode is used to measure the BER (Refer "4.2.1 Test mode operation features"). (2) Select "10" (P25 Phase1), "7" (P25 Phase2) and "7" (NXDN Mode) for test signaling (Refer to "4.2.3 Frequency and Signaling"...
Page 70 Nut wrench In order to turn the volume nut and the channel selector nut, use a recommendation tool. KENWOOD part No.: W05-1123-00 Battery Jig (W3F-0001-00) Connect the power cable properly between the battery jig installed in the transceiver and the power supply, and be sure output voltage and the power supply polarity prior to switching the power supply ON, otherwise over voltage and reverse connection may damage the transceiver, or the power supply or both.
Page 71  *PC tuning 100 10V PCB layout Connect the wires to the PCB in the connector case of interface cable. AF Voltmeter 100 10V For output the wires out of the connector case, need to process the connector case. 10 10V KPG-36U/36X Audio generator Shield...
Page 72 Item Condition Measurement Adjustment Specifica- tions Panel test PC test mode Test- Unit Terminal Unit Parts Method /Remarks mode equipment 1)CH-Sig: 1-1 1)Test Channel Deviation Panel ANT Adjust AG 12.5mV AG: 1kHz Channel: 1 meter Univer- input to get ±5.8mV sensitivity PTT: ON Test Signaling Mode: Analog...
Page 73 Item Condition Measurement Adjustment Specifications /Remarks Panel tuning PC test mode Test- Unit Ter- Unit Parts Method mode equip- minal ment 1) Adj item: 1) Adj item: Panel [Panel [PC test mode] 2.0V±0.1V Receive [RAST] [Receive Assist] tuning [Automatic Adjust- [Automatic Ad- Assist Adjust:[****]...
Page 74 Item Condition Measurement Adjustment Specifications /Remarks Panel tuning PC test mode Test- Unit Ter- Unit Parts Method mode equip- minal ment *The Frequen- 1) Adj item: Panel ANT Panel [Panel [PC test mode] [PC test mode] Frequency cy adjust- [Frequency] tuning Press [Start] button of “IF20”...
Page 75 4.19 Transmitter Section Item Condition Measurement Adjustment Specifica- tions Panel tuning PC test mode Test- Unit Ter- Unit Parts Method /Remarks mode equip- minal ment 1) Adj item: 1) Adj item: Power Panel ANT Panel [Pan- [PC test mode] Ramp up [RAMPU] [Ramp Up Offset] meter...
Page 76 Adjust:[****] button. (Same as TK-5210, the value after all PTT : ON Press [Apply All] old model of NX-5200). adjustment Press [ ] key to button to store the Press [AUX(Orange)] points have store the adjust- adjustment value.
Page 77 Item Condition Measurement Adjustment Specifica- tions Panel tuning PC test mode Test- Unit Ter- Unit Parts Method /Remarks mode equip- minal ment 1) Adj item: 1) Adj item: Devia- Panel ANT Panel [Pan- Write fixed value “503” 4150~4250Hz Maxi- [Aw ADEV] [Maxmum Devia- tion el tun-...
Page 78 Item Condition Measurement Adjustment Specifica- tions Panel tuning PC test mode Test- Unit Ter- Unit Parts Method /Remarks mode equip- minal ment 8. P25 1) Adj item: 1) Adj item: Devia- Panel ANT Panel [Pan- Write fixed value “505” 2771~2883Hz High De- [P1 PDEV] [P25 High Devia-...
Page 79 Item Condition Measurement Adjustment Specifica- tions Panel tuning PC test mode Test- Unit Ter- Unit Parts Method /Remarks mode equip- minal ment [NXDN 1) Adj item: 1) Adj item: Devia- Panel ANT Panel [Pan- Write fixed value “495” 1311~1363Hz Very [Nv NDEV] [NXDN High Devia- tion...
Page 80 Item Condition Measurement Adjustment Specifica- tions Panel tuning PC test mode Test- Unit Ter- Unit Parts Method /Remarks mode equip- minal ment [Analog 1) Adj item: 1) Adj item: Devia- Panel ANT Panel [Pan- Write the value as fol- 0.35kHz±0.05 Narrow] [An QT] [QT Deviation (An-...
Page 81 Item Condition Measurement Adjustment Specifica- tions Panel tuning PC test mode Test- Unit Ter- Unit Parts Method /Remarks mode equip- minal ment [Analog 1) Adj item: 1) Adj item: Devia- Panel ANT Panel [Pan- Write the value as fol- 0.35kHz±0.05 Narrow] [An DQT] [DQT Deviation...
Page 82 Item Condition Measurement Adjustment Specifica- tions Panel tuning PC test mode Test- Unit Ter- Unit Parts Method /Remarks mode equip- minal ment [Analog 1) Adj item: 1) Adj item: Devia- Panel ANT Panel [Pan- Write the value as fol- 0.75kHz±0.05 Narrow] [An LTR] [LTR Deviation...
Page 83 Item Condition Measurement Adjustment Specifica- tions Panel tuning PC test mode Test- Unit Ter- Unit Parts Method /Remarks mode equip- minal ment [Analog 1) Adj item: 1) Adj item: Devia- Panel ANT Panel [Pan- Write the value as fol- 1.25kHz±0.05 Narrow] [An DTMF] [DTMF Deviation...
Page 84 Item Condition Measurement Adjustment Specifica- tions Panel tuning PC test mode Test- Unit Ter- Unit Parts Method /Remarks mode equip- minal ment [Analog 1) Adj item: 1) Adj item: Devia- Panel ANT Panel [Pan- Write the value as fol- 1.50kHz±0.05 Narrow] [An TONE] [Single Tone Devi-...
Page 85 Item Condition Measurement Adjustment Specifica- tions Panel tuning PC test mode Test- Unit Ter- Unit Parts Method /Remarks mode equip- minal ment [Analog 1) Adj item: 1) Adj item: Devia- Panel ANT Panel [Pan- Write the value as fol- 1.50kHz±0.05 Narrow] [An MSK] [MSK Deviation...
Page 86 Item Condition Measurement Adjustment Specifica- tions Panel tuning PC test mode Test- Unit Ter- Unit Parts Method /Remarks mode equip- minal ment [Panel test mode] 1)Test Channel Check The transceiv- Battery 1) CH-Sig: 1-1 Channel: 1 er can transmit Warning BATT terminal Test Signaling with causing...
Page 87 Image • Universal connector with tape • Packaging with the LCD facing down (No.RA018<Rev.002>)1-87...
Page 88 4.19.1 Necessary Deviation adjustment item for each signaling and mode The following shows the necessary adjustment items for each signaling deviation. Please read the following table like the following example. In the case of the signaling “QT (Analog Wide 5k)”, this signaling is composed of three elements [Balance, Maximum Devi- ation (Analog Wide 5k) and QT Deviation (Analog Wide 5k)].
Page 89 4.20 Receiver Section Item Condition Measurement Adjustment Specifi- cations Panel tuning mode PC test mode Test- Unit Ter- Unit Parts Method /Remarks equip- minal ment [Panel test mode] 1) Test Channel Panel ANT Panel Vol- Turn the Volume knob to 0.90V AF level 1) CH-Sig: 1-1...
Page 90 Item Condition Measurement Adjustment Specifi- cations Panel tuning mode PC test mode Test- Unit Ter- Unit Parts Method /Remarks equip- minal ment 5. Open 1) Adj item: 1) Adj item: Panel ANT Panel [Panel tuning mode] Squelch [Aw SQL] [Open Squelch (An- Distor- Uni- After input signal from...
Page 91 Item Condition Measurement Adjustment Specifi- cations Panel tuning mode PC test mode Test- Unit Ter- Unit Parts Method /Remarks equip- minal ment [P25 1) Adj item: 1) Adj item: Panel ANT Panel [Panel tuning mode] (C4FM)] [P1 SQL] [Open Squelch (P25 Distor- Uni- After input signal from...
Page 92 Item Condition Measurement Adjustment Specifi- cations Panel tuning mode PC test mode Test- Unit Ter- Unit Parts Method /Remarks equip- minal ment [NXDN 1) Adj item: 1) Adj item: Panel ANT Panel [Panel tuning mode] Very [Nv SQL] [Open Squelch Distor- Uni- After input signal from...
Page 93 Item Condition Measurement Adjustment Specifi- cations Panel tuning mode PC test mode Test- Unit Ter- Unit Parts Method /Remarks equip- minal ment [Analog 1) Adj item: 1) Adj item: Panel ANT Panel [Panel tuning mode] Wide 4k] [As SQLT] [Tight Squelch (Ana- Distor- Uni- After input signal from...
Page 94: Troubleshooting
SECTION 5 TROUBLESHOOTING Fault Diagnosis of the BGA (Ball Grid Array) IC Overview: A flowchart for determining whether or not the transceiver can be powered on (the LCD does not function even if the power switch is turned on) due to broken BGA parts. BGA parts: MPU/DSP (IC702), mobile DDR (IC703), Flash memory (IC705) When the BGA IC is problematic, please bring the printed circuit board (XC1-0331-81/XC1-0360-11) in for service.
Page 95 When a normal Checking the output signal value is confirmed. from the MPU/DSP. When an abnormal If the IC706 (1 pin) is 0V or 1.8V, the MPU/DSP Normal voltage Points to be checked value is confirmed. may be broken. After power-on, and /CS_F IC706 (4 pin) If the IC706 (2 pin) is 0V or 1.8V, the MPU/DSP 1.8V...
Page 96 Failure diagnosis of the GPS section Overview: When the GPS fuction does not operate, use this flowchart to determine the problem. Major parts for a GPS circuit GPS antenna (Connect on CN907) IC702 IC850 L857 Shee t metal IC852 LNA IC (IC851) UART UART Pre-SAW Filter (L857)
Page 97 When a normal condition is confirmed. [The reference clock circuit When an abnormal When an abnormal Verify the reference clock for the BT/GPS. for the BT/GPS is faulty]. condition is confirmed. condition is confirmed. (BT_CLK) Intersection of Check the PCB side B (c). Visual check of the PCB side A parts C850 and R861: Sine waveform, (Whether not damaged)
Page 98 [The GPS RF input circuit is faulty] Verify the RF input circuit for the GPS. When an abnormal Replace the GPS RF input circuit HPF, Pre-SAW, LNA, ATT, Post-SAW, condition is confirmed. parts. (only the parts which can be GPS IC RF Matching. replaced.) If any unexchangeable HPF parts: C882, C881, C880, L859, L858 parts are abnormal, replace the PCB.
Page 99 Failure diagnosis of the Bluetooth section Overview: When the Bluetooth function does not operate, use this flowchart to determine the problem. Major parts for a Bluetooth circuit IC702 IC852 IC850 Bluetooth antenna (Connect on CN909) UART UART Shee t metal L855 Level LC filter (L855)
Page 100 When a normal condition is confirmed. [The reference clock circuit Verify the reference clock for the BT/GPS. When an abnormal When an abnormal for the BT/GPS is faulty] (BT_CLK) Intersection of condition is confirmed. condition is confirmed. Visual check of the PCB side A parts Check the PCB side B (c).
Page 101 Check the PCB side B (a). When a normal condition is confirmed. When an abnormal [The BT/GPS power supply line 33BT circuit is faulty] condition is confirmed. Visual check of the PCB side B parts. [The BT/GPS IC is abnormal] (Whether not damaged) Replace the PCB.
Page 102 KENWOOD ESN/ NXDN ESN/ Product Number/ MPT ESN/P25 ESN Label • When a new printed circuit board is used, the KENWOOD ESN changes, as does the Transceiver Information dis- play of the KPG-D1/D1N, but this does not have any effect on the operation of the transceiver.
Page 103 ESN Label Layout ESN Label Note: Cut a UPC code and UPC barcode at dotted line. (No.RA018<Rev.002>)1-103...
Page 104 MEMO...
Page 105 SCHEMATIC DIAGRAM MAIN UNIT (XC1-0331-80 (NX-5200(F2), NX-5200(F3), NX-5200(K2), NX-5200(K3)), XC1-0360-10 (NX-5200(K2), NX-5200(K3), NX-5200(E), NX-5200(E2))) HDQ_1 Q160 OVER HOLD_T VOLTAGE OSCILLATION R:0V T:4.17V PROTECTION 7.50V SDET C197 IC20 C196 C190 CN301 RESET IC 7.47V 4.98V 13V DC/DC C114 L187 C188 BATT...
Page 106 BLOCK DIAGRAM DC SW 50VCO 50VCO_T Q110 SSM3J15FS Q181 2SC5108F/Y/ Q101 DSC9A01/T/ D101 1SS400SM Q111 EM6M2 IC702 Ripple 50VCO DC SW IC100 Filter SKY72310362LF 136-174MHz --------------------------------------------------------- --CODEC(IC902)-- /CRST,MCLK,CODEC_DI,CODEC_DO IC712 (2/2) IC102 (1/2) --------------------------------------------------------- TC7WH14FK-F BU7242NUX --SD(J1)-- SD1_DAT [0]~SD1_DAT[3],SD1_CLK,SD1_CMD,/SD_DET /PLD_T CV_T --------------------------------------------------------- --UNIVERSAL CONNECTOR(CN12)-- PLL_MOD...
Page 107 PRINTED CIRCUIT BOARD MAIN UNIT (XC1-0331-80 (NX-5200(F2), NX-5200(F3), NX-5200(K2), NX-5200(K3)), XC1-0360-10 (NX-5200(K2), NX-5200(K3), NX-5200(E), NX-5200(E2))) --- Component side view (J79-0410-19) --- XC1-033/036 J79-0410-19 CN31 R858 R859 R870 R806 C223 C808 C807 C222 IC852 IC853 R745 R217 R746 L861 C891 C885...
Page 108 MAIN UNIT (XC1-0331-80 (NX-5200(F2), NX-5200(F3), NX-5200(K2), NX-5200(K3)), XC1-0360-10 (NX-5200(K2), NX-5200(K3), NX-5200(E), NX-5200(E2))) --- Foil side view (J79-0410-19) --- C603 Q330 L600 L601 L857 L165 R600 CP600 C220 C880 C169 C283 L602 R281 L248 C171 R248 C219 L285 C615 L858 L185...
Page 109 A-1C ADDRESS TABLE OF BOARD PARTS Side Y axis Each address may have an address error by one X axis interval. REF.NO. LOCATION REF.NO. LOCATION REF.NO. LOCATION REF.NO. LOCATION REF.NO. LOCATION REF.NO. LOCATION REF.NO. LOCATION REF.NO. LOCATION REF.NO. LOCATION REF.NO. LOCATION REF.NO. LOCATION REF.NO. LOCATION REF.NO. LOCATION REF.NO. LOCATION REF.NO. LOCATION REF.NO. LOCATION REF.NO. LOCATION Q310 B- 4A A- 3A...
Page 110 LEVEL DIAGRAM Receiver section RF (Center Frequency) 1st IF (49.95MHz) AF (1kHz) f1: -122.0dBm f1:-121.5dBm f1:-118.0dBm 238mVp -p f2:-117.5dBm f2:-117.0dBm -113.5dBm -113.5dBm -121.5dBm -112.0dBm -105.5dBm f2: -118.0dBm D350 D351 D370 IC702 C352 D371 C372 C541 Q530 R540 C511 Q500 C558 XF670 C676 Q670 C670 Q660 C660 IC902 C926 IC904...
Page 111 PARTS LIST [NX-5200] * SAFETY PRECAUTION Parts identified by the symbol are critical for safety. Replace only with specified part numbers. * BEWARE OF BOGUS PARTS Parts that do not meet specifications may cause trouble in regard to safety and performance.
Page 112 Exploded view of general assembly and parts list Block No.M1MM MAIN UNIT<01> 3-2(No.RA018<Rev.002>)
Page 113 REAR PANEL A1A-0005-10 CHASSIS B0K-0024-00 SD CARD B38-0960-05 LCD ASSY 1.74IN B4B-0006-00 CAUTION STICKER FCC L,CAUTION F2,F3,K2,K3 B4C-0105-00 TER.STICKER TERMINAL BLOCK B4D-0002-00 KENWOOD BADGE D32-0454-04 STOPPER 16CH D3C-0001-10 STOPPER CIRCULAR NUT E04-0467-15 C.RECEPTACLE-SM E2D-0003-00 TERMINAL E3H-0007-00 LEAD.WIRE W.C. E58-0532-05 R.RECEPTACLE E7C-0001-00...
Page 114  Symbol No. Part No. Part Name Description Local N84-2004-43 P.HEAD T.SCREW TERM-BL(+,-)(x2) XC1-0331-81 SERVICE MAIN UNIT SERVICE UNIT *Produced in Japan F2,F3,K2,K3 XC1-0360-11 SERVICE MAIN UNIT SERVICE UNIT *Produced in Malaysia K2,K3,E,E2 3-4(No.RA018<Rev.002>)
Page 115 Electrical parts list MAIN UNIT  Symbol No. Part No. Part Name Description Local XC1-0331-80(NX-5200_F2,NX-5200_F3, EMD12 TRANSISTOR NX-5200_K2,NX-5200_K3) SSM6N37FE SSM6N37FE XC1-0360-10(NX-5200_K2,NX-5200_K3, SSM3K15AMFV NX-5200_E,NX-5200_E2) KTA2012EP TRANSISTOR EM6M2 *Note : This part cannot be replaced. There- EM6M2 LTC014EEBFS8 DIGI TRANSISTOR fore, this part is not supplied as a service part. 2SB1132(Q,R) TRANSISTOR Q100...
Page 116  Symbol No. Part No. Part Name Description Local  Symbol No. Part No. Part Name Description Local D601 SMV1705-079LF VARI CAP DIODE CK73HB1A105K C CAPACITOR 1uF 10V K D603 DA3S101F DIODE ARRAY CK73GB1A335K C CAPACITOR 3.3uF 10V K D700 RB521CM-30 DIODE CK73GB1A335K C CAPACITOR...
Page 117  Symbol No. Part No. Part Name Description Local  Symbol No. Part No. Part Name Description Local C191 CC73HCH1H270G C CAPACITOR 27pF 50V G C328 CK73HBB1H102K C CAPACITOR 1000pF 50V K C192 CC73HCH1H060B C CAPACITOR 6pF 50V B C331 CK73HBB1H102K C CAPACITOR 1000pF 50V K C193...
Page 118  Symbol No. Part No. Part Name Description Local  Symbol No. Part No. Part Name Description Local C553 CK73HB1H103K C CAPACITOR 10000pF 50V K C676 CC73HCH1H120G C CAPACITOR 12F 50V G C554 CK73HBB1H102K C CAPACITOR 1000pF 50V K C678 CC73HCH1H220G C CAPACITOR 22pF 50V G C558...
Page 119  Symbol No. Part No. Part Name Description Local  Symbol No. Part No. Part Name Description Local C775 CC73JCH1H101J C CAPACITOR 100pF 50V J C860 CC73HCH1H180J C CAPACITOR 18pF 50V J C776 CK73HB1H103K C CAPACITOR 10000pF 50V K C861 CK73HB1A105K C CAPACITOR 1uF 10V K C777...
Page 120  Symbol No. Part No. Part Name Description Local  Symbol No. Part No. Part Name Description Local C943 CK73HB1E104K C CAPACITOR 0.10uF 25V K RK73JB1H102J MG RESISTOR 1Ω 1/20W J C944 CK73HB1E104K C CAPACITOR 0.10uF 25V K R92-3774-05 MG RESISTOR 27Ω...
Page 121  Symbol No. Part No. Part Name Description Local  Symbol No. Part No. Part Name Description Local R206 RK73HB1J100J MG RESISTOR 10Ω 1/16W J R409 RK73HB1J470J MG RESISTOR 47Ω 1/16W J R207 RK73HB1J102J MG RESISTOR 1kΩ 1/16W J R410 RK73HB1J000J MG RESISTOR 0Ω...
Page 122  Symbol No. Part No. Part Name Description Local  Symbol No. Part No. Part Name Description Local R708 RK73HB1J681J MG RESISTOR 680Ω 1/16W J R836 RK73HB1J101J MG RESISTOR 100Ω 1/16W J R710 RK73HB1J222J MG RESISTOR 2.2kΩ 1/16W J R837 RK73HB1J000J MG RESISTOR 0Ω...
Page 123  Symbol No. Part No. Part Name Description Local  Symbol No. Part No. Part Name Description Local LB73H0AV-002 CHIP FERRITE L607 LB73H0AV-003 CHIP FERRITE LB73G0BJ-002 CHIP FERRITE L608 LB73H0AV-003 CHIP FERRITE LB73H0AV-002 CHIP FERRITE L609 L41-1885-53 CHIP INDUCTOR L41-1502-70 CHIP INDUCTOR L610 LK73G0AQ100K M.CHIP INDUCTOR 10uH...
Page 124  Symbol No. Part No. Part Name Description Local CP600 RK74HB1J100J NET RESISTOR 10Ω 1/16W J CP601 RK74HB1J100J NET RESISTOR 10Ω 1/16W J CP700 RK74HB1J100J NET RESISTOR 10Ω 1/16W J CP701 RK74HB1J101J NET RESISTOR 100Ω 1/16W J CP702 RK74HB1J101J NET RESISTOR 100Ω...
Page 125 Packing materials and accessories parts list Block No.M2MM Packing and accessories Block No. [M][2][M][M]  Symbol No. Part No. Part Name Description Local B0K-0002-00 B5A-0049-10 INSTRUCTION MANUAL F2,F3,K2,K3 B5A-0940-00 INSTRUCTION MANUAL ACC/9 LANG E,E2 ------------ PAMPHLET SAR(E,F) F2,F3,K2,K3 ------------ PAMPHLET ROHS2 E,E2 G5D-0027-00...
Page 126 JVC KENWOOD Corporation Communications Systems Business Unit (No.RA018<Rev.002>) Printed in Japan...
