Sealey ATCR01R Instructions

Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
Refer to
instruction
manual
1. SAFETY
WARNING! This product relies on the integrity of the existing structures on the ATV it is fitted to. It is the owner's responsibility to
‰
ensure that:
The structure of the ATV is sound and capable of withstanding the weight of the rack and its contents.
9
The ATV manufacturer's specification has been consulted to ensure that the ATV is safe to operate with cargo rack/s and their loads.
9
Ensure that the rack if fitted to the ATV using the supplied fittings and that the fittings are capable of supporting both rack and load.
9
Check rack fixings before each use.
9
Risk assess the load and where it is to be taken before use.
9
Remember that your ability to control the ATV by your body movements will be considerably reduced when carrying a load.
9
Racks and their loads should be fitted as close to the centre of gravity as possible. Loads should be secured as appropriate.
9
DO NOT use racks to carry passengers.
8
2. INTRODUCTION
Lightweight but sturdy mesh surface to avoid accumulation of dust and water. Small mesh design protects items from falling through.
Constructed from high quality materials, capable of holding large items securely. Firmly attaches to ATV to prevent it falling off, even in
demanding conditions. Ample storage space with short sides and open top, allowing larger objects to fit. Supplied with quick and easy fittings
and fits onto most standard ATVs. Powder coated metal frame, ensuring high strength and good wear resistance to withstand rugged outdoor
use.
3. INSTALLATION
This edge to front of ATV
3.1. The 4 U bolt fixings must be used around the box section structure of the rack and the rack assembly of the ATV.
3.2. Location of the 4 U bolt fixings is dependant on the design of the ATV. However they must be spaced so as to spread the load equally
across the rack.
© Jack Sealey Limited
ATV REAR CARGO RACK
ATCR01R, ATCR02R
MODEL NO'S:
Original Language Version ATCR01R ATCR02R Issue:1 27/11/24
