Lynx S VD 5082 Reference Manual

Sdi 8 2 input switch with reference
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Version 1.2
Reference Manual
S VD 5082
SDI 8 > 2 Input Switch with Reference
© LYNX Technik AG
Brunnenweg 3
D-64331 Weiterstadt
Germany
www.lynx-technik.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the S VD 5082 and is the answer not in the manual?

Questions and answers

Related Manuals for Lynx S VD 5082

Summary of Contents for Lynx S VD 5082

  • Page 1 Version 1.2 Reference Manual S VD 5082 SDI 8 > 2 Input Switch with Reference © LYNX Technik AG Brunnenweg 3 D-64331 Weiterstadt Germany www.lynx-technik.com...
  • Page 2 Except as expressly written by LYNX Technik AG, the furnishing of this document does not give you any license to patents, trademarks, copyrights or other intellectual property of LYNX Technik AG or any of its affiliates.

  • Page 3: Warranty

    LYNX Technik, with shipping charges prepaid. LYNX Technik shall pay for the return of the product to the customer if the shipment is within the country which the LYNX Technik service center is located.

  • Page 4: Regulatory Information

    Reference Manual S VD 5082 Version 1.2 Regulatory information Europe Declaration of Conformity LYNX Technik AG Brunneweg 3 D-64331 Weiterstadt Germany Declare under our sole responsibility that the product TYPE: S VD 5082 To which this declaration relates is in conformity with the following...

  • Page 5: Table Of Contents

    Reference Manual S VD 5082 Version 1.2 Contents Warranty................3 Regulatory information........... 4 Europe ..................4 Declaration of Conformity..........4 USA..................4 FCC 47 Part 15 ..............4 Contents................5 Getting Started ..............7 Packaging ................7 Product Description..............7 Functional Diagram..............8 Module Layout................8 Connections ..............11 Video Connections ..............11...
  • Page 6 Reference Manual S VD 5082 Version 1.2 This page is intentionally left blank Page 6...

  • Page 7: Getting Started

    Product Description The S VD 5082 is a high quality digital video 8 > 2 input switch designed primarily for broadcast and professional applications. The S VD 5082 has 8 inputs for digital video signals, which can be switched to two independent outputs.

  • Page 8: Functional Diagram

    S VD 5082 CardModule. Figure 1- S VD 5082 Functional Diagram Module Layout Figure 2 shows the layout of the S VD 5082 CardModule and the rear connection panel. Please refer the connections section of this manual for wiring details for the connectors.
  • Page 9 Reference Manual S VD 5082 Version 1.2 Figure 2 – Module Layout Page 9...
  • Page 10 Reference Manual S VD 5082 Version 1.2 Caution Use static precautions when handling the PCB. Static discharge could result in serious damage to the module. Page 10...

  • Page 11: Connections

    Reference Manual S VD 5082 Version 1.2 Connections Video Connections The S VD 5082 CardModule is configured with standard 75 Ohm BNC connectors. Connection is self-explanatory. We recommend the use of high quality video cable for digital video connections to reduce the risk of interference or errors due to excessive cable attenuation.

  • Page 12: Installation

    Reference Manual S VD 5082 Version 1.2 Installation Caution The CardModule is shipped in a protective anti-static bag. Please take suitable precautions to avoid static discharge onto any part of the PCB or components when handling module or serious damage could result.

  • Page 13: Settings And Control

    Reference Manual S VD 5082 Version 1.2 Settings and Control The S VD 5082 has an integrated micro-controller, which enables the module to be configured and controlled locally using the multifunction switch and 4 character dot matrix display, or from remote when using one of the optional controllers and control software.

  • Page 14: Multi Function Switch

    Reference Manual S VD 5082 Version 1.2 Multi Function Switch The CardModule is equipped with a multi-function switch located on the front bottom edge of the card (refer to figure 3) Multi-function Switch Side Front Switch Operations Down Enter Figure 4 – Switch Operation...

  • Page 15: Using The Local Display Menus

    Reference Manual S VD 5082 Version 1.2 Using the Local Display Menus Making local adjustments to the module is done using the multifunction switch and the integrated 4- character dot matrix display (figure 3). The menu system is layered, and navigation through the system is done using the UP and DOWN functions of the switch.
  • Page 16 Reference Manual S VD 5082 Version 1.2 Page 16...
  • Page 17 Reference Manual S VD 5082 Version 1.2 Page 17...

  • Page 18: Auto Store

    A remote control panel can be connected to the S VD 5082 via the SubD 25 female connector on the connection plate of the S VD 5082. Below is a description of the required connections. There are two versions possible:...
  • Page 19 Reference Manual S VD 5082 Version 1.2 Serial Interface Page 19...
  • Page 20 Reference Manual S VD 5082 Version 1.2 Pin Description for SubD female connector PIN Function config Input 1 select config Input 2 select config Input 3 select config Input 4 select config Input 5 select config Input 6 select config...

  • Page 21: Alarm/Led Status Indicators

    Reference Manual S VD 5082 Version 1.2 Alarm/LED Status Indicators The S VD 5082 module has integral LED indicators, which serve as alarm and status indication for the module. Function is described below. Channel Condition Indicators 2 status LEDs are provided on the top edge of the...

  • Page 22: Locate Function

    Reference Manual S VD 5082 Version 1.2 Locate Function For larger systems which may have multiple cards of the same type in a single rack, or multiple rack systems on a large central control system we have added a useful utility which will help to visually...

  • Page 23: Specifications (S Vd 5082)

    Reference Manual S VD 5082 Version 1.2 Specifications (S VD 5082) Inputs Signal 8 Serial Digital Video. SMPTE 259M-C Input Impedance 75 Ohms Input level 0.8V p-p Return loss > 15dB (270MHz) Connection Outputs Signal 2 Serial Digital Video SMPTE 259M-C...

  • Page 24: Available Options

    Reference Manual S VD 5082 Version 1.2 Available Options Below is a list of related products for the S VD 5082 CardModule. Please refer to product brochures or our web site for more detailed information. Model Description Series 5000 Rack Frame (empty) with single...

  • Page 25: Service

    Reference Manual S VD 5082 Version 1.2 Service If you are experiencing problems, or have questions concerning your S VD 5082 CardModule please contact your local distributor for assistance. We offer a fixed cost service exchange program for defective Series 5000 CardModules out of Warranty.

  • Page 26: Contact Information

    Reference Manual S VD 5082 Version 1.2 Contact Information Please contact your local distributor; this is your local and fastest method for obtaining support and sales information. LYNX Technik can be contacted directly using the information below. Address LYNX Technik AG...
  • Page 27 Reference Manual S VD 5082 Version 1.2 Notes Page 27...
