Version 1.2
Reference Manual
S VD 5012
SDI Change Over Switch
© LYNX Technik AG
Brunnenweg 3
D-64331 Weiterstadt
Germany
www.lynx-technik.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the S VD 5012 and is the answer not in the manual?

Questions and answers

Summary of Contents for Lynx S VD 5012

  • Page 1 Version 1.2 Reference Manual S VD 5012 SDI Change Over Switch © LYNX Technik AG Brunnenweg 3 D-64331 Weiterstadt Germany www.lynx-technik.com...
  • Page 2 Except as expressly written by LYNX Technik AG, the furnishing of this document does not give you any license to patents, trademarks, copyrights or other intellectual property of LYNX Technik AG or any of its affiliates.
  • Page 3: Warranty

    LYNX Technik, with shipping charges prepaid. LYNX Technik shall pay for the return of the product to the customer if the shipment is within the country which the LYNX Technik service center is located.
  • Page 4: Regulatory Information

    Reference Manual S VD 5012 Version 1.2 Regulatory information Europe Declaration of Conformity LYNX Technik AG Brunneweg 3 D-64331 Weiterstadt Germany Declare under our sole responsibility that the product TYPE: S VD 5012 To which this declaration relates is in conformity with the following...
  • Page 5: Table Of Contents

    Reference Manual S VD 5012 Version 1.2 Contents Warranty................3 Regulatory information........... 4 Europe ..................4 Declaration of Conformity..........4 USA..................4 FCC 47 Part 15 ..............4 Contents................5 Getting Started ..............7 Packaging ................7 Product Description..............7 Functional Diagram..............8 Module Layout................8 Connections ..............10 Video Connections ..............10...
  • Page 6 Reference Manual S VD 5012 Version 1.2 This page is intentionally left blank Page 6...
  • Page 7: Getting Started

    The PREVIEW output always shows the non-used input, while the MAIN output shows the currently used input. The S VD 5012 is part of the 5000 series of CardModules, which offer high quality, modularity and flexibility in a small form factor ideal for applications where space is at a premium.
  • Page 8: Functional Diagram

    S VD 5012 CardModule. Figure 1- S VD 5012 Functional Diagram Module Layout Figure 2 shows the layout of the S VD 5012 CardModule and the rear connection panel. Please refer the connections section of this manual for wiring details for the connectors.
  • Page 9 Reference Manual S VD 5012 Version 1.2 Figure 2 – Module Layout Caution Use static precautions when handling the PCB. Static discharge could result in serious damage to the module. Page 9...
  • Page 10: Connections

    Reference Manual S VD 5012 Version 1.2 Connections Video Connections The S VD 5012 CardModule is configured with standard 75 Ohm BNC connectors. Connection is self-explanatory. We recommend the use of high quality video cable for digital video connections to reduce the risk of interference or errors due to excessive cable attenuation.
  • Page 11: Switch Modes

    Reference Manual S VD 5012 Version 1.2 Switch Modes The S VD 5012 CardModule can be switched through various modes. Note: MAIN OUT and PREVIEW are switched simultaneously. If MAIN OUT = MAIN IN then PREVIEW = BYPASS If MAIN OUT = BYPASS then PREVIEW = MAIN IN...
  • Page 12: Gpi

    Reference Manual S VD 5012 Version 1.2 The S VD 5012 CardModule is configured with a standard 75 Ohm BNC connector for a General Purpose Input (GPI). If Switch Mode “GPI” is selected the input switch can be externally triggered/switched through this GPI.
  • Page 13: Installation

    Reference Manual S VD 5012 Version 1.2 Installation Caution The CardModule is shipped in a protective anti-static bag. Please take suitable precautions to avoid static discharge onto any part of the PCB or components when handling module or serious damage could result.
  • Page 14: Settings And Control

    Reference Manual S VD 5012 Version 1.2 Settings and Control The S VD 5012 has an integrated micro-controller, which enables the module to be configured and controlled locally using the multifunction switch and 4 character dot matrix display, or from remote when using one of the optional controllers and control software.
  • Page 15: Multi Function Switch

    Reference Manual S VD 5012 Version 1.2 Multi Function Switch The CardModule is equipped with a multi-function switch located on the front bottom edge of the card (refer to figure 3) Multi-function Switch Side Front Switch Operations Down Enter Figure 4 – Switch Operation...
  • Page 16: Using The Local Display Menus

    Reference Manual S VD 5012 Version 1.2 Using the Local Display Menus Making local adjustments to the module is done using the multifunction switch and the integrated 4- character dot matrix display (figure 3). The menu system is layered, and navigation through the system is done using the UP and DOWN functions of the switch.
  • Page 17 Reference Manual S VD 5012 Version 1.2 Page 17...
  • Page 18: Auto Store

    Reference Manual S VD 5012 Version 1.2 Auto Store If no parameters are changed for 10 seconds then the current settings will be written into flash memory automatically, this can be seen by the channel status LEDS flashing yellow four times.
  • Page 19: Alarm/Led Status Indicators

    Reference Manual S VD 5012 Version 1.2 Alarm/LED Status Indicators The S VD 5012 module has integral LED indicators, which serve as alarm and status indication for the module. Function is described below. Channel Condition Indicators 2 status LEDs are provided on the top edge of the module, one for each channel (MAIN, BYPASS;...
  • Page 20: Locate Function

    Reference Manual S VD 5012 Version 1.2 Locate Function For larger systems which may have multiple cards of the same type in a single rack, or multiple rack systems on a large central control system we have added a useful utility which will help to visually...
  • Page 21: Specifications (S Vd 5012)

    Reference Manual S VD 5012 Version 1.2 Specifications (S VD 5012) Inputs Signal 2 Serial Digital Video. SMPTE 259M-C Input Impedance 75 Ohms Input level 0.8V p-p Return loss > 15dB (270MHz) Connection Outputs Signal 4 Serial Digital Video (2 x MAIN out, 2 x Preview)
  • Page 22: Available Options

    Reference Manual S VD 5012 Version 1.2 Available Options Below is a list of related products for the S VD 5012 CardModule. Please refer to product brochures or our web site for more detailed information. Model Description Series 5000 Rack Frame (empty) with single...
  • Page 23: Service

    Reference Manual S VD 5012 Version 1.2 Service If you are experiencing problems, or have questions concerning your S VD 5012 CardModule please contact your local distributor for assistance. We offer a fixed cost service exchange program for defective Series 5000 CardModules out of Warranty.
  • Page 24: Contact Information

    Reference Manual S VD 5012 Version 1.2 Contact Information Please contact your local distributor; this is your local and fastest method for obtaining support and sales information. LYNX Technik can be contacted directly using the information below. Address LYNX Technik AG...
  • Page 25 Reference Manual S VD 5012 Version 1.2 Notes Page 25...
