Please read this manual carefully before proceeding with installation. Your failure to
follow any of these instructions or operating parameters may lead to personal injury
or damage to the equipment and/or personal property. Do not use this water
treatment system with water that is microbiologically unsafe or of unknown quality,
without adequate disinfection before or after the system. This water treatment
system contains replaceable treatment components critical for effective
performance. It is the user's responsibility to periodically test the product water to
verify the system is performing satisfactorily. Failure to properly maintain this water
treatment system may cause a health risk.
Save this manual for future reference
l
Aqua Magic 2815
04.12.2024 SB

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AQUA MAGIC 2815 and is the answer not in the manual?

Questions and answers

Related Manuals for Frakco AQUA MAGIC 2815

Summary of Contents for Frakco AQUA MAGIC 2815

  • Page 1 It is the user’s responsibility to periodically test the product water to verify the system is performing satisfactorily. Failure to properly maintain this water treatment system may cause a health risk. Save this manual for future reference Aqua Magic 2815 04.12.2024 SB...

  • Page 2: Table Of Contents

    Table of Contents Operating Parameters ..........................3 Installation ............................4 Start-Up Instructions (Electromechanical Timer Only) ................5 3200 Timer Setting Procedure ........................6 3210 Timer Setting Procedure ........................7 3200, 3210 Regeneration Cycle Setting Procedure ..................8 Timer Setting Procedure ........................8 3210 Meter Delayed Timer Assembly ...................... 10 Sxt Timer Assembly ..........................

  • Page 3: Operating Parameters

    IMPORTANT PLEASE READ: OPERATING PARAMETERS • The information, specifications and illustrations in this manual are Minimum Pressure 20 psi/1.38 bar/138 kPa based on the latest information available at the time of release. The manufacturer reserves the right to make changes at any time without Maximum Pressure 125 psi/8.62 bar/862 kPa notice.

  • Page 4: Installation

    Installation Locations INSTALLATION FOR DRY LOCATIONS ONLY. Water Pressure A minimum of 20 psi/1.38 bar/138 kPa water pressure is Bypass Valves required for control valve to operate effectively. Always provide for the installation of a bypass valve if unit is Water pressure is not to exceed 125 psi (8.6 bar), not equipped with one.

  • Page 5: Start-Up Instructions (Electromechanical Timer Only)

    INSTALLATION Continued 6. Close and secure the control box cover. 7. Put salt in the brine tank. 14. Manually advance the control valve through the cycle Do not use granulated or rock salt. positions (checking for leaks at each position) and Salt level must always be above water level in brine tank.

  • Page 6: 3200 Timer Setting Procedure

    3200 TIMER SETTING PROCEDURE How To Set Days On Which Water Conditioner Is To Regenerate (Figure 4) Rotate the skipper wheel until the number “1” is at the red pointer. Set the days that regeneration is to occur by sliding tabs on the skipper wheel outward to expose trip fingers.

  • Page 7: 3210 Timer Setting Procedure

    3210 TIMER SETTING PROCEDURE Typical Programming Procedure Calculate the gallon capacity of the system, subtract the necessary reserve requirement and set the gallons available opposite the small white dot on the program wheel gear (Figure 54). NOTE: Drawing shows 8,750 gallon setting. The capacity (gallons) arrow (15) shows zero gallons remaining.

  • Page 8: 3200, 3210 Regeneration Cycle Setting Procedure

    3200, 3210 REGENERATION CYCLE SETTING PROCEDURE How To Set The Regeneration Cycle Program The regeneration cycle program on your water conditioner has been factory preset, however, portions of the cycle or program may be lengthened or shortened in time to suit local conditions.
  • Page 9 3200 TIME CLOCK TIMER ASSEMBLY 62018 Rev A Item No. Part No. Description ....1..62018-10 ... Timer Assy, EM, 2815, 12 Day, 60Hz ..62018-11 ... Timer Assy, EM, 2815, 12 Day, 50Hz ..62018-20 ... Timer Assy, EM, 2815, 7 Day, 60Hz ..

  • Page 10: 3210 Meter Delayed Timer Assembly

    3210 METER DELAYED TIMER ASSEMBLY 62019 Rev A Item No. Part No. Description ....1..62019-11... Timer Assy, EM, 2815, Delay, 60Hz 1-1/2”STD ..62019-12 ..Timer Assy, EM, 2815, Delay, 50Hz 1-1/2”STD ..62019-13 ..Timer Assy, EM, 2815, Delay, 60Hz 1-1/2”, 40M3, EXT ..

  • Page 11: Sxt Timer Assembly

    SXT TIMER ASSEMBLY 62066 Rev A Item No. Part No. Description ....1..62066 ....Timer Assy. SXT, DC, 2815 Not Shown ..62057 ....Kit, Wire Harness, DC ..44164 ....Power Supply, Intl, 24V DC 3M, 2A...

  • Page 12: Xtr2 Timer Assembly

    XTR2 TIMER ASSEMBLY 62067 Rev A Item No. Part No. Description ....1 ..62067 ....Timer Assy, XTR2, 2815 Not Shown ..62057 ....Kit, Wire Harness, DC ..44164 ....Power Supply, Intl, 24V DC 3M, 2A...
  • Page 13 BACK VIEW FRONT VIEW 61500-2815 Rev A...
  • Page 14 2815 CONTROL VALVE ASSEMBLY CONTINUED Item No. Part No. Description ....1..62017 ....Seals and Spacers Kit, 2815 ....1 ..62050-01 ..End Plug / Bypass Piston Sub ....1..17470 ....Cable Guide Assy, Assembly 11.12” x 2.0”R ....1..19608-15... Disperser, Commerical ..

  • Page 15: Dlfc Insert Options

    FILTER CONVERSION KIT DLFC INSERT OPTIONS 62081 Rev A 1.7-7 8-25 30-45 50-70 Item No. Part No. Description 1....1 ..62081....Filter Plate Kit, 2815 Item No. Part No. Description ....1 ..43773 ....Housing, Internal DLFC KIT, WIRE HARNESS, DC ....1..

  • Page 16: 1720 Brine System Assembly

    1720 BRINE SYSTEM ASSEMBLY Item No. Part No. Description ....1 ..62020-00 ..Brine Valve Assy, No Flow Washer ..62020-10 ..Brine Valve Assy, 1.0 GPM ..62020-20 ..Brine Valve Assy, 2.0 GPM ..62020-50 ..Brine Valve Assy, 5.0 GPM ....1..

  • Page 17: Inch Stainless Steel Meter Assembly

    /2 INCH STAINLESS STEEL METER ASSEMBLY Item No. Part No. Description ....1 ..62049-01 ..Kit, 1” & 1-1/2” Meter, Std ..62049-02 ..Kit, 1” & 1-1/2” Meter, ....1..61933-10... Meter Assy, 1-1/2” NPT, Std, SS Inline, Paddle, Univ Cap ..

  • Page 18: Troubleshooting

    TROUBLESHOOTING Problem Cause Correction Water conditioner fails to Electrical service to unit has been Assure permanent electrical service (check fuse, regenerate. interrupted plug, pull chain, or switch) Timer is defective. Replace timer. Power failure. Reset time of day. Hard water. By-pass valve is open.

  • Page 19: Water Conditioner Flow Diagrams

    WATER CONDITIONER FLOW DIAGRAMS 4 Slow Rinse Position 1 Service Position Hard water enters unit at valve inlet, flows up into injector housing and down through nozzle and throat, around the piston, down through mineral, enters center tube through bottom distributor, flows up through center tube, around piston Hard water enters unit at valve inlet and flows down through and out through drain line.

  • Page 20: Dimensions

    DIMENSIONS 173.4 6.83 346.9 13.66 81.7 3.22 DRAIN OUTLET 336.2 13.24...
  • Page 21 DIMENSIONS continued 1 1/2-11.5 NPT 218.1 8.59 112.5 4.43 57.2 2.25 21.6 3.55 111.8 4.40 224.4 8.84 1 1/2-11.5 NPT RP 1 1/2-11 (BSP) OUTLET 233.1 9.18 81.3 3.20 1/8 NPT INLET TEST PORT 27.4 1/8 NPT OUTLET TEST PORT 1.08 TOP OF TANK 16.5...

  • Page 22: System #4

    DIMENSIONS continued 3.23 COMMUNICATION CABLE ENTRY POWER ENTRY INLET 1 1/2-11.5 NPT RP 1 1/2-11 (BSP) 82.8 3.26 SYSTEM #4 Typical Single Tank Installation with Optional Meter...
  • Page 23 TRANSFORMER THCAM TM - TIMER MOTOR VDM - VALVE DRIVE MOTOR SW1 - TIMER HOMING SWITCH SW2 - TIMER PROGRAM SWITCH HCAM SW3 - VALVE HOMING SWITCH SCAM SW4 - VALVE STEP SWITCH SW AUX - BRINE CAM AUXILIARY SWITCH (OPT) THCAM - TIMER HOMING CAM TPCAM - TIMER PROGRAM CAM HCAM - VALVE HOMING CAM...
  • Page 24 - 24 VDC OPTI BLACK BLUE BLUE N.C. SPDT DRY CONTACTS 5 AMP 30 VDC MAX. N.O. BLACK 10 AMP 250 VAC MAX 12 VDC REMOVE POWER PRESS AND HOLD FOR 30 SECONDS TO RESET PS1- 24VDC POWER SOURCE VDM- VALVE DRIVE MOTOR FM- FLOW METER...
  • Page 25 *WIRING DIAGRAMS ARE REFERENCE ONLY. ALL WIRING SHOULD BE DONE BY A CERTIFIED ELECTRICIAN AND MEET ALL ELECTRICAL CODES. OPTIONAL OPTIONAL REMOTE SIGNAL INTERLOCK START SWITCH (N.O.) SWITCH (N.O.) CLOSED CLOSED CONTACT CONTACT INITIATES PREVENTS 24 VDC LOCK REGENERATION REGENERATION START IF ENABLED IF ENABLED...

  • Page 26: Piston Assembly/Seal And Spacer Cartridge Replacement

    PISTON ASSEMBLY/SEAL AND SPACER 24. Restore water supply to valve (purging air). Cycle valve to backwash to purge the air from the system. Refer CARTRIDGE REPLACEMENT to startup instructions for more information about pressurizing the system. 1. Turn off water supply to valve. 25.

  • Page 27: Injector Replacement

    INJECTOR REPLACEMENT MOTOR DRIVE ASSEMBLY REPLACEMENT 1. Turn off water supply to valve. 2. Open/remove the powerhead assembly cover 1. Turn off water supply to valve. 3. Cycle valve to backwash position. Wait until there 2. Open/remove the powerhead assembly cover is no water flow at the drain to ensure the unit is 3.

  • Page 28: Water Treatment System Warranty

    FRAKCO, INC. will replace or repair the defective item. Replacement of a defective item will be at FRAKCO’S factory in Luverne, MN, and the purchaser must ship the defective item at its own expense to FRAKCO’S factory. Replacement items will be shipped by FRAKCO F.O.B.
