Operational Manual
Model:
Serial Number:
Install Date:
Installed By:
Service Phone:
Sold By:
Please read this manual carefully before proceeding with installation. Your failure to
follow any of these instructions or operating parameters may lead to personal injury
or damage to the equipment and/or personal property. Do not use this Iron Filter
system with water that is microbiologically unsafe or of unknown quality, without
adequate disinfection before or after the system. This water treatment system
contains replaceable treatment components critical for effective performance. It is
the user's responsibility to periodically test the product water to verify the system is
performing satisfactorily. Failure to properly maintain this water treatment system
Owner and
may cause a health risk.
Save this manual for future reference
Aqua Magic Pro Guardian Series
10.16.2024 SB
Advertisement
Related Manuals for Frakco AQUA MAGIC PRO
Summary of Contents for Frakco AQUA MAGIC PRO
- Page 1 Failure to properly maintain this water treatment system may cause a health risk. Save this manual for future reference Aqua Magic Pro Guardian Series 10.16.2024 SB...
- Page 2 Table of Contents Guardian General Specifications ............................ 3 Operating Pressures ..............................3 Operating Temperatures ............................3 Flow Rate ..................................3 Dimensions ................................. 3 Pre-Installation Check List ............................... 4 Start-Up Instructions ..............................4 Installer Display Settings..............................6 User Display Settings..............................7 Front Cover and Drive Assembly...........................
- Page 3 Guardian General Specifications Inlet/Outlet .........................1” Cycles ..........................3 Valve Material ......................Noryl© Operating Pressures Minimum/Maximum ..................40 - 80psi Optimal Range ....................40 - 60psi *Pump output must meet or exceed backwash rate. Operating Temperatures Minimum/Maximum ..................40° - 110°F Flow Rate Guardian 150 Series ..................5 - 9 gpm Guardian 250 Series ..................9 - 14 gpm Dimensions Drain Line .......................¾”...
- Page 4 Pre-Installation Check List (All electrical and plumbing should be done in accordance to all local codes) Guardian Series is acceptable for indoor use only Water Quality: Sand and sediment are often problems in rural water supplies. They may plug the filter and restrict water flow through the media bed. Well and/or pump problems affecting the operation of the filter and repairs are not covered under warranty.
- Page 5 Page 5...
- Page 6 Installer Display Settings STEP 1I - Press NEXT and ▲ simultaneously for 3 seconds. STEP 1I STEP 3I – Day Override: When volume capacity is set to “OFF”, sets the number of days between STEP 3I regenerations. When volume capacity is set to AUTO or to a number, sets the maximum number of days between regenerations.
- Page 7 User Display Settings General Operation When the system is operating, one of several displays may be shown. The displays normally rotate, however pressing NEXT will pause on the selected display for 5 minutes. Pressing NEXT will alternate between the displays. One of the displays is always the current time of day.
- Page 8 Set Time of Day The user can also set the time of day. Time of day should only need to be set if the battery has been depleted because of extended power outages or when daylight saving time begins or ends. If an extended power outage occurs, the time of day will flash on and off which indicates the time of day should be reset.
- Page 9 Front Cover and Drive Assembly Drawing No. Order No. Description Quantity V4441-01 COVER ASY V3107-01 MOTOR ASY V3002-A DRIVE BRACKET ASY V4461FB-BOARD THRU2 FB PCB REPLACE V3110 DRIVE REDUCING GEAR 12X36 V3109 DRIVE GEAR COVER V3186-06 POWER SUPPLY US 15VDC HOCP V3186AUS-05OD POWER SUPPLY AUS 15VDC VI OUTDOOR V3186EU-06...
- Page 10 Drive Cap Assembly, Downflow Piston, Upflow Piston, Regenerant Piston and Spacer Stack Assembly Drawing No. Order No. Description Quantity V3005-02 Spacer Stack Assembly V3004 Drive Cap ASY V3946 Refer to Programming and Cover Drawing Manual V3011* Piston DownflowASY V3174 Regenerant Piston V3135 O-ring 228 V3180...
- Page 11 Injector Cap, Injector Screen, Injector, Plug and O-Ring Drawing No. Order No. Description Quantity V3176 Injector Cap V3152 O-Ring 135 V3177-01 Injector Screen Cage V3010-1X Injector Asy (Specify Tank Size) Page 12...
- Page 12 Refill Control and Check Valve Drawing No. Order No. Description Quantity H4615 Elbow Locking Clip V4144 Elbow 3/8” Liquifit V3163 0-ring 019 NeoOV15 15 MM Check Valve Elbow 3/8 Liquifit Asy w/RFC V4144-01CV ABPUS1 Brine Screen with Tube Flow Proper check valve orientation allows for air to enter system during brine draw cycle.
- Page 13 Drain Line – 3/4” Drawing No. Order No. Description Quantity H4615 Elbow Locking Clip V3962 Drain Elbow ¾ Male V3163 O-ring 019 V3159-01 DLFC Retainer ASY One DLFC V3162-xxx DLFC Based Upon tank and media used must be used if ¾ fitting is used Water Flow Proper DLFC orientation...
- Page 14 Water Meter, Meter Plug and Mixing Valve Drawing No. Order No. Description Quantity V3151 Nut 1” QC V3003-05* Meter ASY V3118-01 Turbine ASY V3105 O-ring 215 V3003-01 Meter Plug ASY *Order number V3003 includes V3118-01 AM1 Turbine ASY and V3105 O-ring 215. THIS WATER METER SHOULD NOT BE USED AS THE PRIMARY MONITORING DEVICE FOR CRITICAL OR HEALTH EFFECT APPLICATIONS.
- Page 15 Bypass Valve Drawing No. Order No. Description Quantity V3151 Nut 1” Quick Connect V3150 Split Ring V3105 O-Ring 215 V3145 Bypass 1” Rotor V3146 Bypass Cap V3147 Bypass Handle V3148 Bypass Rotor Seal Retainer V3152 O-ring 135 V3155 O-ring 112 V3156 O-ring 214 (Not Shown) Order No.
- Page 16 Service Spanner Wrench (Order No. V3193-02) Although no tools are necessary to assemble or disassemble the valve, the WS1 wrench (shown in various positions on the valve) may be purchased to aid in assembly or disassembly. Loosens Injector And Bypass Caps Loosens Drive Cap Page 17...
- Page 17 Quantity Part Number Description CIOX-V1FBDTF CIOX Valve ENDT Distributor Tube EN104 * VT Vortech Mineral Tank EN1354 * VT Vortech Mineral Tank 1.5/2.5 Filter Media D1047 Air Blocker V3006 Bypass Assembly V3191-01CV Elbow Assembly with CV** V4144-01CV Brine Elbow with CV V3962 Drain Assembly *Black or natural color...
- Page 18 Troubleshooting Problem Cause Solution A. Transformer unplugged A. Connect to Power Blank or unreadable LCD B. Defective transformer B. Check to ensure 12 volt display motor, replace transformer C. No electric power at outlet C. Repair outlet or switch to working outlet D.
- Page 19 Upon receiving such notice and determining that the defect is covered by this warranty, FRAKCO, INC. will replace or repair the defective item. Replacement of a defective item will be at FRAKCO’S factory in Luverne, MN, and the purchaser must ship the defective item at its own expense to FRAKCO’S factory.
