Frakco AQUA MAGIC Plus 2900 Owner And Operational Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Owner and
Operational Manua
Model:
Serial Number:
Install Date:
Installed By:
Service Phone:
Sold By:
Please read this manual carefully before proceeding with installation. Your failure to
follow any of these instructions or operating parameters may lead to personal injury
or damage to the equipment and/or personal property. Do not use this water
treatment system with water that is microbiologically unsafe or of unknown quality,
without adequate disinfection before or after the system. This water treatment
system contains replaceable treatment components critical for effective
performance. It is the user's responsibility to periodically test the product water to
verify the system is performing satisfactorily. Failure to properly maintain this water
treatment system may cause a health risk.
Save this manual for future reference
l
Aqua Magic 2900
04.15.2024 SB

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AQUA MAGIC Plus 2900 and is the answer not in the manual?

Questions and answers

Related Manuals for Frakco AQUA MAGIC Plus 2900

Summary of Contents for Frakco AQUA MAGIC Plus 2900

  • Page 1 Owner and Operational Manua Model: Serial Number: Install Date: Installed By: Service Phone: Sold By: Please read this manual carefully before proceeding with installation. Your failure to follow any of these instructions or operating parameters may lead to personal injury or damage to the equipment and/or personal property.

  • Page 2: Table Of Contents

    Table of Contents Installation ................................. 3 Start-Up Instructions ..............................4 3200 Timer Setting Procedure ............................. 5 3210 & 3220 Timer Setting Procedure ........................... 5 3200, 3210, 3220, 3230 Regeneration Cycle Setting Procedure ..................6 3200 Time Clock Timer Assembly ..........................7 Continued ..................................

  • Page 3: Installation

    INSTALLATION a common line. 9. Make sure that the floor is clean beneath the salt storage Water Pressure tank and that it is level. A minimum of 20 pounds (1.4 bar) of water pressure is 10. Place approximately 1 inch (25 mm) of water above the grid required for regeneration valve to operate effectively.

  • Page 4: Start-Up Instructions

    INSTALLATION CONTINUED START-UP INSTRUCTIONS Meter Dome and Union Orientation The water softener should be installed with the inlet, outlet, and drain connections made in accordance with the Control valves outfitted with an electromechanical timer and manufacturer’s recommendations, and to meet applicable stainless steel water meter include a special male x female plumbing codes.

  • Page 5: 3200 Timer Setting Procedure

    3200 TIMER SETTING PROCEDURE How To Set Days On Which Water Conditioner Is To Regenerate (Figure 2) Rotate the skipper wheel until the number “1” is at the red pointer. Set the days that regeneration is to occur by sliding tabs on the skipper wheel outward to expose trip fingers.
  • Page 6 3210 & 3220 TIMER SETTING Timer Setting Procedure PROCEDURE CONTINUED How To Change The Length Of The Backwash Time The program wheel as shown in the drawing is in the service 3. The black center knob will make one revolution in the position.

  • Page 7: 3200 Time Clock Timer Assembly

    3200 TIME CLOCK TIMER ASSEMBLY 615023200 Rev A...
  • Page 8 3200 TIME CLOCK TIMER ASSEMBLY CONTINUED Item No. Part No. Description Item No. Part No. Description 1 ....1 ..13870 ....Housing, Timer, 3200 27 ....1 ..14381 ..... Skipper Wheel Assy, 12 Day 2 ....1 ..14265 ....Clip, Sping 1 ..

  • Page 9: 3210 Meter Delayed Timer Assembly

    3210 METER DELAYED TIMER ASSEMBLY 61502-3210 Rev A...
  • Page 10 3210 METER DELAYED TIMER ASSEMBLY CONTINUED Item No. Part No. Description Item No. Part No. Description 30 ....1 ..14198 ..... Label, Indicator 1 ....1 ..13870 ....Housing, Timer, 3200 31 ....1 ..15465 ..... Label, Caution 2 ....1 ..13802 ....Gear, Cycle Actuator 32 ....1 ..

  • Page 11: 3220 Meter Immediate Timer Assembly

    3220 METER IMMEDIATE TIMER ASSEMBLY 61502-3220 Rev B...
  • Page 12 3220 METER IMMEDIATE TIMER ASSEMBLY CONTINUED Item No. Part No. Description Item No. Part No. Description 31 ....1 ..40617.... Harness, 3220 1 ....1 ..13870 ....Housing, Timer 32 ....2 ..40422 ..... Nut, Wire, Tan 2 ....1 ..15431 ....Gear, Cycle Actuator, System #5 33 ....1 ..

  • Page 13: Upper Environmental Powerhead Assembly

    UPPER ENVIRONMENTAL POWERHEAD ASSEMBLY 61501-2900 Rev G...
  • Page 14 UPPER ENVIRONMENTAL POWERHEAD ASSEMBLY CONTINUED Item No. Part No. Description Item No. Part No. Description 25 ....1 ..19772 ..... Bracket, Terminal Block 1 ....1 ..18697-15 ..Backplate, Hinged 26 ....1 ..40174 ..... Terminal Block, Green/ 2 ....1 ......3200 Clock Timer Assembly Yellow Commercial, 809- .

  • Page 15: Lower Environmental Powerhead Assembly

    LOWER ENVIRONMENTAL POWERHEAD ASSEMBLY 19 9 61501-2900 Rev G...
  • Page 16 LOWER ENVIRONMENTAL POWERHEAD ASSEMBLY CONTINUED Item No. Part No. Description Item No. Part No. Description ..40408 ... Harness, Lower Drive, Syst 7, 1 ....1 ..18709 ....Backplate, Lower Duplex, Lag, Enviromental 2 ....2 ..11224 ....Screw, Slotted Hex Head ..

  • Page 17: Control Valve Assembly

    CONTROL VALVE ASSEMBLY 61500-2900 Rev F Downflow Upflow Item No. Part No. Description Item No. Part No. Description ..41428-09NP ... Valve Body, 2900S, MCHD, 1 ....1 ..41428-01 ..Valve Body, 2900s, Machd, NPT, NP, U.S. Tap, Soft NPT U.S. Tap ADAPT, Top Coll ..
  • Page 18 CONTROL VALVE ASSEMBLY CONTINUED Item No. Part No. Description Item No. Part No. Description 4 ....6 ..11451 ....Spacer, 12 Hole ..61545 ... Piston Assy, 2900S, Upflow, Upper ..16589 .... Spacer, Hot Water ..61545-01 ..Piston Assy, 2900S, 5 ....1 ..
  • Page 19 CONTROL VALVE ASSEMBLY CONTINUED Item No. Part No. Description ..60721-30 ..DLFC, 1-inch F x 1-inch F, Item No. Part No. Description NPTF, 3.0 gpm ..60366-45 ..DLFC, 1-inch F x 3/4-inch ..60721-35 ..DLFC, 1-inch F x 1-inch F, F, NPT, 4.5 gpm NPTF, 3.5 gpm ..

  • Page 20: Control Valve Side Mount Adapter

    CONTROL VALVE SIDE MOUNT ADAPTER 61415 Rev B Item No. Part No. Description 1 ....1 ..40316 ....Adapter, Sidemount 2 ....1 ..40372 ....O-ring - 142 3 ....1 ..40368 ....O-ring - 160, Sidemount, Flange 4 ....1 ..40310 ....Base, 2850/2900/3930, Rotating 5 ....7 ..

  • Page 21: 1600 Series Brine System

    1600 SERIES BRINE SYSTEM 60029 Rev C Item No. Part No. Description Item No. Part No. Description 17 ....1 ..11893 ..... Cap, Injector, SS 1 ....2 ..10332 ..... Fitting, Insert, 3/8 18 ....1 ..10229 ..... Gasket, Injector Cap, 1600 2 ....1 ..
  • Page 22 1600 SERIES BRINE SYSTEM CONTINUED Item No. Part No. Description 25 ..... 60480-01 ..Injector Assy, 1600, #1, Item No. Part No. Description Plastic 21 ....1 ..10914-000 ..Throat, Injector #000, ..60480-02 ..Injector Assy, 1600, #2, Brown Plastic ..

  • Page 23: 1650 Brine System Assembly

    1650 BRINE SYSTEM ASSEMBLY 60011 Rev D Item No. Part No. Description Item No. Part No. Description Plastic 1 ....1 ..10329 ..... Fitting, Tube, 3/8 Nut, Brass 1 ..60010-100 ..BLFC, 1650, 1.0 GPM, Plastic 2 ....1 ..10330 ..... Fitting, Sleeve, 3/8 Celcon 15 ....1 ..
  • Page 24 1650 BRINE SYSTEM ASSEMBLY CONTINUED Item No. Part No. Description Item No. Part No. Description ..12973-3 ..Nozzle, Injector #3, PVC, 27 ....1 ..12550 ..... Quad Ring -009 Grey 1 ..12550-01 ..Quad Ring -009 560CD ..12973-4 ..Nozzle, Injector #4, PVC, 28 ....1 ..

  • Page 25: 1700 Brine System Assembly

    1700 BRINE SYSTEM ASSEMBLY 60034 Rev D...
  • Page 26 1700 BRINE SYSTEM ASSEMBLY CONTINUED Item No. Part No. Description Item No. Part No. Description ..14801-05c ..Nozzle, Injector, #5c, White 1 ....1 ..14792 ....Plug, End, Brine Valve ..14801-06c ..Nozzle, Injector, #6c, Red 2 ....1 ..13201 ....Quad Ring, -020 25 ....1 ..

  • Page 27: 1710 Brine System Assembly

    1710 BRINE SYSTEM ASSEMBLY 60604 Rev F Item No. Part No. Description Item No. Part No. Description 22 ..... 60605-00 ..Brine Valve, 1710, 2750, Blank 1 ....1 ..41202 ..... Brine Valve, 1700, Plastic, ..60605-10 ..Brine Valve, 1710, 2750, 1.0 gpm 2 ....1 ..

  • Page 28: 2-Inch Brass Meter Assembly

    2-INCH BRASS METER ASSEMBLY Item No. Part No. Description Item No. Part No. Description 11 ....1 ..14680 ..... Flow Straightener 1 ....1 ..14456 ..... Body, Meter, 2-inch ..14456-20 ..Body, Meter, 2-inch, BSP, 12 ....1 ..14569 ..... Nut, 2900 Meter Metric 13 ..........

  • Page 29: 2-Inch Stainless Steel Meter Assembly

    2-INCH STAINLESS STEEL METER ASSEMBLY IMPORTANT: For valves equipped with electromechanical timers and stainless steel meters, refer to the Meter Dome and Union Orientation section. Item No. Part No. Description Item No. Part No. Description 1 ....1 ..62048-01 ..Service Kit, 2 inch Meter, Not Shown (optional) Standard Range 1 ..

  • Page 30: 2-Inch Plastic Meter Assembly

    2-INCH PLASTIC METER ASSEMBLY 60621 REV 60621 Rev D Item No. Part No. Description Item No. Part No. Description 12 ....1 ..14680 ..... Flow Straightener 1 ....1 ..17689....Body, Meter, 2-inch Plastic w/Impeller Shaft Seat 13 ....2 ..17988 ..... Nut, 2-inch Meter 2 ....1 ..

  • Page 31: 1600 Service Valve Operator (New Style)

    1600 SERVICE VALVE OPERATOR (NEW STYLE) 60150 Rev A Item No. Part No. Description Item No. Part No. Description 1 ....1 ..11749 ..... Guide, Brine Valve Stem 14 ....2 ..15415 ..... Fitting, Insert, 1/2-inch Tube 2 ....1 ..10250 ..... Ring, Retaining 15a ..1 ..

  • Page 32: Troubleshooting

    TROUBLESHOOTING Problem Cause Correction Water conditioner fails to Electrical service to unit has been Assure permanent electrical service (check fuse, regenerate. interrupted plug, pull chain, or switch) Timer is defective. Replace timer. Power failure. Reset time of day. Hard water. By-pass valve is open.
  • Page 33 WATER CONDITIONER FLOW DIAGRAMS - DOWNFLOW 1 Service Position 4 Slow Rinse Position 2 Backwash Position 5 Rapid Rinse 3 Brine Position 6 Brine Tank Refill Position 61500-2900 UPFLW Rev F...

  • Page 34: Water Conditioner Flow Diagrams - Upflow

    WATER CONDITIONER FLOW DIAGRAMS - UPFLOW 1 Service Position 4 Back Wash Position 2 Brine Position 5 Rapid Rinse 3 Slow Rinse Position 6 Brine Tank Fill Position 61500-2900 UPFLW Rev F...

  • Page 35: Environmental Backplate Dimensions

    ENVIRONMENTAL BACKPLATE DIMENSIONS 61500-2900LNE Rev B...

  • Page 36: System #4

    SYSTEM #4 Typical Single Tank Installation with Optional Meter SYSTEM #5 INTERLOCK Typical Twin Tank Installation with Optional Meter Interlock and No Hard Water Bypass...

  • Page 37: System #6 & #7

    SYSTEM #6 & #7 Twin Series Regeneration Installation with a Remote Meter Twin Alternator Installation NOTE: On System 7, the power cord is on Unit 2. NOTE: System 7 can run with either one or two brine tanks. Two brine tanks should be used if regeneration is less than 4 hours.

  • Page 38: System #4 Wiring

    SYSTEM #4 WIRING Single Valve Regeneration Immediate and Delayed Valve Wiring...
  • Page 39 SYSTEM #4 WIRING CONTINUED With Remote Starter Valve Wiring...

  • Page 40: System #5 Wiring

    SYSTEM #5 WIRING Interlocked Regeneration Valve Wiring 18685-01 Rev D 18685-02 Rev D...

  • Page 41: System #6 Wiring

    SYSTEM #6 WIRING Series Regeneration Valve Wiring 18686-01 Rev E 18686-02 Rev E...

  • Page 42: System #7 Wiring

    SYSTEM #7 WIRING Alternating Regeneration Valve Wiring 18687-01 Rev E 18687-02 Rev E...
  • Page 43 SYSTEM #7 WIRING CONTINUED...

  • Page 44: Water Treatment System Warranty

    Upon receiving such notice and determining that the defect is covered by this warranty, FRAKCO, INC. will replace or repair the defective item. Replacement of a defective item will be at FRAKCO’S factory in Luverne, MN, and the purchaser must ship the defective item at its own expense to FRAKCO’S factory.
