HC65 V2 USER MANUAL
Features:
Triple output full metal USB-C rechargeable headlamp
Utilizes a primary Luminus SST-40-W LED with a max output of 1,750 lumens
Equipped with a high CRI auxiliary white light (CRI≥90, Color Temperature: 4500K) and an
auxiliary red light
Unibody TIR lens system reflects uniform and soft light
A max beam intensity of 7,000cd and a max throw of 165 meters
Highly efficient constant current circuit provides max runtime of 800 hours
Built-in intelligent Li-ion battery charging circuit with a USB-C charging port
180° adjustable tilt angle for various lighting needs
The power indicator beneath the power button can indicate the remaining battery power (Patent
No. ZL201220057767.4)
The power indicator can display the battery voltage (±0.1V)
Integrated Advanced Temperature Regulation (Patent No. ZL201510534543.6)
Constructed from aero grade aluminum alloy
HA III military grade hard-anodized finish
Waterproof and dustproof rating in accordance with IP68 (2 meters submersible)
Impact resistant to 2 meters
Specifications
Dimensions: 90.8mm × 34.75mm × 26.95mm (3.57" × 1.37" × 1.06")
Weight: 114.5g (4.04oz) (Bracket and Headband Included, Battery Not Included)
65.5g (2.31oz) (Bracket, Headband and Battery Not Included)
Accessories
NITECORE 18650 Rechargeable Li-ion Battery (NL1835HP 3,500mAh), Spare O-ring, USB-C Charging Cable,
Headband, Bracket
Battery Options
NITECORE NL1835HP (3,500mAh)
Button Topped 18650 Rechargeable Li-
ion Battery (Discharge Current Over
8A)
Primary Lithium Battery
Rechargeable Li-ion Battery
Flat Topped 18650 Battery
Button Topped 18650 Rechargeable Li-
ion Battery (Discharge Current Below
8A)
Note: DO NOT attempt to use the HC65 V2 to charge CR123/RCR123 batteries.
Technical Data
FL1
STANDARD
TURBO
HIGH
PRIMARY WHITE LIGHT
MID
LOW
Type
Nominal
Voltage
18650
3.6V
18650
3.6V/3.7V
CR123
3V
RCR123
3.6V/3.7V
18650
─
18650
─
AUXILIARY RED LIGHT
ULTRALOW
HIGH
LOW
Compatibility
Y (Recommended)
Y (Compatible)
Y (Compatible)
Y (Compatible)
N (Incompatible)
N (Incompatible)
AUXILIARY
WHITE
FLASHING
BEACON
SOS
Advertisement
Related Manuals for Nitecore HC65 V2
Summary of Contents for Nitecore HC65 V2
- Page 1 N (Incompatible) Button Topped 18650 Rechargeable Li- 18650 ─ N (Incompatible) ion Battery (Discharge Current Below Note: DO NOT attempt to use the HC65 V2 to charge CR123/RCR123 batteries. Technical Data PRIMARY WHITE LIGHT AUXILIARY RED LIGHT AUXILIARY BEACON STANDARD...
- Page 2 Battery Charging The HC65 V2 is equipped with an intelligent charging system. As illustrated, unscrew the charging port cap after inserting the battery and tightening the battery cap, use the USB cable to connect an external power supply (e.g.
- Page 3 Off: When the light is on, press and hold the Power Button for 1 second to turn it off. Note: The HC65 V2 has a memory function to memorize ULTRALOW, LOW or MID of the primary white light only.
- Page 4 Note: When using two CR123/RCR123 in series, the indicator will show the average voltage between the two batteries. ATR (Advanced Temperature Regulation) The integrated ATR technology regulates the output of the HC65 V2 according to the working condition and ambient environment to maintain the optimal performance. Changing Batteries The batteries should be replaced when the output appears to be dim or the headlamp becomes unresponsive due to low power.
