Summary of Contents for Trilux LiveLink SwarmSens

Page 1 LIVELINK SWARMSENS...
Page 2: Table Of Contents
TABLE OF CONTENTS TABLE OF CONTENTS 1 INTRODUCTION ....................3 SAFETY INFORMATION ..........................3 BASIC FUNCTIONS ............................3 SYSTEM OVERVIEW ............................4 2 SYSTEM COMPONENTS ...................5 CONTROLLER .............................. 5 PRACTICAL TIPS FOR POSITIONING ......................5 PUSH-BUTTON ............................6 3 FUNCTIONS AND COMMISSIONING ..............7 COMMISSIONING OPTIONS ........................
Page 3: Introduction
• Work on electrical equipment may only be carried out while dis- • LiveLink SwarmSens is not intended for applications other than connected from the power supply. those listed here. Other applications are considered improper. If LiveLink is used improperly, safe operation is not guaranteed.
Page 4: System Overview
INTRODUCTION SYSTEM OVERVIEW TRILUX light management LiveLink SwarmSens is a simple light man- ther via a DIP switch on the respective luminaires or via the LiveLink agement system that allows radio-controlled luminaires (identified by SwarmSens app. In addition, a push-button can be integrated for man- “+DMM”...
Page 5: System Components
“+DMM”, receiver luminaires by the designation “+DMR”. Technical data such as IP pro- tection and impact resistance are then determined in each case by the LiveLink SwarmSens Master Controller luminaire. Technical data...
Page 6: Push-Button
LiveLink SwarmSens luminaires. The radio push-buttons are integrated into the luminaire group via QR code scan – in the LiveLink SwarmSens app. One radio push-button can be integrated into a luminaire group for each sensor luminaire. Mounting is by means of an adhesive pad or screws.
Page 7: Functions And Commissioning
+DMR 3.1.1 CONFIGURATION ON THE LUMINAIRE The LiveLink SwarmSens system is flexible in its configuration. It can be configured via DIP switch and rotary potentiometer on the luminaire or via app.For manual configuration, sensor and grouping settings can be made on a sensor luminaire, using the rotary potentiometers (SW1–...
Page 8: Overview
LiveLink SwarmSens serves for configuring luminaire groups, sensor Note: Absc functions, basic lighting, cluster function and push-buttons. The re- Before opening the LiveLink SwarmSens app, make sure that the Blue- • HELLIGKEIT TESTEN: Solange auf die Testfunktion gedrückt wird Helligkeitswert eingestellt. Nach Loslassen der Testfun eingestellt.
Page 9 FUNCTIONS AND COMMISSIONING Login After starting the app, a screen opens in which the password must be entered in the “Current PW” field. The password per factory setting is: livelink. If necessary, a new password can be stored. The entries must be confirmed by tapping the "OK"...
Page 10 FUNCTIONS AND COMMISSIONING Luminaire menu By selecting one of the detected luminaires the luminaire menu opens, in which the following information and settings can be found: • Base information • Basic options • Sensors • Test brightness (my light) • Test my groups (blink) Base information This section lists the basic information about the luminare.
Page 11 FUNCTIONS AND COMMISSIONING Test brightness (“Helligkeit testen”) In this area, the set dimming values for four different scenarios are indicated in percent: • Movement ON (light intensity of the luminaire group when motion is detected) • Swarm Neighbour ON (light intensity of the neighbouring group) •...
Page 12: Functions And Settings
Die Gruppenzugehörigkeit der Module kann über den DIP Schalter SW 4 eingestellt werden. Die einstellbaren Werte werden in Tabelle 4 und Tabelle 5 gezeigt. The group can be assigned via DIP switches 3–8 (binary-coded, see fol- LIVELINK SWARMSENS lowing table). Group listing - binary coding: 8.4.1 Master...
Page 13: Settings In The App
FUNCTIONS AND COMMISSIONING 3.2.1.2 SETTINGS IN THE APP The group can be assigned in the settings menu (“EINSTELLUNGEN”) of the luminaire. My group By tapping the grey field in the “My Group” area, the luminaire can be assigned to a group by selecting the desired group number from the pop-up list (up to 255 groups).
Page 14: Setting The Motion Detection Sensitivity
FUNCTIONS AND COMMISSIONING Sensor The delay time can be set in the “Sensor” area: • Motion Sensor Switch Off Time Sets the overrun time in the range of 30 sec up to 60 min, after which the light switches off after last sensor detection. •...
Page 15: Setting The Light Level When Motion Is Detected
Only if this is not sufficient, the basic lighting is switched on. In the following, the lighting is briefly switched off every two hours to meas- The basic light can be configured in the LiveLink SwarmSens system ure the ambient brightness again. The basic lighting is subsequently via two setting options: switched on again only if the ambient brightness is insufficient.
Page 16: Settings On The Luminaire
FUNCTIONS AND COMMISSIONING Projekt Doc-Titel Document No. Autolight – DIP- SLM-C-PS/DI/BT/X-008 -009-A DB20191001 Mesh Gruppeneinstellung 3.2.5.1 SETTINGS ON THE LUMINAIRE Die Gruppenzugehörigkeit der Module kann über den DIP Schalter SW 4 eingestellt werden. Die einstellbaren Werte werden in Tabelle 4 und Tabelle 5 gezeigt. DIP switch (switch 2) Activating the function, with a preset value of 10% (only available for the sensor luminaires.
Page 17: Settings On The Luminaire
After the set overrun time, the groups switch off again. the LiveLink SwarmSens app, not only the luminaire groups of the sen- This function can be used to illuminate the road or walkway ahead of sor luminaire switch on when motion is detected, but also the assigned the movement of vehicles or people.
Page 18: Settings In The App
FUNCTIONS AND COMMISSIONING 3.2.7.1 SETTINGS IN THE APP This setting can only be made in the settings menu (“EINSTELLUN- GEN” of the luminaire in the Swarmsens app. Swarm Neighbour Group By tapping the gray fields, up to four luminaire groups can be selected in the “Swarm Neighbour Group”...
Page 19: Settings In The App
• switch off for at least 5 s & switch on for a maximum of 3 s 3.2.10 FURTHER SETTING OPTIONS IN THE APP The following settings and functions are available exclusively in the app 3.2.10.1 SAVE TEMPLATE This function can be configured in the settings menu of the luminaire in the LiveLink SwarmSens app.
Page 20: Dip Switch Mode
QR code scan. 3.2.10.2 DIP SWITCH MODE This function can be configured in the settings menu of the luminaire in the LiveLink SwarmSens app. Mode In the MODE area, the following modes can be activated or deactivated by pressing the respective slider: •...
Page 21 FUNCTIONS AND COMMISSIONING Add radio push-button By tapping the QR code symbol in the “Add Radio Button” area, the cam- era opens and the QR code on the back of the desired radio push-button can be scanned. Switch-off time By tapping on the time in the gray box in the “Switch-Off Timeout” area, a pop-up list opens in which the desired switch-off time can be se- lected.
Page 22: Update
FUNCTIONS AND COMMISSIONING 3.2.10.4 UPDATE This function can be configured in the settings menu in the LiveLink SwarmSens app. Update Tapping the UPDATE button takes you to the firmware menu. Note: If the latest firmware version is already installed, the UPDATE button is not displayed! Install now The firmware menu displays both the installed version and the new ver-...
Page 23: Qr Code
FUNCTIONS AND COMMISSIONING Complete update Once the update is 100% complete, the process can be finished by tap- ping the “OK” button. 3.2.10.5 QR CODE This function can be configured in the settings menu in the LiveLink SwarmSens app. Generate QR code for a luminaire By tapping the printer icon in the luminaire menu, a QR code can be generated for the respective luminaire.
Page 24: Test Mode
FUNCTIONS AND COMMISSIONING Print QR code By tapping the “Print” button, the generated QR code can be printed. Note: Supported printers are: • Brother QL-820NWB • Brother Print Service Plugin 3.2.10.6 TEST MODE The Test Mode can be helpful during commissioning. By pressing the BWM Reset button, all detected movements are reset and the lumi- naires are switched off.
Page 25 TRILUX GmbH & Co. KG Postfach 1960 · D-59753 Arnsberg Phone +49 (0) 29 32 301-0 Fax +49 (0) 29 32 301-375 info@trilux.de · www.trilux.de...
