Summary of Contents for Total TH115526
- Page 1 ROTARY HAMMER TH115526，TH115526S，TH115526-4，TH115526-6， TH115526-7，TH115526-8，TH115526-9，UTH115526 TOTAL TOOLS WORLD SCAN FOR VIDEO 1500W 丨画画...
- Page 2 The symbols in instruction manual and the label on the tool 回 Double insulated for additional protection. © Read the instruction manual before using. C € CE conformity. ® Wear safety glasses, hearing protection and dust mask. Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist.
- Page 3 GENERAL POWER TOOL SAFETY WARNINGS WARNING Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference. The term "power tool" in the warnings refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool.
- Page 4 a residual current device (RCD) protected supply. Use of an RCD reduces the risk of electric shock. Personal safety a) Stay alert, watch what you are doing and use common sense when operating a power tool. Do not use a power tool while you are tired or under the influence of drugs，alcohol or medication.
- Page 5 and must be repaired. c) Disconnect the plug from the power source and/or the battery pack from the power tool before making any adjustments, changing accessories， or storing power tools. Such preventive safety measures reduce the risk of starting the power tool accidentally. d) Store idle power tools out of the reach of children and do not allow persons unfamiliar with the power tool or these instructions to operate the power tool.
-
Page 6: Residual Risks
Residual risks Even when the power tool is used as prescribed it is not possible to eliminate all residual risk factors. The following hazards may arise in connection with the power tool’s construction and design: Health defects resulting from vibration emission if the power tool is being used over longer period of time or not adequately managed and properly maintained. - Page 8 Drill bit ⑴ Part of SDS max shank Hammer rod protector Flex Sheath ⑷ Auxiliary handle Speed Adjuster Knob Power -ON Indicator Service Indicator Function Knob (10) Cover Contents General Power Tool Safety Warnings Special requirements for rotary hammer Safety Instructions Applications Technical Data Accessories...
-
Page 9: Technical Data
*Note type designation on the device, differences might depend on area. Wear hearing protection while operating the power tool. The declared vibration total value has been measured in accordance with a standard test method and may be used for comparing one tool with another. -
Page 10: Prior To Operation
(2) Auxiliary handle Standard accessories are subject to change without notice. Prior To Operation ■■ 'Read the ENTIRE IMPORTANT SAFETY INFORMATION section at the beginning of this manual including all text under subheadings therein before set up use of this products. 1. -
Page 11: Operation
a maximum speed with the number of 305 rotations per minute and 2760 times of blow per minute. CAUTIONiDo not adjust the speed adjuster knob during operation. Doing so can result in injury because the Rotary Hammer must be held by only one hand, disabling the steady control of the Rotary Hammer. 4. -
Page 12: Maintenance And Inspection
(2) Mount the drill bit. (3) Pull the trigger switch3 after applying the drill bit tip to the drilling position Fig.6 (4) Pushing the rotary hammer forcibly is not necessary at all. Pushing slightly so that drill dust comes out gradually is sufficient. - Page 13 CAUTION: Repair, modification and inspection of TOTAL Power tools must be must be carried out by a TOTAL Authorized Service Center. In the operation and maintenance of power tools, the safety regulations and standards prescribed in each country must be observed.
- Page 14 ， ， ， ， ， TH115526 TH115526S TH115526-4 TH115526-6 TH115526-7. TH115526-8 ， TH115526-9 UTH115526 Exploded view...
-
Page 15: Part Description
， ， ， ， TH115526 TH115526S TH115526-4 TH115526-6 TH115526-7. ， ， TH115526-8 TH115526-9 UTH115526 Spare part list Part Description NO. Part Description Hammer rod protector Shock absorption ring Flex Sheath Sliding sleeve 028 Steel Wire Block Ring Sliding sleeve Spring... - Page 16 TH115526,TH115526S,TH115526 -4,TH115526-6,TH115526-7, TH115526-8,TH115526-9,UTH115526 Spare part list NO. Part Description NO. Part Description Airproof Ring Switch 2 cover Selector fork Speed Adjuster 220-240V Torsion spring Indicator Lifting jack Machine Screw ST5.5^25 Eccentric gear subassembl 06 Flat Washer(06.4x018x1.6) Needle Bearing 012^019^12 Side Handle Ass’y Base...
- Page 17 ROTARY HAMMER www.totalbusiness.com TOTAL TOOLS PTE. LTD. ， 45 Songbei Road，Suzhou Industrial Park China. MADE IN CHINA ， T1221.V01 1500W...
