Stamina 35-1442C Owner's Manual

Stamina 35-1442C Owner's Manual

Water rower
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Product May Vary Slightly From Pictured.
CAUTION:
Weight on this product should not exceed 300 lbs.
This Product is Distributed Exclusively by
2040 N Alliance Ave, Springfield, MO 65803
www.staminaproducts.com
Customer Care
1 (800) 375-7520
Owner's
Manual
WARNING
!
Exercise can present a
h e a l t h r i s k . C o n s u l t a
physician before beginning
any exercise program with
this equipment. If you feel
faint or dizzy, immediately
d i s c o n t i n u e u s e o f t h i s
equipment. Serious bodily
i n j u r y c a n o c c u r i f t h i s
equipment is not assembled
and used correctly. Serious
bodily injury can also occur
if all instructions are not
followed. Keep others and
pets away from equipment
when in use. Always make
sure all bolts and nuts are
securely tightened prior to
each use. Follow all safety
instructions in this manual.
When calling for parts or
service, please specify
the following numbers :
Model#: 35-1442C
S/N: _____________
STAMINA PRODUCTS
MADE IN CHINA
©
2021 Stamina Products, Inc.
2021, 05

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 35-1442C and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Stamina 35-1442C

Summary of Contents for Stamina 35-1442C

  • Page 1 Weight on this product should not exceed 300 lbs. This Product is Distributed Exclusively by STAMINA PRODUCTS MADE IN CHINA 2040 N Alliance Ave, Springfield, MO 65803 Customer Care © 2021 Stamina Products, Inc. 1 (800) 375-7520 2021, 05 www.staminaproducts.com...
  • Page 2 Quickstart Guide Smart Audio Workouts for Your Rower Go to the App Store on your device or scan the QR Code for quick access. Download the app and get moving! Assembly video included in app. Apple, the Apple logo, iPhone, and iPod touch are trademarks of Apple Inc., registered in the U.S. and other countries. App Store is a service mark of Apple Inc., registered in the U.S.

  • Page 3: Table Of Contents

    4. We recommend that two people be available for assembly of this product. 5. Keep children away from the STAMINA│X Water Rower. Do not allow children to use or play on the STAMINA│X Water Rower. Keep children and pets away from the STAMINA│X Water Rower when it is in use.

  • Page 4: Need Help

    1 (800) 375-7520 customer.care@staminaproducts.com Hi! From all of us here at Stamina Products, thank you for your purchase. We know that you have big fitness goals in mind and we are here to help you along. Call us, email us, or send us a message on Facebook. Be sure to contact us if you have any questions on your new product.

  • Page 5: Before You Begin

    STAMINA│X Water Rower. exercise to make you feel better, look better, and Providing you with a quality product is Stamina's enjoy life to its fullest. top priority. However, sometimes there could be a It's a proven fact that a regular exercise program missing or incorrectly sized part.

  • Page 6: Equipment Warning, Caution & Notice Labels

    EQUIPMENT WARNING, CAUTION & NOTICE LABELS This chart is provided to help identify the warning, caution, and notice labels on the STAMINA│X Water Rower. Please take a moment to familiarize yourself with all of the warning, caution, and notice labels.

  • Page 7: Hardware Identification Chart

    HARDWARE IDENTIFICATION CHART This chart is provided to help identify the hardware used in the assembly process. Place the washers or the ends of the bolts or screws on the circles to check for the correct diameter. Use the small scale to check the length of the bolts and screws.

  • Page 8: Assembly Instructions

    ASSEMBLY INSTRUCTIONS Place all parts from the box in a cleared area and position them on the floor in front of you. Remove all packing materials from your area and place them back into the box. Do not dispose of the packing materials until assembly is completed.
  • Page 9 ASSEMBLY INSTRUCTIONS STEP 3 There is an “L” decal on the left PEDAL CAP(43L), and an “R” decal on the right PEDAL CAP(43R). Insert the PEDAL SHAFT(12) through the tube located on the FRONT SUPPORT(2). Slide the right PEDAL CAP(43R) onto the right side of the PEDAL SHAFT(12) and make it ride on the Rack on the FRONT SUPPORT(2).
  • Page 10 ASSEMBLY INSTRUCTIONS STEP 4 Attach the SEAT(39) to the SEAT CARRIAGE(10) with BUTTON HEAD BOLTS(M6x1x15mm)(75). STEP 5 Attach the HANDLEBAR HOLDER(45) to the UPRIGHT(4) with BUTTON HEAD BOLTS(M6x1x15mm) (75). Place the HANDLEBAR(5) onto the HANDLEBAR HOLDER(45). STEP 6 Install two AAA batteries into the METER(54), the batteries are not included. See page 14 for detailed battery installation instructions.

  • Page 11: Operational Instructions

    SENSOR STRAP(99) monitor your heartbeat, and the adjustable ELASTIC SENSOR STRAP(99) holds the transmitter in place. The receiver built into the STAMINA│X Water Rower picks up your heart rate from the HEART RATE TRANSMITTER(98) and displays it on the monitor during your workout.
  • Page 12 Do not stretch the heart rate sensor electrodes. NOTE: The frequency of the receiver built into the STAMINA│X Water Rower is 5 kHz. All compatible heart rate transmitters from other companies will work with the STAMINA│X Water Rower.

  • Page 13: Function Buttons

    OPERATIONAL INSTRUCTIONS USING THE FITNESS METER POWER ON: Move the handlebar or press any button. POWER OFF: Automatically shuts off after 4 minutes of inactivity. SCAN FUNCTION BUTTONS : MODE : In the setting mode, press and release to select each function for preset target values for COUNT, DISTANCE, TIME, and CALORIES.
  • Page 14 OPERATIONAL INSTRUCTIONS PRESET VALUES OPERATION: You can pull on the HANDLEBAR(5) to power on the meter and workout with the meter directly. Or, you can preset the function values for counting down. Press and release the MODE button until “SCAN” does not appear on display, the meter will enter setting mode.
  • Page 15 OPERATIONAL INSTRUCTIONS HOW TO FILL AND EMPTY THE TANK 1. Remove the FILL PLUG(21) from the UPPER TANK(18). 2. To fill with water, refer to illustration C. Place the FUNNEL(95) into the tank. Use a water cup, or the SYPHON PUMP(94) and a bucket to fill the tank. Use Water Level Gauge on the side of tank to measure volume of water in tank to the desired level.

  • Page 16: Storage

    2. To avoid damage to the electronics, remove the batteries before storing the STAMINA│X Water Rower for one year or more. 3. Move the STAMINA│X Water Rower with the moving wheels on the back of the MAIN FRAME(1). Grasp the stabilizer of the FRONT SUPPORT(2) to move the STAMINA│X Water Rower. Do not use the SEAT(39) to move the STAMINA│X Water Rower.

  • Page 17: Trouble Shooting Guide

    TROUBLE SHOOTING GUIDE STRAP REPLACEMENT Over time, the STRAP(50) may become frayed or worn. If your STAMINA│X Water Rower is within the 90 day warranty, a replacement STRAP(50) is available by contacting Stamina Customer Care at customer.care@staminaproducts.com. If your STAMINA│X Water Rower is not under warranty, you can purchase a replacement STRAP(50).
  • Page 18 TROUBLE SHOOTING GUIDE Slowly pull out the current Strap(50). Carefully Run the new Strap(50) through the Upright(4) rotate the Strap/Bungee Pulley(27) to release the and Main Frame(1), turn it 90 degrees on the Strap(50). Idler Roller(32), then attach to the Strap/Bungee Pulley(27) with Bolt(118).
  • Page 19 TROUBLE SHOOTING GUIDE Attach the Mounting Bracket(7) back to the Tank Attach the Rail(3) and Upright(4) back the the Brace(8) with Bolts(62). Frame with Bolts(70, 72, and 65). Cable Ties Run the Bungee Cord(51) through the Bungee Pulleys(37). Secure the Bungee Cord(51) to the Frame with the Cable Ties as illustrated.
  • Page 20 TROUBLE SHOOTING GUIDE BUNGEE CORD REPLACEMENT Over time, the BUNGEE CORD(51) may become frayed or worn. If your STAMINA│X Water Rower is within the 90 day warranty, a replacement BUNGEE CORD(51) is available by contacting Stamina Customer Care at customer.care@staminaproducts.com. If your STAMINA│X Water Rower is not under warranty, you can purchase a replacement BUNGEE CORD(51).
  • Page 21 TROUBLE SHOOTING GUIDE Run the new Bungee Cord(51) through the Strap/ Place the Upright(4) on the Main Frame(1) as Bungee Pulley(27), and pull the Bungee Cord(51) illustrated. Rotate the Strap/Bungee Pulley(27) to the end. enough to place the Handlebar(5) up against the Strap Pulley(31).

  • Page 22: Conditioning Guidelines

    CONDITIONING GUIDELINES How you begin your exercise program depends on your physical condition. If you have been inactive for several years or are severely overweight, start slowly and increase your workout time gradually. Increase your workout intensity gradually by monitoring your heart rate while you exercise. Remember to follow these essentials: Have your doctor review your training and diet programs.

  • Page 23: Warm-Up And Cool-Down

    WARM-UP and COOL-DOWN Warm-Up The purpose of warming up is to prepare your body for exercise and to minimize injuries. Warm up for two to five minutes before strength training or aerobic exercising. Perform activities that raise your heart rate and warm the working muscles. Activities may include brisk walking, jogging, jumping jacks, jump rope, and running in place Stretching Stretching while your muscles are warm after a proper warm-up and again after your...

  • Page 24: Product Parts Drawing

    PRODUCT PARTS DRAWING FRONT BACK...

  • Page 25: Parts List

    PARTS LIST PART# PART NAME Main Frame Front Support Rail Upright Handlebar Meter Plate Mounting Bracket Tank Brace Impeller Seat Carriage Sensor Bracket Pedal Shaft Rail Shaft Idle Roller Spacer Roller Long Spacer Roller Short Spacer Strap Pulley Spacer Upper Tank Lower Tank Rubber Ring Seal Fill Plug...
  • Page 26 PARTS LIST PART# PART NAME Bearing (608zz) Bolt, Flat Socket Head (M6 x 1 x 10mm) Bolt, Button Head (M10 x 1.5 x 115mm) Bolt, Button Head (M10 x 1.5 x 105mm) Bolt, Button Head (M10 x 1.5 x 55mm) Bearing Spacer Bolt, Button Head (M8 x 1.25 x 135mm) Bolt, Button Head (M8 x 1.25 x 110mm)

  • Page 27: Limited Warranty

    To implement this limited warranty, send a written notice stating your name, date, and place of purchase and a brief description of the defect along with your receipt to Stamina Products, Inc. 2040 N Alliance Ave, Springfield, Missouri, USA, MO 65803, or email us at customer.care@staminaproducts.com, or call us at 1-800-375-7520.

  • Page 28: Notes

    NOTES...
  • Page 29 NOTES...

  • Page 30: To Order Parts

    2040 N Alliance Ave, Springfield, MO 65803 Would you like to recieve email information or special offers from Stamina Products? Register at contact.staminaproducts.com TO REGISTER YOUR PRODUCT To enact your warranty, please register your product by going to register.staminaproducts.com. Please have your product model number (printed on the cover of this owner’s manual) and the serial number (printed on the black and white sticker on your...
