Summary of Contents for Hytera AP519EG

  • Page 1 AP519EG...
  • Page 2 Preface This manual describes the information related to the product repair. It is intended for use by qualified technicians only. Before repairing the product properly, please read this manual carefully. This manual is applicable to the following product: AP51X Two-way Radio (X may represent 2, 5, 6,8,9 or 9EG)

  • Page 3: Copyright Information

    Copyright Information Hytera is the trademark or registered trademark of Hytera Communications Corporation Limited (the Company) in the People's Republic of China (PRC) and/or other countries or areas. The Company retains the ownership of its trademarks and product names. All other trademarks and/or product names that may be used in this manual are properties of their respective owners.

  • Page 4: Documentation Information

    Documentation Information This section describes the conventions and revision history of this document. Conventions Instruction Conventions Icon Description Indicates information that can help you make better use of your product. Indicates references that can further describe the related topics. Indicates situations that could cause data loss or equipment damage. Indicates situations that could cause minor personal injury.

  • Page 5: Revision History

    Revision History Version Release Date Description March 2022 Initial release.
  • Page 6 VHF (136–174 MHz)

  • Page 7: Table Of Contents

    VHF (136–174 MHz) Contents Contents 1. Product Layout ............................1 2. Disassembly and Reassembly ......................2 2.1 Tools ..............................2 2.2 Procedure ............................2 3. Exploded View and Packaging Guide ....................4 3.1 Exploded View ........................... 4 3.2 Packaging Guide ..........................6 4.

  • Page 8: Product Layout

    VHF (136–174 MHz) Product Layout 1. Product Layout Part Name Part Name Part Name Channel Selector Knob On-Off Key Accessory Connector Push-to-Talk (PTT) Key Antenna USB Type-C Port Volume Up Key LED Indicator Strap Hole Volume Down Key Speaker Belt Clip Side Key 3 (SK3) Microphone Battery...

  • Page 9: Disassembly And Reassembly

    Disassembly and Reassembly VHF (136–174 MHz) 2. Disassembly and Reassembly This section introduces how to disassemble the radio. To reassemble the radio, do vice versa. 2.1 Tools  Socket wrench  Torx screwdriver  Tweezers  Soldering iron 2.2 Procedure Make sure the waterproof ring is attached in place during reassembly.
  • Page 10 VHF (136–174 MHz) Disassembly and Reassembly Rotate the antenna counter-clockwise to remove it, pull out the Channel Selector knob, and then use a socket wrench to remove the nuts from the Channel Selector knob. Use a Torx screwdriver to remove the four screws on the main board, and then use a soldering iron to unsolder the solder joint of the speaker.

  • Page 11: Exploded View And Packaging Guide

    Exploded View and Packaging Guide VHF (136–174 MHz) 3. Exploded View and Packaging Guide 3.1 Exploded View Parts list: Part No. Description Qty. Part No. Description Qty. 5117000081547A Aluminum chassis 11500000059471 Audio accessory board Protective foam for 5113050000341A 5113010081525A Earpiece PC sheet filter Waterproof sheet for 5113010061001A...
  • Page 12 VHF (136–174 MHz) Exploded View and Packaging Guide Part No. Description Qty. Part No. Description Qty. 5111000000193A Inner lining for knob 5116000081758A Side key bracket 5107020060322A Anti-loose nut 5116000000229A PTT key cover 11500000059474 Knob adapter board 51020600000038 Speaker 5111000081583A Antenna connector 5110000000591B Microphone cover 5113010000110A...

  • Page 13: Packaging Guide

    Exploded View and Packaging Guide VHF (136–174 MHz) 3.2 Packaging Guide...

  • Page 14: Specifications

    VHF (136–174 MHz) Specifications 4. Specifications General Frequency Range 136–174 MHz Dimensions (H x W x D) (with battery and without 105 mm x 55 mm x 29.5 mm antenna) Weight (with battery and antenna) 200 g (±5%) Zone Capacity Channel Capacity Channel Spacing 12.5 KHz/20 KHz/25 KHz...
  • Page 15 Specifications VHF (136–174 MHz) TX Section Frequency Stability ±0.5 ppm Power Output High 11K0F3E@12.5 kHz FM Modulation 14K0F3E@20 kHz 16K0F3E@25 kHz 12.5 kHz (data only): 7K60FXD 4FSK Modulation 12.5 kHz (data and voice): 7K60FXW –36 dBm < 1 GHz Spurious Emission –30 dBm >...
  • Page 16 VHF (136–174 MHz) Specifications All specifications are tested according to applicable standards, and subject to change without notice due to continuous technological development.

  • Page 17: Circuit Description

    Circuit Description VHF (136–174 MHz) 5. Circuit Description 5.1 Baseband Section 5.1.1 Power Supply Module 40mA 3V3A_RX 1000mA U2008 Audio PA TYPE_C 80mA 5V/2A 3V3A_FGU U2009 Charge VSYS U2100 90mA 3V3A_TX U2011 Max. Charging Current 2 A 3V3A_MIC U2014 BAT+ PWR_KEY VBUS 25mA...

  • Page 18: Control Module

    VHF (136–174 MHz) Circuit Description Network Test Point Voltage Range (V) 3V3A_FGU FB2010 3.3±10% V 3V3A_RX FB2008 3.3±10% V 5.1.2 Control Module Reserved DACH SPI1 UART1 Flow Control 52MHz XTAL UART_HOST External PTT GPIO4 KEYIN0-4 KEYOUT0-4 Earpiece Detection GPIO7 KEYPAD BT_MIC AUDIO EMC SK1 SK2...

  • Page 19: Audio Module

    Circuit Description VHF (136–174 MHz) 5.1.3 Audio Module Green ： Transmit Path Blue ： Receive Path RF UNIT BT_SPKP AU_AUXMIC_P BT_SPKN BT_MICP AU_AUXMIC_N MICLP Codec BT_SPKP BT_MICN SPKRP MICLN BT_SPKN (Built-in A7) SPKRN INT_MICP AU_MIC_P INT_MICN EXT_MICP AU_MIC_N EXT_MICN AU_RCVP AU_RCVN Speaker Audio PA...

  • Page 20: Audio Power Amplifier

    VHF (136–174 MHz) Circuit Description Audio Power Amplifier The table below lists the main parameters of the audio amplifier. Parameter Value Rated power (P 0.5 W Maximum power (P 1.7 W max) 8 Ω Speaker Impedance (R 5.2 RF Section 5.2.1 TX Circuit Drive-stage Final-stage Pre-Driver...

  • Page 21: Apc Circuit

    Circuit Description VHF (136–174 MHz) harmonics and spurious signals. Finally, it goes to the antenna for transmission. APC Circuit The APC circuit converts the drain current from the driver-stage PA and final-stage PA into a voltage, and then compares the voltage with the APC control voltage output by the MCU. The error voltage generated from the comparison adjusts the TX power by controlling the gate bias voltage of the driver-stage PA and final-stage PA.

  • Page 22: Fgu Circuit

    VHF (136–174 MHz) Circuit Description RX Back-End The amplified RF signal goes to the A7, in which it is further amplified by the LNA and mixes with the VCO signal to generate a zero IF signal. The zero IF signal goes to the PGA and filter, and is converted into a digital signal by the ADC.

  • Page 23: Troubleshooting Flowchart

    Troubleshooting Flowchart VHF (136–174 MHz) 6. Troubleshooting Flowchart 6.1 Control Circuit Start Is power-on Is the RF circuit The control circuit is En d indication normal? [1] driven normally? [2] normal. Check RF power supply circuits U2008, U2009, and U2010, and control circuit Press the On-Off key, and then check...
  • Page 24 VHF (136–174 MHz) Troubleshooting Flowchart [3] If the On-Off key is not pressed, the level of PWR_KEY_DET is 3.0 V; otherwise, the level of PWR_KEY_DET is 0 V. [4] If the radio can be turned on normally, the current will increase slowly and remain stable, and will keep jumping regularly after the radio enters the standby state.

  • Page 25: Rx Circuit

    Troubleshooting Flowchart VHF (136–174 MHz) 6.2 RX Circuit Start Is output of 3V3A_RX Is output of R3V3 normal? [2] Check U2008 normal? [1] Check U6003 Is t he quiescent operating point of Check Q6000 Q6000 normal? [3] Is RF signal sensitivi t y in t he test Check whether the RF at RF connector of CARKI T connector of CARKI T is...

  • Page 26: Tx Circuit

    VHF (136–174 MHz) Troubleshooting Flowchart [5] Confirm the RF signal output at Q6000. For example, input a –123 dBm RF signal at the RF connector of CARKIT, the output amplitude of LNA_OUT2 at Q6000 is about –115 dBm. [6] U6001 and U6002 are toggle switches. When the radio is receiving signals normally, LNA_H_En will output a control voltage of 3.3 V, and Pin 4 of U6001 and Pin 6 of U6002 are at high level.
  • Page 27 Troubleshooting Flowchart VHF (136–174 MHz) Start Check the power sup ply Is th e p ower supp ly normal? circuit Is th e curre nt or VGG Check the voltage of chip Is TX_En normal? [3] normal? [2] output pin Check the voltage of chip Is APC normal? [8] output pin...
  • Page 28 VHF (136–174 MHz) Troubleshooting Flowchart [2] When the radio operates in low power mode, the current ranges from 1.4 A to 1.9 A. When the radio operates in high power mode, the current ranges from 2.7 A to 3.3 A. [3] The voltage at TX_En is about 3.3±10% V.

  • Page 29: Interface Definition

    Interface Definition VHF (136–174 MHz) 7. Interface Definition The table below lists information about the 9-pin accessory connector. Pin No. Signal Description Illustration SPK+ External speaker + SPK– External speaker - UART pin UART pin 1.SPK+ General ground 2.SPK- 3.TXD Accessory identifier 1_wire 4.RXD 1_WIRE/GPIO...

  • Page 30: Tuning Description

    VHF (136–174 MHz) Tuning Description 8. Tuning Description 8.1 Tools  Radio communication test set: Aeroflex 3920 and HP8921  Power supply: 3 A/10 V  Multimeter  A6 Tuner software 8.2 Tuning Procedure 8.2.1 Tuning the Radio After reassembling the radio, tune it using the A6 Tuner software. The table below describes the items to be tuned and the corresponding tuning methods.

  • Page 31: Pcb View

    9. PCB View Main Board_Top Layer...
  • Page 32 Main Board_Bottom Layer...

  • Page 33: Block Diagram

    Block Diagram VHF (136–174 MHz) 10. Block Diagram Reserved DACH SPI1 UART1 Flow Control 52MHz XTAL UART_HOST External PTT GPIO4 KEYIN0-4 KEYOUT0-4 Earpiece Detection GPIO7 KEYPAD BT_MIC AUDIO EMC SK1 SK2 KEYIN1 AU_HPR KEYOUT0-2 BUTTON GPIO1 Interrupt AUX_MIC INT_MIC Knob Switch GPIO3,6,9,10 Interrupt SWITCH...

  • Page 34: Schematic Diagram

    POWER_charge 11. Schematic Diagram USB_DP TP2112 J2101 FB2214 120R/100MHZ/1300mA GND1 VBUS1 VBUS FB2206 120R/100MHZ/1300mA GND2 VBUS2 R2588 10R/F HOST_TXD1 (11) C2102 R2101 10R/F USB_DP (7) C2656 0.1uF/16V R2589 10R/F 270pF/25V HOST_RXD1 (11) R2102 10R/F USB_DM (7) SBU1 SBU2 MUP-U22401-2 TP2111 USB_DM VSYS C2008...
  • Page 35 POWER_CTRL TP2100 BAT+ TP2101 BAT_THERM TP2114 BAT+ J2100 BAT_THERM (3,6) C2116 470pF/25V D2112 C17200 ESD9N5BM VSYS 3V3D R2116 R2115 R2123 100K/J 560K/J 10K/J Q2115 PWR_KEY_DET PWR_ON PMZ350UPE TP2102 D2100 R2120 BAS16XV2T1G 100K/J D2217 R2282 BAS16XV2T1G (11) PWR_KEY 100K/J R2777 100K/J D2317 D2107 (5,7)
  • Page 36 POWER_LDO 3V6D 3V3A_RX VSYS U2002 L2559 U2008 FB2008 4.7uH/2.85A 3V6D VOUT BOOT C2015 C2016 C2017 C2018 L2003 L2008 C2058 120R/100Mhz/450mA C2077 C2889 0.1uF/16V 3.3uH/1A C2062 VSS2 4.7uF/25V 0.1uF/16V 22uF/25V 16V/2.2 uF C2125 22uF/25V 22uF/25V PWR_ON (4,6) 4.7uH/2.85A 16V/2.2 uF 0.1uF/16V C2019 C2023 R2321...
  • Page 37 A7-POWER R1105 220K/F R1106 220K/F R1121 0R/F BAT+ R1112 10K/J VBUS PWR_ON (4,5) D1102 L1100 V_CORE V_FPGA V_MIC V_RTC BBPLL_TEST 4.7uH/300mA C1103 C1101 C1102 LO_TEST SW_BUCK1 SW_BUCK2 22uF/10V 0.1uF/16V 2700pF/50V ANA_TEST_EN V_CORE1 V_CORE2 CHARGER TST_H V_CORE3 L1101 VBUCK2_2V4 EFUSE R1103 10K/J PROG_EFUSE1 SW_BUCK2_1...
  • Page 38 A7_CTRL 3V3D 3V3D 3V3D R1294 R1295 100K/J R1296 100K/J 1_Wire_EXT (11) Q1203 U1201 R1293 LCD_ID2/1_W IRE_CTRL (7,11) Vcca Vccb UART2_TXD_EXT (11) UART2_RXD_EXT (11) UART2_TXD UART2_RXD 1_Wire 10R/J 2SK3019 2SK3019 Q1201 R1298 0R/F Q1202 2SK3019 TXS0102DCU/NC D1201 NC R1297 0R/F R1291 R1229 100R/J TD_ON (11)
  • Page 39 CODEC TP3001 RCV_SPKP R3001 0R/F C3055 C3056 10K/J 10K/J R3002 0R/F U3009 R3086 0.47uF/6.3V AMP_INPR SPKP U3001 COM1 R3087 0.47uF/6.3V RCV_SPKP AMP_INNR R3003 1.5K/F SPKP RCV_SPKP SPKP (8) SPKN COM1 COM2 RCV_SPKN SPKN R3004 1.5K/F RCV_SPKN SPKN (8) R3152 0R/F COM2 (7,9) AUD_SW...
  • Page 40 U3004 AU_MICN AF_BT_EARP (10) COM1 AUD_SW=0:EXT_MIC ENABLE AU_MICP AF_BT_EARN (10) COM2 AUD_SW=1:INT_MIC ENABLE R3054 BT_AUDIO_SW U3002 33R/J INT_MICN R3055 0R/F INT_MIC 3V3A SSCAP COM1 INT_MICP COM2 C3091 R3053 R3015 1K/J 0.1uF/16V (7,8) AUD_SW SGM2268 33R/J R3000 0R/F 3V3A EXT_MICN (11) SSCAP EXT_MIC EXT_MICP (11)
  • Page 41 3V3D_BT BT_SWS BT_USB_DP BT_USB_DM R9579 R9580 DC5V 10K/J 10K/J J9504 C9531 R9527 BT_RF BT_UART_TXD R9543 33R/J UART1_RXD_BT BT_UART_TXD 33pF/50V 0R/F BT_UART_RXD R9544 33R/J UART1_TXD_BT BT_UART_RXD BT_EARP BT_EARP BT_EARN BT_EARN 818002935 J9505 BT_MIC+ U9504 I2S_DIN/SPI_MOSI BT_MICP BT_MIC- I2S_DOUT/SPI_MISO BT_MICN TLSR9513C I2S_SCK/SPI_CLK I2S_DWS/SPI_CS BT_MICP0 BT_MICN0_AGND...
  • Page 42 INTERFACE 120R/100MHZ/1300mA BL_LED_OUT C5145 J5101 C5110 R5130 L5101 C5111 LED-LCD-BL BL_LED_OUT 0.1uF/16V 0.1uF/16V R5131 16V/2.2 uF L5102 120R/100Mhz/450mA OK_14F016_04 C5144 C5133 0.1uF/16V R5142 10K/J LCD_ID1 R5112 1K/J R5102 1K/J 16V/2.2 uF R5144 (7,11) KROW1 LCD_ID2/1_WIRE_CTRL KCOL1 (7) R5113 1K/J R5108 1K/J R5139 100R/J...
  • Page 43 RX-FRONT-END C6000 C6001 C6002 C6003 C6004 C6005 [13] LNA_IN_1 1000PF/50V 56PF/50V 22pF/50V 20pF/50V 39pF/50V 1000pF/25V C6006 C6007 C6008 C6009 C6010 C6011 68pF/50V 47pF/50V U6000 50V/220PF 1000PF/50V RB706F-40(T106) 1000pF/25V 1000pF/25V L6000 L6001 L6002 72nH/400mA 56nH/600mA 68nH/0.34A L6003 [12] LNA_IN_2 LNA_H_En 120R/100Mhz/450mA C6012 1000pF/25V C6013...
  • Page 44 TX PATH FB7001 3V3A_TX 180R/100MHz/1500mA 7V4_PA R7000 R7001 100R/J 100R/J FB9509 180R/100MHz/1500mA C7004 C7005 1000pF/25V 0.1uF/16V L7000 C7015 C7014 220nH/160mA 8PF/50V 3pF/50V C7089 D7004 C7011 ANT7000 C7009 C7010 27pF/50V 10PF/50V SMP1320-079LF 1000PF/50V 9.1PF/50V 3.9PF L7002 C7013 J111 H2zIs C7026 C7018 C7068 10PF/50V C7017...
  • Page 45 5VA_FGU FGU-VCO 3V3A_FGU L8000 FB8000 BLM15PD121SN1D Q8000 EM6M2 120R/100Mhz/450mA VCC_VCO VCC_VCO R8001 C8000 R8000 VCO_En 1000PF/50V L8001 C8001 R8002 C8002 C8060 0.1uF/16V 22R/F TX_LO [6,13] BLM15PD121SN1D 470pF C8003 C8004 1000PF/50V R8003 L8002 470pF 0.1uF/16V 3.3K/J C8005 R8093 390nH 1000PF/50V 330R/J R8004 L8014 33K/J...

  • Page 46: Part List

    VHF (136–174 MHz) Part List 12. Part List Location Part No. Description No. Ref No. Location Part No. Description C1100 50020100001324 22pF 263 FB2188 50040200000137 Ferrite bead 50020100060783 22μF C1101 264 FB2206 50040200000146 Ferrite bead 50020100000693 0.1μF C1102 265 FB2213 50040200000146 Ferrite bead C1103 50020100061432 2700pF...
  • Page 47 Part List VHF (136–174 MHz) Location Part No. Description No. Ref No. Location Part No. Description 50020100060783 22μF 25 C1139 287 L1104 50040200000156 Ferrite bead 50020100000693 0.1μF 26 C1142 288 L1105 50040200000146 Ferrite bead 27 C1143 50020100001470 470pF 289 L1106 50020100062409 1nF 50020100000693 0.1μF 28 C1144...
  • Page 48 VHF (136–174 MHz) Part List Location Part No. Description No. Ref No. Location Part No. Description 50020100060550 2.2μF 50 C2064 312 L7006 50040300060566 19.4nH 50020100060550 2.2μF 51 C2066 313 L7007 50040300060566 19.4nH 50020100060550 2.2μF 52 C2071 314 L7008 50040100064714 2.2nH 50020100060550 2.2μF 53 C2072 315 L7009...
  • Page 49 Part List VHF (136–174 MHz) Location Part No. Description No. Ref No. Location Part No. Description 50020100000693 0.1μF 50030100001493 33Ω 75 C2142 337 R1102 50020100062445 4.7μF 50030100001582 10kΩ 76 C2331 338 R1103 50020100060550 2.2μF 50030100001582 10kΩ 77 C2332 339 R1104 50020100000693 0.1μF 50030100001493 33Ω...
  • Page 50 VHF (136–174 MHz) Part List Location Part No. Description No. Ref No. Location Part No. Description 50030100001493 33Ω 100 C3018 50020100060524 100pF 362 R1293 50020100000693 0.1μF 50030100001917 100kΩ 101 C3019 363 R1295 50020100000559 1μF 50030100001917 100kΩ 102 C3021 364 R1296 50020100000693 0.1μF 50030100000012 47kΩ...
  • Page 51 Part List VHF (136–174 MHz) Location Part No. Description No. Ref No. Location Part No. Description 50030100001917 100kΩ 125 C6001 50020100002140 15pF 387 R2779 50030100000297 0Ω 126 C6002 50020100000501 6.8pF 388 R3000 50030100000845 1.5kΩ 127 C6003 50020100001323 18pF 389 R3003 50030100000845 1.5kΩ...
  • Page 52 VHF (136–174 MHz) Part List Location Part No. Description No. Ref No. Location Part No. Description 50030100001493 33Ω 150 C6029 50020100061390 330pF 412 R5107 50030100001493 33Ω 151 C6030 50020100000878 3.9pF 413 R5118 50030100001511 1kΩ 152 C6031 50020100000501 6.8pF 414 R5119 50030100001511 1kΩ...
  • Page 53 Part List VHF (136–174 MHz) Location Part No. Description No. Ref No. Location Part No. Description 50030100000967 39Ω 175 C7028 50020100060512 22pF 437 R6006 50030100000896 7.5kΩ 176 C7029 50020100001416 0.5pF 438 R6007 50030100000012 47kΩ 177 C7031 50020100000877 3.3pF 439 R6008 178 C7032 50020100061404 3.6pF 440 R6009...
  • Page 54 VHF (136–174 MHz) Part List Location Part No. Description No. Ref No. Location Part No. Description 50030100000979 0.1Ω 200 C7066 50020100060522 470pF 462 R7021 50030100000570 1kΩ 201 C7067 50020100060516 56pF 463 R7022 50030100001939 150kΩ 202 C7068 50020100060522 470pF 464 R7024 50020100062180 0.1μF 50030100000270 470kΩ...
  • Page 55 Part List VHF (136–174 MHz) Location Part No. Description No. Ref No. Location Part No. Description 50030100001582 10kΩ 225 D1100 50050600000064 LED 487 R9579 50030100001582 10kΩ 226 D1101 50050600000081 LED 488 R9580 50030300000001 100kΩ 227 D1202 50050200000018 Switching diode 489 RT7000 228 D2100 50050200000018 Switching diode 490 5120000000165A Shielding mask...
  • Page 56 VHF (136–174 MHz) Part List Location Part No. Description No. Ref No. Location Part No. Description ESD protection D3007 50050800061344 diode 505 U2008 50080700000384 Power management IC ESD protection D5108 50050800061344 diode 506 U2009 50080700060312 Power management IC ESD protection D5109 50050800061344 diode...
  • Page 57 Part List VHF (136–174 MHz) Location Part No. Description No. Ref No. Location Part No. Description 261 FB2088 50040200000137 Ferrite bead 523 X1100 50110400082007 TCXO 262 FB2105 50040200000137 Ferrite bead...
  • Page 58 Hytera Communications Corporation Limited. 2022 Hytera Communications Corporation Limited. All Rights Reserved. Address: Hytera Tower, Hi-Tech Industrial Park North, 9108 # Beihuan Road, Nanshan District, Shenzhen, People's Republic of China Postcode: 518057 https://www.hytera.com...
