geratech EGE-HSQM Manual

Hdmi 4x4 seamless matrix switcher
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
EGE-HSQM
HDMI 4x4 Seamless
Matrix Switcher

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EGE-HSQM and is the answer not in the manual?

Questions and answers

Related Manuals for geratech EGE-HSQM

Summary of Contents for geratech EGE-HSQM

  • Page 1 EGE-HSQM HDMI 4x4 Seamless Matrix Switcher...
  • Page 2 EGE-HSQM HDMI 4x4 Seamless Matrix Switcher...

  • Page 3: Copyright Notice

    The information in this manual has been carefully checked and is believed to be accurate. Geratech assumes no responsibility for any infringements of patents or other rights of third parties which may result from its use. Geratech assumes no responsibility for any inaccuracies that may be contained in this document. Geratech also makes no commitment to update or to keep current the information contained in this document.
  • Page 4 EGE-HSQM HDMI 4x4 Seamless Matrix Switcher SAFETY PRECAUTIONS Please read all instructions before attempting to unpack, install or operate this equipment and before connecting the power supply. Please keep the following in mind as you unpack and install this equipment: •...

  • Page 5: Table Of Contents

    EGE-HSQM HDMI 4x4 Seamless Matrix Switcher CONTENTS 1. INTRODUCTION ..............1 2. APPLICATIONS ............... 1 3. PACKAGE CONTENTS ............1 4. SYSTEM REQUIREMENTS ............. 1 5. FEATURES ................1 6. OPERATION CONTROLS AND FUNCTIONS ......2 6.1 Front Panel ................. 2 6.2 Rear Panel ................

  • Page 6: Introduction

    EGE-HSQM HDMI 4x4 Seamless Matrix Switcher 1. INTRODUCTION The 4 by 4 HDMI Seamless Matrix Switcher allows the signal from 4 dif- ferent input sources to be freely selected and arranged on 4 displays (TV or monitor), providing four output modes (Matrix, Dual PoP/ PiP, Quad and TV Wall) for various applications.

  • Page 7: Operation Controls And Functions

    EGE-HSQM HDMI 4x4 Seamless Matrix Switcher • Matrix mode: Can routes and output any 4 source to any 4 dis- plays with seamless switching Note: Under output timing 1080i@50/60 input 4 will be disabled, OSD will show “IN 4 Disabled”...
  • Page 8 EGE-HSQM HDMI 4x4 Seamless Matrix Switcher -/+ Buttons: Press these buttons to scroll down/up the OSD selections then press. CHANNEL INPUT 1~4 and CHANNEL OUTPUT A~D: Matrix mode: To display any of the four sources on to andy of the four displays.
  • Page 9 EGE-HSQM HDMI 4x4 Seamless Matrix Switcher Dual PiP mode: To combine 2 sources to be presented on each HDMI output port (Dual A and Dual B) as main and sub screen image. The sub screen is in a part of the main screen.

  • Page 10: Rear Panel

    EGE-HSQM HDMI 4x4 Seamless Matrix Switcher 6.2 Rear Panel HDMI IN 1~4: Connect with HDMI source equipments such as DVD/Blue-ray play- ers and or PC/ Notebook devices. HDMI OUT 1~4: Connect with HDMI TV/Monitor/Recorder for output image display or saving.

  • Page 11: Remote Control Dip Switch

    EGE-HSQM HDMI 4x4 Seamless Matrix Switcher Lock: Press once to lock the keypad and remote control, press 3 second again to release the lock function. Mute: Press this button to mute the audio from HDMI output port. / < / > /OK: Press these buttons to scroll through the OSD selection and press OK to enter and confirm the setting.

  • Page 12: Rs-232 Protocols

    Stop Bit: 1 6.5 RS-232 & Telnet Commands All commands will be not executed unless followed with a carriage return (0x0D) and commands are case-sensitive. Command Active EGE-HSQM Return ASP000 Aspect Ratio is Full ASP000 ASP001 Aspect Ratio is 4:3 TV...
  • Page 13 EGE-HSQM HDMI 4x4 Seamless Matrix Switcher AUD001 Audio output On AUD001 AUD999 Check audio on/off status AUD??? AUE000 Audio edid is LPCM 2CH AUE000 AUE001 Audio edid is LPCM 6CH AUE001 AUE002 Audio edid is LPCM 8CH AUE002 AUE003 Audio edid is BITSTREAM...
  • Page 14 EGE-HSQM HDMI 4x4 Seamless Matrix Switcher DUL002 Set Dual mode to PiP DUL002 DUL003 Check Dual mode status DUL999 RS232 only, check current Ethernet Gateway EGW999 aaa.bbb.ccc.ddd Address EIP999 RS232 only, check current Ethernet IP aaa.bbb.ccc.ddd RS232 only, check current Ethernet Subnet EMK999 aaa.bbb.ccc.ddd...
  • Page 15 EGE-HSQM HDMI 4x4 Seamless Matrix Switcher MNX001 OSD Menu No response DUL003 Check Dual mode status DUL999 RS232 only, check current Ethernet Gateway EGW999 aaa.bbb.ccc.ddd Address EIP999 RS232 only, check current Ethernet IP aaa.bbb.ccc.ddd RS232 only, check current Ethernet Subnet EMK999 aaa.bbb.ccc.ddd...
  • Page 16 EGE-HSQM HDMI 4x4 Seamless Matrix Switcher MNR001 OSD Menu RIGHT (+) No response MNU001 OSD Menu UP No response MNX001 OSD Menu No response MOD001 Matrix mode MOD001 MOD002 Dual PoP mode MOD002 MOD003 TV Wall mode MOD003 MOD004 Dual PiP mode...

  • Page 17: Rs-232 & Telnet Control

    EGE-HSQM HDMI 4x4 Seamless Matrix Switcher SAVE FAV. SAV??? SAV??? ???=001~004=FAV.1~4 VER??? VER999 Check firmware version Example: VER110=V1.1 HGCSSS Check customer's firmware VR2??? 6.6 RS-232 & Telnet control Using PC software or Hyper terminal to configure the settings. This software application can be downloaded from the product webside.

  • Page 18: Telnet Setting

    EGE-HSQM HDMI 4x4 Seamless Matrix Switcher 6.7 Telnet Setting Through TCP/IP protocol, to sent Port 23 for Telnet communication. From OSD menu or through RS-232 command to check Telnet con- nection behavior.

  • Page 19: Osd Menu

    EGE-HSQM HDMI 4x4 Seamless Matrix Switcher 6.8 OSD MENU Main Menu Sub Menu Adjustments Default MATRIX MATRIX DUAL PoP TV WALL MODE DUAL PiP QUAD EXIT CONTRAST 0 ~ 100 BRIGHTNESS 0 ~ 100 SATURATION 0 ~ 100 0 ~ 100...
  • Page 20 EGE-HSQM HDMI 4x4 Seamless Matrix Switcher EXIT LPCM 2CH, LPCM 6CH, LPCM LPCM 2CH 8CH, BITSTREAM, HD LPCM AUDIO EDID (*3) EXIT POSITION LEFT T, RIGHT LEFT T T, LEFT B, RIGHT B H OFFSET 0 ~ 20 V OFFSET...
  • Page 21 EGE-HSQM HDMI 4x4 Seamless Matrix Switcher BYTE3 BYTE4 RE-LINK(*9) TIMEOUT (Min.)(*10) 5~60, OFF EXIT ASPECT RATIO(*11) FULL, 4:3TV, FULL 16:9 TV, KEEP Ratio OTHERS INPUT LABELS(*12) ON, OFF IR ADDRESS(*13) 0~ 3 EXIT YES, NO FACTORY DEFAULT EXIT EXIT IN/OUT RESOLUTION, SOURCE...
  • Page 22 EGE-HSQM HDMI 4x4 Seamless Matrix Switcher *6 HDCP OUTPUT: FOLLOW INPUT: If source with HDCP the output will support HDCP. If input source without HDCP the output will display blue scren. When in Dual mode, one of each side (Left or Right) support HDCP, the output will support HDCP.

  • Page 23: Web Gui

    EGE-HSQM HDMI 4x4 Seamless Matrix Switcher 6.9 Web GUI Connect the device’s CONTROL port from an active network service with RJ-45 terminated CAT5e/6 cable and open a web browser from a PC/laptop with device’s IP address on the web address entry bar then hit enter. The browser will display device’s Routing, Outupt, OSD and System setting pages.
  • Page 24 EGE-HSQM HDMI 4x4 Seamless Matrix Switcher...

  • Page 25: Connection Diagram

    EGE-HSQM HDMI 4x4 Seamless Matrix Switcher 7. CONNECTION DIAGRAM...

  • Page 26: Specifications

    EGE-HSQM HDMI 4x4 Seamless Matrix Switcher 8. SPECIFICATIONS Video Bandwidth 225MHz/6.75Gbps 4x HDMI (Female type) Input port 1xUSB (Service only) Output port 4 x HDMI (Female type) 12V/3A DC Power Supply (US/EU standards, CE/FCC/UL certified) Human body model: ESD Protection ±8kV (air-gap discharge)

  • Page 27: Output Support Timing

    EGE-HSQM HDMI 4x4 Seamless Matrix Switcher 1280x800@60RB, 60, 75 1280x1024@60, 60cvt, 75 1360x768@60 1366x768@60RB, 60 1400x1060@60RB, 60 1440x900@60RB, 60, 75 1600x900@60RB 1600x1200@60 1680x1050@60RB, 60 1920x1200@@60RB 9.2 Output Support Support Timing 480p60 1024x768@60 576p50 1280x800@60 720p50 1280x1024@60 720p60 1366x768@60 1080i50 (Matrix Mode Only)
  • Page 29 www.geratech.eu...
