geratech EGE-UHD2-642FS Manual

6×2 hdmi 4k uhd matrix with hdcp 2.2 and fast switching
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
E G E - U H D 2 - 6 4 2 F S
6×2 HDMI 4K UHD Matrix with HDCP 2.2 and Fast Switching

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EGE-UHD2-642FS and is the answer not in the manual?

Questions and answers

Related Manuals for geratech EGE-UHD2-642FS

Summary of Contents for geratech EGE-UHD2-642FS

  • Page 1 E G E - U H D 2 - 6 4 2 F S 6×2 HDMI 4K UHD Matrix with HDCP 2.2 and Fast Switching...
  • Page 3 DISCLAIMERS The information in this manual has been carefully checked and is believed to be accurate. Geratech assumes no responsibility for any infringements of patents or other rights of third parties which may result from its use. Geratech assumes no responsibility for any inaccuracies that may be contained in this document.
  • Page 4 E G E - U H D 2 - 6 4 2 F S 6×2 HDMI 4K UHD Matrix with HDCP 2.2 and Fast Switching SAFETY PRECAUTIONS Please read all instructions before attempting to unpack or install or operate this equipment, and before connecting the power supply.

  • Page 5: Table Of Contents

    E G E - U H D 2 - 6 4 2 F S 6×2 HDMI 4K UHD Matrix with HDCP 2.2 and Fast Switching CONTENTS 1. Introduction .................1 2. Applications ................1 3. Package Contents ...............1 4. System Requirements ............1 5.

  • Page 6: Introduction

    E G E - U H D 2 - 6 4 2 F S 6×2 HDMI 4K UHD Matrix with HDCP 2.2 and Fast Switching 1. INTRODUCTION The 6 by 2 HDMI 4K UHD Matrix with HDCP 2.2 and Fast Switch which allows HDMI signal from any of its 6 sources to be routed to and displayed on any of its 2 connected HDMI displays simultaneously with View All Mode and Picture-in-picture (PIP) supported.

  • Page 7: Features

    E G E - U H D 2 - 6 4 2 F S 6×2 HDMI 4K UHD Matrix with HDCP 2.2 and Fast Switching 5. FEATURES • HDMI with 3D & 4Kx2K supported, HDCP 2.2 and DVI compliant • Supports 6 HDMI inputs and 2 HDMI outputs • Displays any of 6 High-Definition sources on 2 HDTV displays simultaneously with fast switch • When in Preview mode, the system will be treated as Switcher (2 HDMI output same...

  • Page 8: Operation Controls And Functions

    E G E - U H D 2 - 6 4 2 F S 6×2 HDMI 4K UHD Matrix with HDCP 2.2 and Fast Switching 6. OPERATION CONTROLS AND FUNCTIONS 6.1 Front Panel 11 13 OUT A OUT B CANCEL MENU LOCK POWER...

  • Page 9: Rear Panel

    E G E - U H D 2 - 6 4 2 F S 6×2 HDMI 4K UHD Matrix with HDCP 2.2 and Fast Switching 6.2 Rear Panel HDMI IN HDMI OUT S/PDIF OUT SERVICE CONTROL RS232 IR IN DC 5V HDMI IN: Connect from source equipment such as Blu-ray / DVD / PS3 player, Set-Top Box or any HDMI equipped source device for input signal sending.

  • Page 10: Remote Control

    E G E - U H D 2 - 6 4 2 F S 6×2 HDMI 4K UHD Matrix with HDCP 2.2 and Fast Switching 6.3 REMOTE CONTROL POWER: PRESS POWER KEY TO TURN ON THE DEVICE OR SET TO STANDBY MODE. OUT A~B: PRESS THESE OUT BUTTONS ONCE OUT A IN 1...

  • Page 11: Ir Pin Definitions

    E G E - U H D 2 - 6 4 2 F S 6×2 HDMI 4K UHD Matrix with HDCP 2.2 and Fast Switching LOCK: Press to lock all button functions, press and hold 5 seconds to rescission lock mode. MUTE: Press to mute audio source.
  • Page 12 E G E - U H D 2 - 6 4 2 F S 6×2 HDMI 4K UHD Matrix with HDCP 2.2 and Fast Switching Main Menu Sub Menu Description Default 8/2D/PCM/ Standard EDID. AC3/720P Content: deep color/2D3D/audio/ native resolution. 8/2D/PCM/1080P Standard EDID.
  • Page 13 E G E - U H D 2 - 6 4 2 F S 6×2 HDMI 4K UHD Matrix with HDCP 2.2 and Fast Switching Main Manu Sub Menu Description Default EDID IN3 Same as EDID All. Select Input 3 EDID. Same as EDID All. EDID IN4 Same as EDID All.
  • Page 14 E G E - U H D 2 - 6 4 2 F S 6×2 HDMI 4K UHD Matrix with HDCP 2.2 and Fast Switching Main Menu Sub Menu Description Default Preview Mode View All 1 Main video source and 5 View All Sub video sources.
  • Page 15 E G E - U H D 2 - 6 4 2 F S 6×2 HDMI 4K UHD Matrix with HDCP 2.2 and Fast Switching Main Manu Sub Menu Description Default 5~20 Preview with OSD info show 5~20 Seconds then disappear OSD Always On Preview with OSD...
  • Page 16 E G E - U H D 2 - 6 4 2 F S 6×2 HDMI 4K UHD Matrix with HDCP 2.2 and Fast Switching Main Menu Sub Menu Description Default IN5 On/Off IN6 On/Off Detect IN5, IN6 source with/without signal.

  • Page 17: Rs-232 Protocols

    E G E - U H D 2 - 6 4 2 F S 6×2 HDMI 4K UHD Matrix with HDCP 2.2 and Fast Switching 6.6 RS-232 Protocols Matrix Remote Control Definition Definition Baud Rate: 115200bps Data bit: 8 bits Parity: None Flow Control: None Stop Bit: 1...
  • Page 18 E G E - U H D 2 - 6 4 2 F S 6×2 HDMI 4K UHD Matrix with HDCP 2.2 and Fast Switching 6.7 RS-232 & Telnet Commands Command Name Description Description of Parameter HTTPPORT N1 Set Http Port Number N1=0~65535 TELNETPORT N1 Set Telnet port number...
  • Page 19 E G E - U H D 2 - 6 4 2 F S 6×2 HDMI 4K UHD Matrix with HDCP 2.2 and Fast Switching Command Name Description Description of Parameter EDIDIN N1 N2 Set Input N1 EDID N1=1~6 Source N2=0(Sink A), 1(Sink B), 2(8/2D/PCM/720p), 3(8/2D/ PCM/AC3/720p), 4(8/2D/...
  • Page 20 E G E - U H D 2 - 6 4 2 F S 6×2 HDMI 4K UHD Matrix with HDCP 2.2 and Fast Switching Command Name Description Description of Parameter PVPOS N1 Set preview mode to N1 In view all mode: N1=0(Top), 1(Right), 2(Bottom), 3(Left) In PIP mode:...
  • Page 21 E G E - U H D 2 - 6 4 2 F S 6×2 HDMI 4K UHD Matrix with HDCP 2.2 and Fast Switching Command Name Description Description of Parameter SINKINFO N1 Show Output N1 Information N1=A~B Information: TYPE, Manuf. Name, Native Resolution, Color Depth, 3D, 4K2K, Audio Format...

  • Page 22: Telnet Control

    E G E - U H D 2 - 6 4 2 F S 6×2 HDMI 4K UHD Matrix with HDCP 2.2 and Fast Switching 6.8 Telnet Control To access the telnet control in Windows 7, click on ‘Start’ menu and type “cmd” in the Search field then press enter.
  • Page 23 E G E - U H D 2 - 6 4 2 F S 6×2 HDMI 4K UHD Matrix with HDCP 2.2 and Fast Switching Type HELP or ? to bring out all the commands.

  • Page 24: Web Gui Control

    E G E - U H D 2 - 6 4 2 F S 6×2 HDMI 4K UHD Matrix with HDCP 2.2 and Fast Switching 6.9 Web GUI Control On a PC/Laptop which is connected to an active network system, open a web browser and type device’s IP address (available from LCM monitor or OSD menu) on the web address entry bar.
  • Page 25 E G E - U H D 2 - 6 4 2 F S 6×2 HDMI 4K UHD Matrix with HDCP 2.2 and Fast Switching Click on Settings to set each input’s HDCP control and preset configuration. Click on Network Configuration to set the device’s IP configuration. Once the changes are saved the system will reset the IP address on the device automatically and user will need to re-enter the IP address to continue the Web GUI function.
  • Page 26 E G E - U H D 2 - 6 4 2 F S 6×2 HDMI 4K UHD Matrix with HDCP 2.2 and Fast Switching...

  • Page 27: Connection Diagram

    E G E - U H D 2 - 6 4 2 F S 6×2 HDMI 4K UHD Matrix with HDCP 2.2 and Fast Switching 7. CONNECTION DIAGRAM Satellite Receiver Media Streamer DVD Player Set-top Box Games Console Blu-ray Player RS-232 Equipped PC/ Laptop...

  • Page 28: Specifications

    E G E - U H D 2 - 6 4 2 F S 6×2 HDMI 4K UHD Matrix with HDCP 2.2 and Fast Switching 8. SPECIFICATIONS Video Bandwidth 300MHz/9Gbps Input Ports 6 x HDMI 1 x USB(Service) 1 x RS232 1 x RJ45(Control) 1 x IR Output Ports...
  • Page 29 E G E - U H D 2 - 6 4 2 F S 6×2 HDMI 4K UHD Matrix with HDCP 2.2 and Fast Switching DVI and HDMI Supported Resolutions Input Output 640x480@60 640x480@72 640x480@75 720x480@60 720x576p@50 800x600@60 800x600@72 800x600@75 1024x768@60 1024x768@70 1024x768@75...
  • Page 30 www.egerate-store.com...
