  • Page 1 EGE-6UHD2-848AL 18Gbps 8x8 HDMI Matrix with ARC Function...

  • Page 2: Table Of Contents

    EGE-6UHD2-848AL 18Gbps 8x8 HDMI Matrix with ARC Function Thank you for purchasing this product For optimum performance and safety, please read these instructions care- fully before connecting, operating or adjusting this product. Please keep this manual for future reference. Surge protection device recommended This product contains sensitive electrical components that may be damaged by electrical spikes, surges, electric shock, lighting strikes, etc.

  • Page 3: Introduction

    EGE-6UHD2-848AL 18Gbps 8x8 HDMI Matrix with ARC Function 1. Introduction The 18Gbps 8x8 HDMI Matrix supports the transmission of video (up to 4K2K@60Hz YUV 4:4:4) and multi-channel high resolution digital audio from 8 HDMI sources to 8 HDMI displays. Audio de-embedded to analog and coaxial audio is supported from 8 HDMI output ports.

  • Page 4: Specifications

    EGE-6UHD2-848AL 18Gbps 8x8 HDMI Matrix with ARC Function 4. Specifications...

  • Page 5: Operation Controls And Functions

    EGE-6UHD2-848AL 18Gbps 8x8 HDMI Matrix with ARC Function 5. Operation Controls and Functions Front Panel...
  • Page 6 EGE-6UHD2-848AL 18Gbps 8x8 HDMI Matrix with ARC Function Rear Panel...

  • Page 7: Ir Remote

    EGE-6UHD2-848AL 18Gbps 8x8 HDMI Matrix with ARC Function 6. IR Remote • Power on or Standby: Power on the Matrix or set it to standby mode. • Input 1/2/3/4/5/6/7/8: Select input source button. : Select the last or next input source button.

  • Page 8: Ir Cable Pin Assignment

    EGE-6UHD2-848AL 18Gbps 8x8 HDMI Matrix with ARC Function The second way: If the IR receiver window of the Matrix is blocked or the Matrix is installed in a closed area out of infrared line of sight, the IR receiver cable can be inserted to the “IR EXT” port to receive the IR remote signal.

  • Page 9: Edid Management

    EGE-6UHD2-848AL 18Gbps 8x8 HDMI Matrix with ARC Function 8. EDID Management This Matrix has 21 factory defined EDID settings, 2 user-defined EDID modes and 8 copy EDID modes. You can select defined EDID mode or copy EDID mode to input port through front panel buttons, RS-232 control or Web GUI.
  • Page 10 EGE-6UHD2-848AL 18Gbps 8x8 HDMI Matrix with ARC Function The defined EDID setting list of the product is shown as below:...

  • Page 11: Web Gui User Guide

    EGE-6UHD2-848AL 18Gbps 8x8 HDMI Matrix with ARC Function 9. Web GUI User Guide The Matrix can be controlled by Web GUI. The operation method is shown as below: Step 1: Get the current IP Address. The default IP address is 192.168.1.100. You can get the current Matrix IP address in two ways: The first way: You can get the IP address via panel buttons.
  • Page 12 EGE-6UHD2-848AL 18Gbps 8x8 HDMI Matrix with ARC Function After entering the Web GUI page, there will be a Login page, as shown below: Select the Username from the list and enter the password. The default passwords are: After entering the password, click the “LOGIN” button and the following Status page will appear.
  • Page 13 EGE-6UHD2-848AL 18Gbps 8x8 HDMI Matrix with ARC Function ■ Video Page You can do the following operations on the Video page: 1) Output: The current device’s OUTPUT port. You can select signal source for it. 2) Input: You can click the drop-down menu to select signal source for the corresponding OUTPUT port .
  • Page 14 EGE-6UHD2-848AL 18Gbps 8x8 HDMI Matrix with ARC Function ■ Input Page You can do the following operations on the Input page: 1) Inputs: Input channel of the device. 2) Active: It indicates whether the channel is connected to a signal source.
  • Page 15 EGE-6UHD2-848AL 18Gbps 8x8 HDMI Matrix with ARC Function Download the EDID File of the Corresponding Input Channel Click the drop-down box of “Select EDID File” to select the corresponding input channel. Then click “Download” to download the corresponding EDID file.
  • Page 16 EGE-6UHD2-848AL 18Gbps 8x8 HDMI Matrix with ARC Function ■ CEC Page You can perform CEC management on this page: 1) Input Control: You can control the operation of each input source by clicking the icons on the page. 2) Output Control: You can control the operation of each display, such as power on/off, volume +/-, active source switching.
  • Page 17 EGE-6UHD2-848AL 18Gbps 8x8 HDMI Matrix with ARC Function Set the Default Network Click “Set Network Defaults”, there will be a prompt, as shown in the following figure: Click “OK” to search the IP Address again, as shown in the following figure: After searching is completed, it will switch to the login page, the default network setting is completed.
  • Page 18 EGE-6UHD2-848AL 18Gbps 8x8 HDMI Matrix with ARC Function Modify Username Click the “User” button, enter the correct Old Password, New Password, and Confirm Password, then click “Save”. After successful modification, there will be a prompt, as shown in the following figure: Note: Input rules for changing passwords: (1) The password can’t be empty.
  • Page 19 EGE-6UHD2-848AL 18Gbps 8x8 HDMI Matrix with ARC Function ■ System Page 1) Panel Lock: Click “Panel Lock” to lock/unlock panel buttons. “On” indicates that panel buttons are unavailable; “Off” indicates panel buttons are available. 2) Beep: Click “Beep” to turn on/off the beep.

  • Page 20: Rs-232 Control Command

    EGE-6UHD2-848AL 18Gbps 8x8 HDMI Matrix with ARC Function 10. RS-232 Control Command The product also supports RS-232 control. You need a serial cable with RS- 232 male head and DB9 transfer USB male head. The RS-232 head of the serial cable is connected to the RS-232 control port with DB 9 at the rear of the Matrix, and the USB head of the serial cable is connected to a PC.
  • Page 21 EGE-6UHD2-848AL 18Gbps 8x8 HDMI Matrix with ARC Function...
  • Page 22 EGE-6UHD2-848AL 18Gbps 8x8 HDMI Matrix with ARC Function...
  • Page 23 EGE-6UHD2-848AL 18Gbps 8x8 HDMI Matrix with ARC Function...
  • Page 24 EGE-6UHD2-848AL 18Gbps 8x8 HDMI Matrix with ARC Function...

  • Page 25: Application Example

    EGE-6UHD2-848AL 18Gbps 8x8 HDMI Matrix with ARC Function 11. Application Example...
  • Page 26 www.egerate.com...
