geratech EGE-UHD-642FS Manual

6×2 4k uhd hdmi matrix with fast switching
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
E G E - U H D - 6 4 2 F S
6×2 4K UHD HDMI Matrix with Fast Switching

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EGE-UHD-642FS and is the answer not in the manual?

Questions and answers

Related Manuals for geratech EGE-UHD-642FS

Summary of Contents for geratech EGE-UHD-642FS

  • Page 1 E G E - U H D - 6 4 2 F S 6×2 4K UHD HDMI Matrix with Fast Switching...
  • Page 3 E G E - U H D - 6 4 2 F S 6×2 4K UHD HDMI Matrix with Fast Switching DISCLAIMERS The information in this manual has been carefully checked and is believed to be accurate. Egerate assumes no responsibility for any infringements of patents or other rights of third parties which may result from its use.
  • Page 4 E G E - U H D - 6 4 2 F S 6×2 4K UHD HDMI Matrix with Fast Switching SAFETY PRECAUTIONS Please read all instructions before attempting to unpack, install or operate this equipment and before connecting the power supply. Please keep the following in mind as you unpack and install this equipment: •...

  • Page 5: Table Of Contents

    E G E - U H D - 6 4 2 F S 6×2 4K UHD HDMI Matrix with Fast Switching CONTENTS 1. Introduction ..................1 2. Applications ..................1 3. Package Contents ................1 4. System Requirements ..............1 5. Features ....................2 6. Operation Controls and Functions ..........3 6.1 Front Panel ...................3 6.2 Rear Panel..................5 6.3 OSD Menu ..................6...

  • Page 6: Introduction

    E G E - U H D - 6 4 2 F S 6×2 4K UHD HDMI Matrix with Fast Switching 1. INTRODUCTION The 6 by 2 HDMI matrix which allows HDMI signal from any of its six sources to be routed to and displayed on any of its two connected HDMI displays simultaneously with View All Mode and Picture-in-picture(PIP) supported.

  • Page 7: Features

    E G E - U H D - 6 4 2 F S 6×2 4K UHD HDMI Matrix with Fast Switching 5. FEATURES • HDMI with 3D & 4Kx2K supported, HDCP and DVI compliant • Support six HDMI inputs and two HDMI outputs •...

  • Page 8: Operation Controls And Functions

    E G E - U H D - 6 4 2 F S 6×2 4K UHD HDMI Matrix with Fast Switching 6. OPERATION CONTROLS AND FUNCTIONS 6.1 Front Panel 9 10 12 14 OUT A OUT B CANCEL MENU LOCK POWER 4K UHD 6X2 HDMI MATRIX FAST SWITCH CDPS-6H2HFS...
  • Page 9 E G E - U H D - 6 4 2 F S 6×2 4K UHD HDMI Matrix with Fast Switching All: (SWAP) Press this button to select all outputs to display with an input source. When in PIP mode, press to swap between Main video source and Sub video source. MODE: Press to switch between Preview or Matrix mode.

  • Page 10: Rear Panel

    E G E - U H D - 6 4 2 F S 6×2 4K UHD HDMI Matrix with Fast Switching 6.2 Rear Panel HDMI IN HDMI OUT S/PDIF OUT SERVICE CONTROL RS232 IR IN DC 5V HDMI IN: Connect from source equipments such as Blu-ray/DVD/PS3 players, Set-Top- Box or any HDMI equipped source device for input signal sending.

  • Page 11: Osd Menu

    E G E - U H D - 6 4 2 F S 6×2 4K UHD HDMI Matrix with Fast Switching 6.3 OSD Menu Main Menu Sub Menu Description Default EDID Mode All Input port is using same EDID. In menu “EDID All”, can select suitable EDID.
  • Page 12 E G E - U H D - 6 4 2 F S 6×2 4K UHD HDMI Matrix with Fast Switching Main Menu Sub Menu Description Default 8/2D/PCM/ Standard EDID, AC3/4K2K Content: deep color/2D3D/audio/ native resolution 8/2D/PCM/Y420 Standard EDID, Content: deep color/2D3D/audio/ native resolution 8/2D/PCM/AC3/...
  • Page 13 E G E - U H D - 6 4 2 F S 6×2 4K UHD HDMI Matrix with Fast Switching Main Menu Sub Menu Description Default IN5 Standard /Apple Set IN5 in Apple/ Standard Standard mode IN6 Standard /Apple Set IN6 in Apple/ Standard Standard mode...
  • Page 14 E G E - U H D - 6 4 2 F S 6×2 4K UHD HDMI Matrix with Fast Switching Main Menu Sub Menu Description Default 5~20 Preview with OSD Info 5-20 sec and disappear OSD Always Preview with OSD Info remain ON Exit Network Setup...
  • Page 15 E G E - U H D - 6 4 2 F S 6×2 4K UHD HDMI Matrix with Fast Switching Maın Menu Sub Menu Description Default IN5 On/Off , IN5 , IN6 detect IN6 On/Off source with/without the signal Exit Sink A Info Type, Manuf...

  • Page 16: Remote Control

    E G E - U H D - 6 4 2 F S 6×2 4K UHD HDMI Matrix with Fast Switching 6.4 Remote Control POWER: Press this button to switch the system ON/OFF. OUT A IN 1 OUT A/B: Press these buttons once a time along with an IN OUT B TAKE IN 2...

  • Page 17: Rs-232 Protocols

    +/-: Press these buttons to move up/down under menu selection. IN1~6: Press the IN buttons to select an input from the 6 input sources. MUTE: Press this button to mute both video and audio on the selected OUT A/B selected. 6.5 RS-232 Protocols EGE-UHD-642FS Remote Control Assignment Assignment ►...

  • Page 18: Telnet & Rs-232 Commands

    E G E - U H D - 6 4 2 F S 6×2 4K UHD HDMI Matrix with Fast Switching Command Name Description Description of Parameter POWER OFF NONE POWER ON NONE IPCONFIG DISPLAY THE CURRENT NONE IPCONFIG SIPADDR XXX.XXX.XXX. SET ETHERNET XXX=0-255 ADDRESS...
  • Page 19 E G E - U H D - 6 4 2 F S 6×2 4K UHD HDMI Matrix with Fast Switching Command Name Description Description of Parameter EDIDALL N SET EDID CONTENT FOR N=0-9 (0) Sink A, (1)Sink B, (2) 8/2D/PCM/720p, (3)8/2D/ PCM/AC3/720p, (4) 8/2D/ PCM/1080p, (5)8/2D/PCM/...
  • Page 20 E G E - U H D - 6 4 2 F S 6×2 4K UHD HDMI Matrix with Fast Switching Command Name Description Description of Parameter PRESET SHOW ALL PRESET NONE CONFIG PRESET N1 RECALL PRESET N1 N1=1-6 PRESET N1 N2 SET PRESET N1 N1=1-6 CONFIGURE...
  • Page 21 E G E - U H D - 6 4 2 F S 6×2 4K UHD HDMI Matrix with Fast Switching Command Name Description Description of Parameter PVSRC N1 N2 In Vıew All Mode: NONE NOT SUPPORT In PIP Mode: SET N1=(0)MAIN/1)SUB MAIN/SUB SCREEN N2=INPUT 1-6...
  • Page 22 E G E - U H D - 6 4 2 F S 6×2 4K UHD HDMI Matrix with Fast Switching Command Name Description Description of Parameter OUTNAME N1 SHOW OUTPUT N1 N1=A/B NAME OUTNAME N1 N2 SET OUTPUT N1 NAME N1=A/B N2=ABCDEFGH MATRIXMODE...

  • Page 23: Telnet Control

    E G E - U H D - 6 4 2 F S 6×2 4K UHD HDMI Matrix with Fast Switching 6.7 Telnet Control Before attempting to use the telnet control, please ensure that both the Matrix (via the ‘CONTROL’ port) and the PC/Laptop are connected to the active networks. To access the telnet control in Windows 7, click on the ‘Start’...
  • Page 24 E G E - U H D - 6 4 2 F S 6×2 4K UHD HDMI Matrix with Fast Switching This will bring us into the device which we wish to control. Type "HELP" to list the available commands. Type “IPCONFIG”...

  • Page 25: Web Gui Control

    E G E - U H D - 6 4 2 F S 6×2 4K UHD HDMI Matrix with Fast Switching 6.8 Web GUI Control On a PC/Laptop that is connected to an active network system, open a web browser and type device’s IP address (available from LCM monitor or OSD menu) on the web address entry bar.
  • Page 26 E G E - U H D - 6 4 2 F S 6×2 4K UHD HDMI Matrix with Fast Switching Click on Matrix Control for outputs and EIDID selections. Click on Settings to set each input’s HDCP Control and Preset Configuration.

  • Page 27: Connection Diagram

    E G E - U H D - 6 4 2 F S 6×2 4K UHD HDMI Matrix with Fast Switching Click on Network Configuration to set the device’s IP configuration. Once the changes is saved the system will reset the IP address on the device automatically and user will need to re-enter the IP address to continue the Web GUI function.

  • Page 28: Specifications

    E G E - U H D - 6 4 2 F S 6×2 4K UHD HDMI Matrix with Fast Switching 8.SPECIFICATION Frequency Bandwidth 300Mbps to 3Gbps Input Ports 6 x HDMI 1 x USB (Service only) 1 x Control 1 x RS~232 1 x IR Output ports...
  • Page 29 E G E - U H D - 6 4 2 F S 6×2 4K UHD HDMI Matrix with Fast Switching DVI and HDMI Supported Resolutions Input Output 640x480@60 640x480@72 640x480@75 720x480@60 720x576p@50 800x600@60 800x600@72 800x600@75 1024x768@60 1024x768@70 1024x768@75 1280x720@50 1280x720@60 1280x720p@60 1280x768@60...

  • Page 30: Acronyms

    E G E - U H D - 6 4 2 F S 6×2 4K UHD HDMI Matrix with Fast Switching Audio Sampling Rate Up to 192 kHz HDMI Input (Up to 192kHz) HDMI output Optical output LPCM 2CH LPCM 5.1 CH LPCM 7.1 CH Dolby Digital 2 ~5.1 CH/ DTS 2~5.1 CH Dolby TrueHD / DTS~HD Master Audio...
  • Page 31 E G E - U H D - 6 4 2 F S 6×2 4K UHD HDMI Matrix with Fast Switching...
  • Page 32 www.egerate-store.com...
