Summary of Contents for geratech EGE-UHD-444
- Page 1 EGE-UHD-444 4 x 4 4 K U H D H D M I M a t r i x...
-
Page 3: Copyright Notice
DISCLAIMERS The information in this manual has been carefully checked and is believed to be accurate. Geratech assumes no responsibility for any infringements of patents or other rights of third parties which may result from its use. Geratech assumes no responsibility for any inaccuracies that may be contained in this document. -
Page 4: Safety Precautions
EGE-UHD-444 4 x 4 4 K U H D H D M I M a t r i x SAFETY PRECAUTIONS Please read all instructions before attempting to unpack, install or operate this equipment and before connecting the power supply. - Page 5 EGE-UHD-444 4 x 4 4 K U H D H D M I M a t r i x CONTENTS...
-
Page 6: Package Contents
EGE-UHD-444 4 x 4 4 K U H D H D M I M a t r i x 1. INTRODUCTION The 4 by 4 HDMI 4K UHD Matrix is capable of switching and routing an HDMI signal from any of its four sources to any of four connected HDMI displays, allowing any source to be shown independently on any display. - Page 7 EGE-UHD-444 4 x 4 4 K U H D H D M I M a t r i x 5. FEATURES • HDMI (with 3D & 4K2K supported), HDCP and DVI compliant • Supports up to 7.1 channels of high-definition audio (LPCM, Dolby TrueHD, Dolby Atmos and DTS-HD Master Audio) •...
-
Page 8: Operation Controls And Functions
EGE-UHD-444 4 x 4 4 K U H D H D M I M a t r i x 6. OPERATION CONTROLS AND FUNCTIONS 6.1 Front Panel IR Window: Accepts the remote control signal of this matrix only. POWER Button and LED: Press this button to power the matrix on/off. The LED will light up in green when the power is on and in red when put it into standby mode. - Page 9 EGE-UHD-444 4 x 4 4 K U H D H D M I M a t r i x 6.2 Rear Panel INPUT 1~4: Connect to HDMI equipped source devices such as DVD/Blu-ray players, set-top boxes or games consoles. OUTPUT A~D: Connect to an HDMI TVs/displays or monitors for display of the selected source signal.
- Page 10 EGE-UHD-444 4 x 4 4 K U H D H D M I M a t r i x 6.3 Remote Control POWER: Press this button to switch the unit ON or to put it into standby mode. OUTPUT A and 1~4: Press buttons 1~4 to select the required source for Output A.
-
Page 11: Remote Controller
EGE-UHD-444 4 x 4 4 K U H D H D M I M a t r i x 6.5 RS-232 Protocol MATRIX REMOTE CONTROLLER Assignment Assignment ► ◄ Baud Rate: 115200bps Data bit: 8 bits Parity: None Flow Control: None... - Page 12 EGE-UHD-444 4 x 4 4 K U H D H D M I M a t r i x 6.6 RS-232 and Telnet Commands COMMAND DESCRIPTION PARAMETER Power off NONE Power on NONE IPCONFIG Display the current IP NONE configuration SIPADDR XXX.
- Page 13 EGE-UHD-444 4 x 4 4 K U H D H D M I M a t r i x COMMAND DESCRIPTION PARAMETER EDIDIN N1 N2 Set EDID Appoint content N1=1~4 N2=0~15 0:8/2D/2CH/720p, 1:8/2D/MCH/720p, 2:8/2D/2CH/1080p, 3:8/2D/ MCH/1080p, 4:8/2D/2CH/4K3G, 5:8/2D/MCH/4K3G, 6:8/2D/2CH/ Y420, 7:8/2D/MCH/...
- Page 14 4 x 4 4 K U H D H D M I M a t r i x 6.7 Software Application Please download the software from www.geratech.com.tr with file name CDPS V2.000 and save it in a directory where you may use it later.
- Page 15 EGE-UHD-444 4 x 4 4 K U H D H D M I M a t r i x 6.8 Telnet Control To access the Telnet control in Windows 7, click on the 'Start' menu and type "cmd" in the Search field then press enter.
- Page 16 EGE-UHD-444 4 x 4 4 K U H D H D M I M a t r i x This will bring us into the unit which we wish to control. Type "help" to list the available commands. Note: Commands will not be executed unless followed by a carriage return. Commands are case-insensitive.
- Page 17 EGE-UHD-444 4 x 4 4 K U H D H D M I M a t r i x 6.9 WebGUI Control On a PC/Laptop that is connected to the same active network as the Matrix, open a web browser and type the Matrix's IP address on the web address entry bar (The IP Address can be obtained via RS-232 by using the 'help' command or use the default IP: 192.168.1.50).
- Page 18 EGE-UHD-444 4 x 4 4 K U H D H D M I M a t r i x EDID Settings EDID setting could select EDID mode from the list, also it has four set of “USER”, allows user to upload custom EDID bin file.
- Page 19 EGE-UHD-444 4 x 4 4 K U H D H D M I M a t r i x EDID copy allow user to execute single output EDID to assign position. EDID Import/Export could import or export EDID from Internal to custom EDID.
- Page 20 EGE-UHD-444 4 x 4 4 K U H D H D M I M a t r i x Four custom slots allow user to upload edit EDID, simply select to custom slot and click browse, it allows you to select EDID file from user’s connected PC/Laptop.
- Page 21 EGE-UHD-444 4 x 4 4 K U H D H D M I M a t r i x Type the custom name on, then press to save. Select an EDID from dropdown menu then click Export to download EDID to your connected PC/Laptop.
-
Page 22: Connection Diagram
EGE-UHD-444 4 x 4 4 K U H D H D M I M a t r i x 7. CONNECTION DIAGRAM... -
Page 23: Specifications
EGE-UHD-444 4 x 4 4 K U H D H D M I M a t r i x 8. SPECIFICATIONS 8.1 Technical Specifications Video Bandwidth 300 MHz/9 Gbps Input Ports 4×HDMI, 1×IR (3.5 mm),1×RS-232 (9-pin D-sub ), 1×Control (RJ-45), 1×USB (Service only) Output Ports 4×HDMI... - Page 24 EGE-UHD-444 4 x 4 4 K U H D H D M I M a t r i x 8.2 Supported Resolutions Resolution Input Output 640×480@60/72/75 √ √ 720×480@60 √ √ 720×576p@50 √ √ 800×600@60/72/75 √ √ 1024×768@60/70/75 √ √...
- Page 25 EGE-UHD-444 4 x 4 4 K U H D H D M I M a t r i x 9. ACRONYMS ACRONYM COMPLETE TERM Command Line Interface Digital Theater System Digital Visual Interface EDID Extended Display Identification Data Graphical User Interface...
- Page 26 www.egerate-store.com...
