Electrical Connection:

 Perform electrical connection on the circuit board in the lens as follows:
115 – 230 V AC/ 115 – 230 V DC
X1 Light intensity
Operating voltage control
connection (15 – 100%)
1
AC:
DC:
OFF OFF OFF
OFF OFF ON
OFF ON OFF
OFF ON ON
ON OFF OFF
ON OFF ON
ON ON OFF
ON ON ON
* Factory setting
10/2020
S1
Selection of operating mode
Oper-
S1
ating
mode
2 3
no.
1 Flashing light 0.75 Hz
2
Flashing light 1 Hz
3 Continuous light
4 Blinking light 1 Hz
5 Flashing light 2 Hz
6 Blinking light 2 Hz
7 Flashing light 0.1 Hz
8 Flashing light 0.5 Hz
Connection
of the line
X2
External control input
S1
1 2 3
OFF OFF OFF
*
OFF OFF ON
OFF ON OFF
OFF ON ON
ON OFF OFF
ON OFF ON
ON ON OFF
ON ON ON
Switch position S1.4 for external control: ON
* Factory setting
Example for control by C1:
4/10
Quick guide Quadro LED-HI
DC version (12-48 V)
S1 Light intensity control
Selection of
(15 – 100%)
operating mode
External Control
Operating
mode no.
Standby for
1
external control
*
2
Flashing light 1 Hz
3 Continuous light
4 Blinking light 1 Hz
5 Flashing light 2 Hz
6 Blinking light 2 Hz
7
Flashing light 0.1 Hz
8 Flashing light 0.5 Hz
X1
Operating voltage
connection
Switchover by ...
C1 C2 C1 + C2
... to operating mode No. ...
3 2 4
4 -- 4
-- 4 4
-- -- --
7 6 8
8 -- 8
-- 8 8
-- -- --
