OPERATOR'S MANUAL
Model:
FXA2141R
24V BRUSHLESS CIRCULAR SAW
WARNING: To reduce the risk of injury, the user must read and understand the
Owner's Manual before using this product. Save these instructions for future reference.
Please contact FLEX customer service in Australia 1300 000 346 or
New Zealand 0508 000 346 any time you have questions or warranty claims.
0
10
20
30
40
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Flex FXA2141R
Summary of Contents for Flex FXA2141R
- Page 1 WARNING: To reduce the risk of injury, the user must read and understand the Owner’s Manual before using this product. Save these instructions for future reference. Please contact FLEX customer service in Australia 1300 000 346 or New Zealand 0508 000 346 any time you have questions or warranty claims.
-
Page 2: Safety Symbols
SAFETY SYMBOLS The purpose of safety symbols is to attract your attention to possible dangers. The safety symbols and the explanations with them deserve your careful attention and understanding. The symbol warnings do not, by themselves, eliminate any danger. The instructions and warnings they give are no substitutes for proper accident prevention measures. -
Page 3: General Power Tool Safety Warnings
GENERAL POWER TOOL SAFETY WARNINGS Read all safety warnings, instructions, illustrations and specifications WARNING provided with this power tool. Failure to follow all instructions listed below may result in electric shock, fire and/or serious injury. SAVE ALL WARNINGS AND INSTRUCTIONS FOR FUTURE REFERENCE. The term "power tool"... - Page 4 Power tool use and care Use power tools only with specifically designated battery packs. Use of any other Do not force the power tool. Use the correct battery packs may create a risk of injury and power tool for your application. The correct fire.
-
Page 5: Safety Instructions For Circular Saws
SAFETY INSTRUCTIONS FOR CIRCULAR SAWS Cutting procedures If the blade becomes twisted or misaligned in the cut, the teeth at the back edge of the blade Keep hands away from DANGER can dig into the top surface of the wood causing cutting area and the blade. -
Page 6: Lower Guard Function
Lower guard function Check the lower guard for proper closing before each use. Do not operate the saw if the lower guard does not move freely and close instantly. Never clamp or tie the lower guard into the open position. If the saw is accidentally dropped, the lower guard may be bent. - Page 7 SYMBOLS IMPORTANT: Some of the following symbols may be used on your tool. Please study them and learn their meaning. Proper interpretation of these symbols will allow you to operate the tool better and more safely. Symbol Name Designation/Explanation Volts Voltage Amperes Current...
- Page 8 Symbol Name Designation/Explanation Wear eye protection symbol Alerts user to wear eye protection This product complies with applicable Regulatory compliance mark Australian standards.
- Page 9 FUNCTIONAL DESCRIPTIONS& SPECIFICATIONS Brushless Circular Saw Fig. 1 Calibrated Depth Bracket Auxiliary Handle Calibrated for Standard Lumber Sizes Upper Guard Lock-off Button Trigger Bevel-preset Knob Switch Bevel- adjustment Lever Main Handle Depth-adjustment Lever Blade Depth-of-cut Marks Outer Washer Lower-guard Lift Lever Lower Guard Blade Bolt...
- Page 10 Vacuum Hose Port Calibrated Bevel Quadrant Foot Blade Wrench & Bevel Indicator Storage Area LED Light Model No. FXA2141R Rated Voltage 24 V d.c. No-load Speed 6200 / min (RPM) Bevel Capacity 0 – 56° Blade Diameter Ø 184 mm Blade Arbor Hole Ø...
- Page 11 ASSEMBLY Detach the battery pack WARNING Fig. 2 Battery-release Button from the tool before making any assembly, adjustments or Detach changing accessories. Such preventive safetymeasures reduce the risk of starting the Attach tool accidentally. TO ATTACH/DETACH BATTERY PACK (FIG. 2) To attach the battery pack: Align the raised rib on the battery pack with the grooves in the tool, and then slide the battery...
- Page 12 ATTACHING THE BLADE (FIG. 3) Depress the spindle lock WARNING only when the tool is at a This tool is for cutting WARNING standstill. wood only. Use only the c. Make sure that the saw teeth and the arrow correct saw blades for wood-cutting on the blade point in the same direction as operations.
-
Page 13: Depth-Of-Cut Adjustment
ADJUSTMENTS Detach the battery pack WARNING Fig. 4a Depth-of- from the tool before cut Mark performing any assembly, adjustments, or changing accessories. Such preventive safety measures reduce the risk of starting the tool accidentally. DEPTH-OF–CUT ADJUSTMENT (FIG. 4a & 4b) Your tool is equipped with a depth-of-cut adjustment lever, located beside the upper guard. - Page 14 90° CUTTING ANGLE CHECK (FIG. 5) Fig.5 Quadrant a. Remove the battery pack from the circular saw. Set the foot to the maximum depth of cut setting. b. Loosen the bevel-adjustment lever and set the bevel indicator to 0° on quadrant. Retighten the lever, and check for 90°...
- Page 15 LINE GUIDE (FIG. 7) Fig. 7 For a 0° cut, use the large notch in the foot for 0° Cuts guidance. For 45° bevel cuts, use the small notch. The cutting guide notch will indicate an 45° Cuts approximate line of cut. Make sample cuts in scrap lumber to verify the actual line of cut.
- Page 16 VACUUM HOSE PORT (FIG. 9) Fig. 9 Your tool is equipped with a vacuum hose port Vacuum Hose Port for connection to vacuum / dust extractor hoses with Ø 32mm. Use a suitable vacuum extractor hose or use an adapter, if necessary. Never allow a vacuum / WARNING dust extractor hose to...
- Page 17 This brushless circular saw must be used If any parts are damaged WARNING only with the FLEX 24V series battery packs or missing, do not operate and chargers. this product until the parts are replaced. Use...
- Page 18 LED LIGHT (FIG. 12) Fig. 12 Your tool is equipped with a LED light, located behind the upper guard. This provides additional light on the saw blade and the surface of the workpiece for operation in lower light areas.The LED light will automatically turn on with a slight squeeze on the trigger switch before the tool starts running.
- Page 19 PLUNGE CUTS (FIG. 13) Fig. 13 a. Remove the battery pack from the circular saw. Set the depth adjustment according to the thickness of the material to be cut. c. Attach the battery pack. Lower-guard Lift Lever d. Hold the main handle of the saw with one hand, tilt the saw forward, and rest the front of the foot plate on the material to be cut.
-
Page 20: General Maintenance
We recommend that all tool service be that contain ammonia. performed by a FLEX Factory Service Centre or Storage Authorized FLEX Service Station. Store the tool indoors in a place that is GENERAL MAINTENANCE inaccessible to children. -
Page 21: Warranty Statement
If the Customer registers its purchase of the Product online at www.flex-tools.com.au or by calling • 1300 000 346 in Australia or www.flex-tools.co.nz or by calling 0508 000 346 in New Zealand within 30 days of the date of its purchase (Registration), the Warranty Period for the following Products is as follows: FLEX 24V Tools: 5 years;... -
Page 22: Warranty Claims
The Warranty does not apply if: a) the Product is not supplied in its final shape and form by Chervon or an authorised FLEX Dealer, which can be confirmed on the website store locator (for avoidance of doubt, third party online stores such as eBay, Gumtree, Amazon, etc. - Page 23 *Original purchaser must register the product(s) within 30 days of purchase and retain their receipt as proof of purchase. This warranty applies only to the original purchaser from an authorised FLEX dealer and may not be transferred. If original purchaser does not register their product within 30 days, the warranty will apply for the duration set out in table above in column ‘LIMITED...
- Page 24 -24-...
- Page 25 -25-...
