- Page 1 4439 ENCLOSED ADDRESSABLE MANUAL CALL POINT WITH ISOLATOR Fire alarm solutions technical description www.panasonic-fire-security.com...
-
Page 2: Table Of Contents
Table of Contents INTRODUCTION ABBREVIATIONS GENERAL DESCRIPTION 3.1. PROTECTIVE COVER 3.2. LED 3.3. ENCAPSULATED CIRCUIT SET THE COM LOOP ADDRESS 4.1. AUTO ADDRESSING 4.2. MANUAL ADDRESSING SET THE MODE 5.1. COMPATIBILITY TABLE ROUTINE TESTING REPLACE THE GLASS ELEMENT MOUNTING INSTALLATION AND WIRING TECHNICAL DATA APPROVALS... -
Page 3: Introduction
4439 ENCLOSED ADDRESSABLE MANUAL CALL POINT WITH ISOLATOR - FIRE ALARM SOLUTIONS TECHNICAL DESCRIPTION 1. INTRODUCTION This document describes the addressable manual call point with isolator, type number 4439. The document contains information about the product and instructions on how to mount and connect it. -
Page 4: Abbreviations
2. ABBREVIATIONS Control and indicating equipment = control unit Light Emitting Diode Ingress Protection rating... -
Page 5: General Description
4439 ENCLOSED ADDRESSABLE MANUAL CALL POINT WITH ISOLATOR - FIRE ALARM SOLUTIONS TECHNICAL DESCRIPTION 3. GENERAL DESCRIPTION The enclosed addressable manual call point with isolator is used for immediate manual actuation of a fire alarm. To operate the manual call point the glass element is pressed until it is broken. This will generate a fire alarm in the CIE. -
Page 6: Set The Com Loop Address
4. SET THE COM LOOP ADDRESS 4.1. AUTO ADDRESSING The 4439 supports automatic addressing via EBLWin. For more information, see Planning instructions for the system, version 2.4.x or later. 4.2. MANUAL ADDRESSING Each COM loop unit has to have a unique COM loop address (001-253). -
Page 7: Routine Testing
4439 ENCLOSED ADDRESSABLE MANUAL CALL POINT WITH ISOLATOR - FIRE ALARM SOLUTIONS TECHNICAL DESCRIPTION 6. ROUTINE TESTING a) Insert the test key into the hole in the front cover. The glass position will change, indicating that the manual call point is oper- ated. -
Page 8: Mounting
8. MOUNTING The enclosed addressable manual call point must be mounted on the wall. Screws are not supplied. (Measure in mm) 1. Mounting flange a) Mount the mounting flanges with the supplied screws. b) Cut out the required number of knockouts into the top or bottom of the back box (max diameter 20 mm). c) Apply the cable glands before mounting the manual call point on the wall. -
Page 9: Installation And Wiring
4439 ENCLOSED ADDRESSABLE MANUAL CALL POINT WITH ISOLATOR - FIRE ALARM SOLUTIONS TECHNICAL DESCRIPTION 9. INSTALLATION AND WIRING Screen wire termination is not provided. COM-Loop Wire size (Min) Ø 0.8 mm (0.5 mm²) Wire size (Max) Ø 1.6 mm (2 mm²) -
Page 10: Technical Data
10. TECHNICAL DATA All current consumptions are valid by nominal voltage and by 25 °C. Voltage: Allowed 12 – 30V DC Normal 24V DC Current: Quiescent 1.6 mA Active 2.7 mA Address range 001-253 Address setting With address setting tool Short circuit isolator Internal battery Material... -
Page 11: Approvals
4439 ENCLOSED ADDRESSABLE MANUAL CALL POINT WITH ISOLATOR - FIRE ALARM SOLUTIONS TECHNICAL DESCRIPTION 11. APPROVALS Notified body Applicable directive/ Approval Applicable standards EN54-11 EN54-17 No. 0786-CPD-21236 EN54-11 EN54-17 VdS 2344 No. G213005 VdS2504 EN61000-6-3 (Emission) Self declaration EN50130-4 (Immunity) - Page 12 DOCUMENT NAME: TECHNICAL DESCRIPTION 4439 DOCUMENT NUMBER: MEW01943 EN DATE OF ISSUE: 2015-11-18 REV: 4 DATE OF REVISION: 2024-02-22 Panasonic Fire & Security Europe AB Jungmansgatan 12 SE-211 11 Malmö Sweden Tel: +46 (0)40 697 70 00 www.panasonic-fire-security.com...
