Multi Wi-Fi Kit
User & installation manual
VSTAT07P-1
• Thank you for purchasing this Lennox Product.
• Before operating this unit, please read this manual carefully and retain it for future reference.
DB68-13100A-00_IBIM_LENNOX SOL Multi Wi-Fi Kit_CV_EN_.indd 1
DB68-13100A-00_IBIM_LENNOX SOL Multi Wi-Fi Kit_CV_EN_.indd 1
2024-08-12 오후 2:29:57
2024-08-12 오후 2:29:57
Advertisement
Table of Contents
Related Manuals for Samsung LENNOX VSTAT07P-1
Summary of Contents for Samsung LENNOX VSTAT07P-1
- Page 1 Multi Wi-Fi Kit User & installation manual VSTAT07P-1 • Thank you for purchasing this Lennox Product. • Before operating this unit, please read this manual carefully and retain it for future reference. DB68-13100A-00_IBIM_LENNOX SOL Multi Wi-Fi Kit_CV_EN_.indd 1 DB68-13100A-00_IBIM_LENNOX SOL Multi Wi-Fi Kit_CV_EN_.indd 1 2024-08-12 오후...
-
Page 2: Table Of Contents
Downloading the SmartThings app and registering your Samsung account ......19... -
Page 3: Safety Precautions
Safety precautions California Proposition 65 Warning (US) WARNING Cancer and Reproductive Harm - www.P65Warnings.ca.gov. This installation manual explains how to install a Wi-Fi Kit to an indoor unit of Lennox. Read the installation manual thoroughly before installing the Wi-Fi Kit. (Refer to the appropriate manual for installing product or other optional parts.) WARNING Hazards or unsafe practices that may result in severe personal injury or death. - Page 4 Safety precautions CAUTION • Do not install the product in a place where it is or might be exposed to inflammable gas leakage. - There is risk of fire or explosion. • Do not install the product in a place where it will be exposed to oil or vapor etc. - If the product is used in a place where it is exposed to oil, vapor or sulphur dioxide, parts of the product may get damaged or product may function abnormally.
-
Page 5: Checks Before Installation
Checks before Installation Accessories Multi Wi-Fi Kit Cable ties (2) Cable clamps (3) M4×16 screws (5) User & installation manual U-type terminals (6) • The Wi-Fi Kit must be installed by a certified technician. CAUTION • Before installation, be sure to cut off power. •... -
Page 6: Installing The Multi Wi-Fi Kit
Installing the Multi Wi-Fi Kit Multi Wi-Fi Kit installation • To ensure smooth operation, there should be no obstacle between the Wi-Fi Kit and wireless router that may interfere with communication. When the Wi-Fi Kit is too far from a router or there are CAUTION potentially interfering elements between them, it may cause problems with the performance of the Wi-Fi Kit that cannot be resolved by customer services. - Page 7 V1 V2 F3 F4 3. Use two or more screws to fix the back cover to the wall. Connect the power cables (V1, V2) and communication cables (F1, F2) to the terminals on the back of the front cover while adjusting to a suitable length.
- Page 8 Installing the Multi Wi-Fi Kit Wi-Fi Kit wiring diagram 1) Connecting to a single outdoor unit (F1-F2) R1 R2 <Connection between the Wi-Fi Kit and multiple units> <Connection between the Wi-Fi Kit and a single unit> DB68-13100A-00_IBIM_LENNOX SOL Multi Wi-Fi Kit_CV_EN_.indd 8 DB68-13100A-00_IBIM_LENNOX SOL Multi Wi-Fi Kit_CV_EN_.indd 8 2024-08-12 오후...
- Page 9 2) Connecting to multiple outdoor units (R1-R2) R1 R2 R1 R2 F1 F2 V1 V2 F1 F2 Centralized Touch Controller - Connect R1 and R2 on the outdoor unit to F1 and F2 of the Wi-Fi Kit. - Connect the power cables to V1 and V2 of the indoor unit. - Other controllers (e.g.
- Page 10 Installing the Multi Wi-Fi Kit ※ For indoor units without V1 and V2 connection terminals, use the external control line 2 for SUB PBA (inside the indoor unit) for 12VDC power supply. Connect the BLK line (black) to V2 Connect the ORG line (orange) to V1 R1 R2 V1(ORG)
- Page 11 6. Activate the Wi-Fi Kit. • When power is supplied, all indicators on the Wi-Fi Kit illuminate until the system boots completely. • After the system operates, tracking is performed automatically. 7. Tracking ※ Tracking: The Wi-Fi Kit detects connected indoor unit(s) and the indoor unit(s) detects the connection to the Wi-Fi Kit.
-
Page 12: Setting The Indoor Unit Tenants For Each User
Installing the Multi Wi-Fi Kit Setting the indoor unit tenants for each user • The multi-tenants feature allows you to control and monitor the indoor units with the group channel address (RMC1) that is the same as that of the Wi-Fi Kit. NOTE In order to selectively use the indoor units connected to a single outdoor unit by multiple users, you can install multiple Wi-Fi Kits and group the indoor units by setting the group channel address (RMC1) for each Wi-Fi Kit. - Page 13 2. Use the Wi-Fi Kit settings on the dedicated installation program (Lennox Service Software) to set the tenant addresses for each Wi-Fi Kit. ① ② ③ ④ 1) Press the [Search] button to find the connected Wi-Fi Kits. 2) One by one, select the MAC address for each Wi-Fi Kit from the list. - You can see the MAC address on the label inside the Wi-Fi Kit.
- Page 14 Installing the Multi Wi-Fi Kit 3) Set the tenant address. (Unavailable, 0-F) - Seeing the table below, enter the tenant address on the Lennox Service Software. Tenant address Group channel address for the indoor units controlled by a Wi-Fi Kit Unavailable Controls all indoor units connected to the outdoor unit Controls the indoor units with the group channel address “0"...
-
Page 15: Checking The Multi Wi-Fi Kit
Checking the Multi Wi-Fi Kit Power LED Wi-Fi connection LED Wi-Fi setting LED AP button Reset button <Front panel of the Wi-Fi Kit> Items on the LED display Item LED indication Power supply Wi-Fi connection Wi-Fi setting Initialized General AP connected, Internet connection incomplete Blinking Tracking completed, AP connection incomplete... -
Page 16: Initializing The User Data
Installing the Multi Wi-Fi Kit LED display during tracking ▶ If communication is normal but there are only the indoor units with the central control disabled. • Reset the central control option on the indoor units. When the central control is disabled, the indoor units cannot be controlled with the Wi-Fi kit. -
Page 17: Updating With A Micro Sd Card
Updating with a Micro SD card V1 V2 F3 F4 • Updating with a Micro SD card is only for installer. CAUTION Type Capacity File system ⓓ Micro SD Max 4GB FAT16 ⓒ Micro SDHC Max 32GB FAT32 1. Create a folder named “update" in the Micro SD card. Copy the latest software image and paste it into the folder created in the Micro SD card. -
Page 18: Smartthings App
SmartThings app To use the SmartThings app, connect the product to the network in the sequence described below. The images shown may differ depending on your smartphone model, OS version and manufacturer. You need to set up the Wi-Fi access point only when connecting the product to a Wi-Fi network. Once the product is connected, you can use the SmartThings app via Wi-Fi, 3G, LTE or more wireless networks. -
Page 19: Downloading The Smartthings App And Registering Your Samsung Account
• If you have inquiries regarding the items mentioned above, please contact us at st.service@samsung.com. 2. Registering your Samsung account • A Samsung account is required to use the SmartThings app. To create your Samsung account and log in to your account, follow the instructions displayed on the SmartThings app. - Page 20 “REGISTER MY ACCOUNT" to independently connect to the product. • If a Samsung account-related country error occurs while connecting to your product, log out of your current Samsung account, log in to your previous Samsung account, and then delete all devices that have been connected previously.
-
Page 21: Troubleshooting
SmartThings app. To add the connected device again, first remove it and then proceed with the process. • If you are using a Samsung smartphone, the server may not be connected temporarily. Turn off and on the power of the Wi-Fi Kit, Adding... - Page 22 Troubleshooting Symptom Measure • The communication error is encountered between the indoor unit and Wi-Fi kit. Check the communication cables (F1/F2). • After installing the Wi-Fi kit, the addresses of the indoor/outdoor units may be changed. If the problem persists after checking the communication cable, keep the following steps: The SmartThings app displays the error number, 628.
-
Page 23: Specifications
It is also possible to obtain the complete corresponding source code in a physical medium such as a CD-ROM; a minimal charge will be required. The following URL http://opensource.samsung.com/opensource/WIFIKIT_R18_TZ4/seq/0 leads to the download page of the source code made available and open source license information as related to this product. -
Page 24: Regulatory Notice
Regulatory Notice FCC Notice FCC CAUTION: Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This appliance contains the transmitter module. This device complies with Part 15 of FCC Rules. Operation is Subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received including interference that cause undesired operation. - Page 25 FCC Compliance Statement (applicable models only) Model VSTAT07P-1 Kind of product (The symbol “*” can be any alphanumeric character.) Lennox International Responsible Party - U .S . 2140 Lake Park Blvd, Richardson, TX 75080 Contact Information Tel: 800-953-6669 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.
- Page 26 QUESTIONS OR COMMENTS? COUNTRY CALL OR VISIT US ONLINE AT www.lennox.com for homeowners, AMERICA 800-953-6669 www.lennoxpros.com for dealer/contractor DB68-13100A-00_IBIM_LENNOX SOL Multi Wi-Fi Kit_CV_EN_.indd 26 DB68-13100A-00_IBIM_LENNOX SOL Multi Wi-Fi Kit_CV_EN_.indd 26 2024-08-12 오후 2:30:02 2024-08-12 오후 2:30:02...
