  • Page 1 NETWORK VIDEO RECORDER User Manual SNR-73200WN...

  • Page 2: Table Of Contents

    Overview of NVR Contents overview of nvr Contents Safety Instruction Front Panel Rear Panel Remote Controller Install Hard Drive Connect external equipment Connect NVR nvr Boot up System Initialization Startup Wizard Registering with DDNS Main Interface nvr Menu Popup Menu Main Menu Guide Main Menu Menu Lock...

  • Page 3: Safety Instruction

    sAfety instruCtion Please carefully read the following safety instruction so as to avoid personal injuries and prevent the equipment and other connection devices from being damaged. 1. Please use the power supply enclosed or specified by the manufacturer. Never operate the equipment by using unspecified power supply. 2.

  • Page 4: Overview Of Nvr

    Overview of NVR front pAnel NVR is short for Network Video Recorder. a b c Type Key or indicator Identification Functions HDD indicator If the "Red" indicator flashes, the hard drive is being read or written to. Status lamp Net indicator Display network connection and data transfer status.

  • Page 5: Rear Panel

    reAr pAnel snr-73200wn CAUTION RISK OF ELECTRI SHOCK DO NOT OPEN CAUTION : TO REDUCE THE RISK OF ELECTRICAL SHOCK DO NOT OPEN COVERS. NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. WARNING : TO PREVENT FIRE OR SHOCK HAZARD. DO NOT EXPOSE UNITS NOT SPECIFICALLY DESIGNED FOR OUTDOOR USE TO RAIN OR MOISTURE.

  • Page 6: Remote Controller

    Overview of reMote Controller Operation of remote controller Channel select Numeric key Numeric key Menu Enter into Main menu/Exit Multiple display mode suBMenu Go to Submenu Up arrow Select key/Edit key Left/Right key; Decrease/Increase parameter value of control bar. Down arrow Rewind key Forward key Enter into record search menu/Play key...

  • Page 7: Install Hard Drive

    instAll HArd drive HDD is pre-installed. If you want to replace hard disk drive, please refer to the following instruction. Please do not remove the hard drive when is operating. installation of Hard drive 1. Using a screwdriver, remove the screws from the side and back panels.

  • Page 8: Connect External Equipment

    Overview of NVR ConneCt externAl equipMent Connect your monitor to the NVR using the VGA or HDMI video cable. Connect NVR to the power supply adapter provided. After all connections are completed, plug the NVR in to perform function checks. The appearance of power adaptor differs depending on sales region.

  • Page 9: Nvr Boot Up

    NVR Boot up systeM initiAlizAtion After connecting the NVR power cable to wall outlet, the NVR system initializing screen will appear. It may take 40 seconds to start up, and the screen may beep 5~6 times. stArtup wizArd After the startup is complete, the startup wizard will display.
  • Page 10 Boot up 2. Hard Drive Management: Any new disk connected must be formatted before use. Click on "Select" to highlight the hard drive to be formatted. Click on "Format HDD" and the user login box will appear. Enter the password to log in.
  • Page 11 6. Email Configuration: Receive or Send NVR alarm email and set parameters like email address, Encryption, email enable, and interval. • encryption: Disable, SSL, TLS and Auto optional. Auto means it can detect the encryption type automatically. It is recommended to set the encryption type as Auto.

  • Page 12: Registering With Ddns

    NVR Boot up registering witH ddns to register your product with the wisenet ddns 1. Visit the Wisenet DDNS web site (http://ddns.hanwha-security.com) and sign in with a registered account. 2. From the top menu bar, select <My ddns>. 3. Click the [register product] tab. 4.

  • Page 13: Main Interface

    MAin interfACe In real-time preview mode: right click on any area to access the desired menu. Right click on it to open a context menu, whose menu items may vary depending on the specific condition, such as sign-in, sign-out, split screen mode and various operation conditions. Left click on any channel to access shortcut menu, where operations such as image capture, recording and image zoom-in are available.
  • Page 14 Boot up Component Name Function Pair Do the pairing of camera and NVR. Main Menu Access the main menu Lock Sign out or access sign-in page. 4-Channel Layout Display four channels of video. Realtime: There is no delay of video, but it is not that smooth. Preview Policy Smooth:There may be some delay of video, but it is smooth.

  • Page 15: Nvr Menu

    Menu popup Menu After finishing system initialization, right click the mouse on preview interface or slide the mouse to the bottom of screen to enter into Pop-up Menu. Now you could perform parameter setting and operate on Main Menu, Multi-screen, Record Search, Sequence Brightness settings.

  • Page 16: Main Menu Guide

    Menu MAin Menu guide Wireless Camera Display Output Privacy Zone Record Record Record Schedule Capture Capture Capture Schedule Network Parameter Email Email Schedule Network DDNS RTSP Alarm Motion General Record Search Events Picture Main Menu Device General General Users System Info Info Maintain...

  • Page 17: Main Menu

    MAin Menu On LIVE mode, click the mouse button, or [Menu] button on the remote controller, or click [ ] icon on the toolbar to enter the main menu screen. If system interface is locked, refer to page to unlock by entering your password. In Main Menu mode, you can make settings for Parameter, Record Search, Device, System, Advanced and Shutdown.
  • Page 18 Menu output Go to "Main Menu" ; "Parameter" ; "Display" ; "Output" to enter into the interface. • video output: Live Output • sequence Mode: Layout1 • seq time: Sequence time is set 5 seconds by default. User may set it as required up to 300 seconds • vgA/HdMi resolution: For VGA output or HDMI output, the optional...

  • Page 19: Record Schedule

    record Go to "Main Menu" ; "Parameter" ; "Record" ; "Record" to enter into the interface. • Channel: Set the desired channel in the drop-down menu • record switch: Enable/disable record prerecord: Enable to pre-record motion detection record. • record schedule Go to "Main Menu"...

  • Page 20: Capture Schedule

    Menu Capture Go to "Main Menu" ; "Parameter" ; "Capture". • Channel: Select capture channel • Auto Capture: Enable/Disable auto capture. • normal lnterval: 6s / 10s / 30s / 1min / 10min / 30min / 1h • Alarm lnterval: 6s / 10s / 30s / 1min / 10min / 30min / 1h • Manual Capture: Enable/Disable manual capture You can click on the icon [ ] in the live window to manually capture the image...
  • Page 21 network Go to "Main Menu" ; "Parameter" ; "Network" ; "Network" to enter the interface. Select the network connection option (PPPoE, DHCP, Static) to set the port. User can view and do the recording, playback or backup of the video remotely. Take DHCP as an example.

  • Page 22: E-Mail Schedule

    Menu Click on "settings--Forwarding and POP/IMAP" Click on "Enable IMAP--Save Changes" e-mail schedule Go to "Main Menu" ; "Parameter" ; "Network" ; "E-mail Schedule" to make Email schedule. Select the channel and the date to be set. One week's schedule can be set. The record schedule of the current channel can be copied to any other channel or all channels.
  • Page 23 rtsp Go to "Main Menu" ; "Parameter" ; "Network" ; "RTSP" Set User Name and Password to view video by PC software VLC. • rtsp enable: Enable/Disable • verify: Enable/Disable • rtsp port: 00054 • rtsp user name: admin • rtsp password: 111111 • Analog Channel: rtsp://IP:Port/chA/B • A: 01(ch1), 02(ch2) • B: 0(main stream), 1(sub stream)
  • Page 24 Menu Motion Go to "Main Menu" ; "Parameter" ; "Alarm" ; "Motion" to enter into the interface. • Channel: Select Channel. • sensitivity: Support 1-8 level, 8 is the highest level. • Buzzer: When detecting object moving, buzzer makes alarms (disable, 10 seconds, 20 seconds, 40 seconds and 60 seconds).
  • Page 25 record search general Go to "Main Menu" ; "Record Search" ; "Record Search" to enter into the interface. • Channel: Select the channel you want to search. • type: Select the type the playback record. There are three options: All, Normal and Motion.
  • Page 26 Menu • Clip and backup: When it is under single channel playback, the [ ] icon will appear in the Play Control bar. Click the icon to start video clip function, click the icon again to end the function and pop up the dialog. Now, you may save the clipped video file.

  • Page 27: Play Backup Files

    play Backup files 1. Copy backup files to the computer. 2. Open SVideo player and click [ + ] or [ For example, if you want to choose *.264, *.avi, *.mp4, add backup file and select a file to play. Play: Click to play file Pause: Click to pause.
  • Page 28 Menu Capture Settings: Set the path to save image It is recommended to use SVideo Player contained in compact disk for playback. Use of any other player may cause compatibility problem. picture Go to "Main Menu" ; "Parameter" Support search picture for 5000pcs each time. If the picture number greater than this value, please adjust the date (time) of the current search and search again.
  • Page 29 device Go to "Main Menu" ; "Device" ; "HDD" to enter into the interface. When HDD is connected, the system will automatically detect if the HDD is OK or not; if the HDD needs to be formatted, select the HDD and format it. If the system detects the HDD is OK, the HDD status will be shown as "OK". • no.: Number of HDD connected to system.
  • Page 30 Menu system general Go to "Main Menu" ; "System" ; "General" ; "General" to enter into the interface. User may set Date, Time, Date Format, Time Format, Language, Video Format, Menu Timeouts and Show Wizard on this page. Go to "Main Menu" ; "System" ; "General" ; "DST". Enter into the interface to set DST, Time Offset, Start Time and End Time.
  • Page 31 Go to "Main Menu" ; "System" ; "General" ; "NTP". • ntp service: Enable/Disable NTP function. • server Address: Select NTP server (time.windows.com, time.nist.gov, pool. ntp.org). • time zone: Corresponding time zones for various nations or regions. • update time: Enable NTP function and save parameters and click Update Time to calibrate the system time.
  • Page 32 Menu user edit User may enable or disable the function or set password. info Go to "Main Menu" ; "System" ; "Info" to enter into the interface. Go to "Main Menu" ; "System" ; "Log". User may search log information in different period of time. Click "Backup" to save all the log information.
  • Page 33 Advanced Maintain Go to "Main Menu" ; "Advanced" ; "Maintain" to enter into the interface. • default user: Set a user as default user or turn default user off. • Auto reboot: Enable the auto maintenance function to reboot system regularly at every day/week/month.

  • Page 34: Menu Lock

    Menu Menu loCK In consideration of system safety, user may click the icon [ ] on the toolbar when he leaves away from and the system interface will be locked. User has to input Device ID, User Name and Password on the login interface to unlock. In case that the password is forgotten, contact the technical personnel.

  • Page 35: Web Application Manager

    Web Application Manager systeM environMent requireMents The minimum requirements for hardware and OS required to run Web Application are given below. Minimum Recommended Intel i3 Intel i7 or higher 4GB or more 8GB or more Hard Drive 500GB or more 1000GB or more Display RAM 2GB or more...
  • Page 36 Web Application Manager If the Web plugins is not downloaded successfully, please check if your browser's safety level or firewall setting is set too high. Please open IE browser ; [Menu Bar] Tools ; Internet options ; Security ; Internet ; Custom level ; Enable the options. download and installation of plugin for ie Enter IP address of in address bar of IE, for example,...
  • Page 37 Shut down IE browser and restart it, and then enter IP address of NVR in address bar to access login page. download and installation of plugin for Mac sAfAri Enter IP address of NVR in address bar of Mac SAFARI, for example, http://192.168.2.173:80, and click on "download"...

  • Page 38: Web Application Manager Login

    Web Application Manager Shut down Mac SAFARI browser and restart it, and then enter IP address of NVR in address bar to access login page. The above instruction is to install the initial plug in. You can use the same plugin for IE and Firefox.
  • Page 39 Menu Bar Menu Bar: Live, Playback, Remote Setting, Local Setting and Logout. live display video Control Log in the Web Application Manager, system will be defaulted to enter into <Live> interface. You can click [Play] button to Open/ close live images, on-spot record, capture, and many live display modes. Buttons on a single live interface : Open or close the images on Live window.
  • Page 40 Web Application Manager playback Click [ ] to enter into Playback interface to remotely view the records in HDD. It supports 1 to 4 channel record playback. record search Record playback procedure Firstly, select the date you want to check and tick 1 to 4 channels. Any record files in current channel at current date will be displayed in the status bar of the interface.
  • Page 41 playback Control Playback control bar Detailed brief description is shown as below: Description Description Slow playing x1/2,1/4, 1/8, Fast Forward Play x1/2/4/8 Pause Open all the playback channels Stop Stop playing all the playback Frame by frame Digital ZOOM Record Clip Original proportions Image Snapshot Stretch...

  • Page 42: Remote Setting

    Web Application Manager remote setting Click Remote Setting to enter into the interface shown, including Record,Capture, Network, Alarm, Device, System and Advance. record Click <Record> option to unfold its sub-options: Record parameter and Schedule. record parameters The parameters should be consistent with NVR local setting. record schedule The parameters should be consistent with NVR local setting.
  • Page 43 network Unfold <Network> to show its sub-options: Network, Email, DDNS and RTSP configuration. lAn setting supports Static/DHCP/PPPoE modes. System default network type is <DHCP>. User can set parameters as required. If you change Network type to PPPoE, NVR will automatically restart to make the setting effective. email Email: Set NVR alarm Email configuration parameters, including Email address,...
  • Page 44 Web Application Manager Alarm Alarm setting includes Motion Detection Parameters. Motion detection Configure Sensitivity, Alarm out, Alarm Record and Alarm Capture, etc. Detailed setting should be consistent with NVR local setting. device Click <Device> to unfold its sub-options: User may check HDD status of and overwritten time.
  • Page 45 users User may configure user name and password and detailed setting should be consistent with NVR local setting. info User may search device name, device number, device type, MAC address, software version, IE version and hardware version of NVR. English _45...
  • Page 46 Web Application Manager Advanced Click Advance to unfold its sub-options: Firmware Update, Load default, Events and Maintain. firmware update User may remotely update NVR system. updating procedure Firstly, select the update file path. The file format is *.sw. Secondly, click "Start" to start updating. The updating progress can be seen on the screen.

  • Page 47: Local Setting

    Maintain Allow you remotely set auto maintain time for NVR. Detailed setting should be consistent with NVR local setting. local setting User may set Record Path (save Live record and Playback clip file), Download Path for remote file, Snapshot Path for captured pictures, Interval for switching record files (Packaging time), and File type (h.264, AVI and MP4).

  • Page 48: Mobile App

    Mobile App Mobile App Android pHones/tABlets 1. Open Play Store to search WiseView and click "INSTALL" to install. 2. After installation, open WiseView and select "Device". Then click [ ] to add new device. Scan QR code under Information page of system on local NVR. Then input client port, user name and password, and then click Save to log in to the device.

  • Page 49: Iphone/Ipad

    ipHone/ipAd 1. Open App Store to search WiseView, and click icon [ ] to install. 2. Open WiseView, and go to Device. Click [ ] to add new device. Scan QR code under Information page of system on local NVR. Then input client port, user name and password, and then click Save to log in to the device. English _49...

  • Page 50: Appendix

    Appendix Appendix trouBlesHooting Symptom Countermeasures • Check if the power supply system is properly connected and data cord and power cables are securely What can I do if the system does not detect connected, and if something wrong with the HDD interface. Or you may check if your HDD is supported the HDD? by referring to the specifications or descriptions.
  • Page 51 usage Maintenance 1. To shut down NVR, please firstly shut down the system and then turn off the power. Do not turn off the power directly or HDD data will be lost or damaged. 2. Please keep NVR away from heat sources or places. 3.

  • Page 52: Specifications

    Appendix speCifiCAtions snr-73200wn Item Details Description Inputs 4CH Wireless Video Resolution 1,920x1,080 (Full HD) Max 60fps@1080p Frame rate - Main stream : 15fps@1080p per channel Live Resolution 1080p Multi Screen display 1 / 4 / SEQ Performance Embedded Linux Operating System Installation wizard Support Compression...
  • Page 53 Item Details Supported OS - PC : Windows Vista, Windows 7, Windows ® ® ® Mac OS X 10.12.2 or above ® - Mobile : Android Ver4.4 or above Web / App viewer 7.0 or above ® Supported Browser Remote - Microsoft Internet Explorer (Ver.
  • Page 54 Appendix Item Details Mechanical / Package information Color / Material Black / Metal Dimension (W x D x H) 300X219.7X52.5mm (11.8” x 8.65” x 2.07”) Weight 1.43Kg prox.- 1TB hard drive pre-installed Quick start guide - Eng / Fre / Spa / Por / Ger (5 in total) Samsungsv.com insert Printed material Package contents insert...

  • Page 55: Dimension

    diMension Unit: mm (inch) English _55...
