FUNCTIONS |
gm FRONT CONTROL
@) Tint control
) Color control
3) Bright control
@) Picture control
6) Channel display button
This button causea the display of received channel
numbers on the screen.
''1-place'' button...... Each pressing changes channel
"O" through '9'.
"'10-place'' button .... Each pressing changes channel
"no display"' and ''1'' through
"gr,
* Only the channel display changes.
* Selection of broadcasting stations is not possible.
¢ Channel Memory Presetting
6) CH. display button/ 6) preset button/ ® Band
Switch/ Memory button/ @) Tuning-konb
. Press the preset button ''ON"'.
2. Press the channel button (on remote-control device) of
the desired channels.
-3. Preset the band switch as follows:
For memorizing channels 2~6 — VL (VHF)
For memorizing channels 7~13 — VH (VHF)
For memorizing channels 14~69 — U (UHF)
4. Rotate the tuning knob and receive pictures from those
broadcasting stations desired to be memorized.
5. By pressing the channel display button, display the chan-
nel number of the broadcasting station from which the
picture was displayed.
6. Press the memory button (the channel display flickers
once).
7. After completing the memorizing of all desired station
channels, press the preset button ''OFF"'.
*Prior to shipment from the factory, standard presetting
=
to permit sequential channel changing from channel 2 |
through 13 is applied to the TV units.
4 (No. 5883)
Od ®@LoOdA@OlO ©
Qe ON OOD ®
O OG &
(6) Preset button (AFC (Automatic. fine-tune control))
No exclusive AFC < ON # OFF > switch is provided
on this TV unit; However by setting the Preset button
"ON'', the AFC circuit can be switched ''OFF''.
TV/Video button
Each time the TV/Video button is pressed, the mode
is set to TV mode or Video mode.
* In TV mode, the input at the antenna terminal is used.
In Video mode, the input at the Video input terminal is
used.
) Channel up-button
42 Volume up-Down button
43) Power button
Press the power button while the unit is in standby
mode, then, power is supplied and the TV set operates.
Press the power button again to turn the power off. The
unit is set to standby mode.
a4 Remocon Sensor
45) Steep timer indicator
Lights when the sleep timer button (on remote control
device) is pressed to set the sleep timer.
When the sleep timer is released, the indicator goes off.
Main power indicator
Lights when the main power button is pressed. Goes
off when the main power is shut off.
a? Earphone jack
Main Power button
Press the main power button. Then, the main power
indicator lights and the unit is set to standby mode.
Press the button again to turn the main power off.
