JVC C-1336 Service Manual

move. C-1336 ..
SPECIFICATIONS
Dimension : (W) 37.0 cmx(D) 37.8 cmx (H) 35.0 cm
Weight : 10.3 kg
GND. : Live & Neutral GND.
TV System & Color System
VHF/UHF : CCIR(M), NTSC
TV Receiving Channel & Frequency
VL Band (2~6) : 54 MHz ~ 88 MHz
VH Band (7~13) : 174 MHz~216 MHz
UHF Band (14~ 69) : 470 MHz~ 806 MHz
Intermediate Frequency
Video IF Carrier : 45.75 MHz :
Sound IF Carrier : 41.25 MHz (4.5 MHz)
Color Sub Carrier : 3.58 MHz
ANT. Input Impedance: 75 Q Unbalanced (VHF)
30092 Balanced (UHF)
CONTENTS
Specifications ............cccercccvscscsesennsencsecncncncoesccneesaes 1
Safoty: Precautions w2cccccceccievcneccs vecconseapepsensessecetyieeess 2
PG atleS: oscsacis. ies cnveidasveseczinneercestiasesiuant Ss tasventoealeves 2
OUUING. a disesiied chncaptesecacetisesansaats base adenesseesneasecais'. 2~3
EUNCtIONS: siisiscswarsccsccninecsscescsetinaeecawreceaviaieaanvesss 4~5
How to Remove for Service ..... n i g a cetnescawGueuameneacimeirane' 6
Service Adjustment ......c.ccccscecssceceeeesseeseeeenserseareene 7
Replacement Parts List ..........ciscecscsssscscseneeeseaees 8~15
* WITH SCHEMATIC DIAGRAM &
SERVICE ADJUSTMENT (NTSC)
¢ BASIC CHASSIS: VX-SHASSIS
¢ SAME TYPE MODEL: C-1350
Power Input > AC120 V, 60 Hz
Input Current : 115A
Picture Tube : 14" In-Line Type
Viewable Picture Size: (W) 28.1 cm x (H) 21.1 cm
High Voltage : 24 kV + 1kV (at zero beam
; current)
Speaker : 8cm round type, 8 Q
Audio Power Output : 1.2 W
Video Input : 1 Vp-p, 752
Audio Input : 390 mVrms (—6 dB) High
. Impedance
Tube 4
Ic. : 12 {in TV), 1 (in Remocon)
Transistor : 23 (in TV), 2 (in Remocon)
(Design and specifications subject. to change without
notiece)
