ELETTROQUADRI MP2-NR User, Maintenance And Installation Manual

Microprocessor system
Table of Contents

Advertisement

Quick Links

USER, MAINTENANCE AND
INSTALLATION MANUAL
MICROPROCESSOR SYSTEM
MP2 - NR/ND
WITH SOFTWARE VERSION 80.01
TRANSLATION OF THE ORIGINAL INSTRUCTIONS
ENGLISH
2024 Rev. 1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MP2-NR and is the answer not in the manual?

Questions and answers

Summary of Contents for ELETTROQUADRI MP2-NR

  • Page 1 USER, MAINTENANCE AND INSTALLATION MANUAL MICROPROCESSOR SYSTEM MP2 - NR/ND WITH SOFTWARE VERSION 80.01 TRANSLATION OF THE ORIGINAL INSTRUCTIONS ENGLISH 2024 Rev. 1.0...
  • Page 2 REVISION INDEX REASON FOR REVISION DATE OF REVISION New edition 22/07/2024 Text editing/new logo 28/10/2024...
  • Page 3: Table Of Contents

    4.4.2. Fo selection - Omnibus procedure ....................32 4.4.3. Ec selection - Travel limit test ....................32 4.4.4. In selection - Uncontrolled movement test ................. 32 4.4.5. PA selection - Commissioning ...................... 32 3 / 52 MP2-NR/ND - Rev. 1.0...
  • Page 4 6.4.10. X-DOOR board ........................... 48 6.4.11. MP8120 board ........................... 49 6.5. MP2-NR/ND board layout ......................49 6.5.1. LEDs on MP2-NR/ND board ......................50 6.6. Manoeuvres ...........................51 6.6.1. Single call manoeuvre or collective down manoeuvre ..............51 6.6.2. Collective up/down manoeuvre ....................52 6.7.
  • Page 5: General Information

    ELETTROQUADRI S.r.l. declines all liability for improper use of the board and for damages caused as a result of operations not considered in this manual or in any case unreasonable.
  • Page 6: How To Use This Manual

    3. CHAPTER of the Installation Manual section - NUMBER and NAME 4. Type of manual 5. Board model and manual revision index 6. Number corresponding to the current page and total number of pages in the whole manual 7. Manufacturer's name and copyright 6 / 52 MP2-NR/ND - Rev. 1.0...
  • Page 7: Symbols

    1.2.3. General definitions Some recurring terms in the manual are described to ensure a more complete understanding of their meaning. ELETTROQUADRI S.r.l., the manufacturer of the aforementioned board, will be referred to as the Manufacturer. Danger zone: any area inside and/or near the electric cabinet containing the board in which the presence of a person constitutes a risk for the health and safety of said person.
  • Page 8: Manufacturer's Data

    1.5. Warranty The MP2-NR/ND board warranty is valid for 1 year. CAUTION The Manufacturer declines all liability for accidents involving persons or things caused by a failure to observe the instructions and regulations provided in this manual or the non-observance of the safety and accident prevention regulations in force in the country of machine use.
  • Page 9: Safety

    Consequently, any intervention which alters board configuration shall automatically exonerate the manufacturer from all liability. Consequently, any use other than those indicated in this manual shall exonerate ELETTROQUADRI S.r.l. from all liability for any risks which may occur. 2.2.2. Warnings for Installer safety Before commencing work, the Installer must be fully knowledgeable of board function, configuration, and technical operating characteristics.
  • Page 10: Identification Of Operating Personnel

    (e.g. supervision of installation, testing, adjustments, optimization, etc.). The Manufacturer, if stipulated in the contract with the user, may in any case guarantee, if needed, expert technical intervention via the after-sales assistance service. 10 / 52 MP2-NR/ND - Rev. 1.0...
  • Page 11: Personal Protective Equipment

    SAFETY FOOTWEAR MUST BE WORN PROTECTIVE GLOVES MUST BE WORN PROTECTIVE CLOTHING MUST BE WORN 2.4. Correct use The MP2-NR/ND board may ONLY be used in ELETTROQUADRI S.r.l. electrical lift control cabinets. 2.5. Incorrect use The board MUST NOT be used: •...
  • Page 12 Safety MP2-NR/ND USER, MAINTENANCE AND INSTALLATION MANUAL PAGE LEFT INTENTIONALLY BLANK 12 / 52 MP2-NR/ND - Rev. 1.0...
  • Page 13: Installation

    8. After completing and checking the connections, set the switch on the cabinet to the "INSPECTION" position. 9. Reset the board to exit the "COMMISSIONING" mode ("INSPECTION" mode will be active from the cabinet). 13 / 52 MP2-NR/ND - Rev. 1.0...
  • Page 14: Installation Control Panel Connections

    The run of the car is limited by CRS and CRD mechanical switches or by bistable CRSB / CRDB switches at the top and bottom floors. • Once the inspection is completed, the car, if it has been moved, resets to the lowest floor, or to its former destination. 14 / 52 MP2-NR/ND - Rev. 1.0...
  • Page 15: Inspection Control With Bilm5 Switch (With Paramater Nc = Yes)

    - Using the floor key, keep it in the active position and the MP8120 board will emit a two-tone signal to confirm that reset has been completed. 15 / 52 MP2-NR/ND - Rev. 1.0...
  • Page 16: Reset Conditions

    If the main floor is not the lowest floor, the reset described above will conclude with the car returning to the main floor. IMPORTANT The LED functions may vary depending on system configuration, see the table in “6.5.1. LED sulla scheda MP2” a pagina <?>. 16 / 52 MP2-NR/ND - Rev. 1.0...
  • Page 17: Programming

    4.2. Programming the board The MP2 board parameters can be configured using: • the QuickUP APP (EQBLE tool needed). • the PROGR and ENT/RST buttons on the board. 17 / 52 MP2-NR/ND - Rev. 1.0...
  • Page 18: App Quickup

    MPX OUTPUTS Device info INFO XCAB INPUTS Descent inspection limits (XCAB LID input) XCAB OUTPUTS 4.2.2. Board display Indication on the display Description Program release version (e.g. “rl51”); displays on power up. System resetting. 18 / 52 MP2-NR/ND - Rev. 1.0...
  • Page 19 Normal operation, actuation: • of the door open button. • of the photocells or mobile rib. • of the overload. • of machine room temperature. Normal operation: • timer running. 19 / 52 MP2-NR/ND - Rev. 1.0...
  • Page 20: Mp2 Board Programming Using Buttons On The Board

    Press PROGR to change the program/move the dot/modify the parameter. PROGR Press ENT/RST to enter the selected program/confirm the setting. ENT/RST Key/Terminal block Function M1A/1 + GND increments numerical values. M1B/1 + GND decrements numerical values. MAIN MENU Codes Values Meaning Description 20 / 52 MP2-NR/ND - Rev. 1.0...
  • Page 21 Pressed button Condition Pressed button Condition Pressed button condition The successive Pb submenu will display To confirm: ENT/RST ENT/RST → → To go to the next function in the AL submenu: PROGR → 21 / 52 MP2-NR/ND - Rev. 1.0...
  • Page 22 Micro-processor for bistable lowest floor inspection ramp Enabled down switch RIDB Not active if active: enables control via the board Micro-processor for bistable ramp down and top floor Enabled inspection switch) RISB 22 / 52 MP2-NR/ND - Rev. 1.0...
  • Page 23 STAFF operation S.F. parking doors open parking doors parking doors closed 0 to UP setting parking with doors closed/open on different floors front doors closed rear doors closed front+rear doors closed C.P. 23 / 52 MP2-NR/ND - Rev. 1.0...
  • Page 24 5 to 99 start wait time for parking 50 to 250 duplo/duplex/triplex/quadruplex: closest call function activation time 0 to 250 only if Elettroquadri has set “PICK-UP manoeuvre”: main floor departure delay contactor excitation delay after slide excitation 0 to 50 dsec duplo/duplex/triplex/quadruplex:...
  • Page 25 20 to 90 5 to 120 energy saving activation time (ES=YES) 10 to 90 variable speed drive: call disable time after energy saving activation (equal to inverter shutdown time) 25 / 52 MP2-NR/ND - Rev. 1.0...
  • Page 26 “Alt” button disabled (restart when button released) active (restart with car call) disabled rope: restart after E -23 (travel limit or fall arrestor) active 26 / 52 MP2-NR/ND - Rev. 1.0...
  • Page 27 CF4) and J12/3 (CF5, led CF5) active disabled ENABLED with uL= YES = microlevel with doors - OPEN (default) active YES = microlevel with doors - CLOSED disabled hydraulic: safety circuit control active 27 / 52 MP2-NR/ND - Rev. 1.0...
  • Page 28 (AUX) with start in GV ignores the next floor with AUX set does not change destination disabled monitor repeated releveling (yo-yoing) active disabled with EN81-20/EN81-50 standard: car door aux contact control active 28 / 52 MP2-NR/ND - Rev. 1.0...
  • Page 29 BOARD) if serial, ignored if parallel (used as photocell) compatible with old MP2 Overload input J13-6 on MP2 board Overload on configurable Xcab input Both inputs can be used with separate S.r. functions. 29 / 52 MP2-NR/ND - Rev. 1.0...
  • Page 30 7 segments 0 to 7 floor display offset serial display 0 to 7 floor display offset special binary IGV 0 to 7 floor display offset 30 / 52 MP2-NR/ND - Rev. 1.0...
  • Page 31: Further Board Functions

    To activate the manoeuvre, press ENT/RST once, close the safety chain: 1. the car starts moving up and down; 2. if any calls are made, they are handled in the normal manner; 3. once the limit of 50 is reached, the process terminates; 31 / 52 MP2-NR/ND - Rev. 1.0...
  • Page 32: Le Selection - Fault Log Reading

    4.4.5. PA selection - Commissioning 1. After activation, PA flashes on the display; 2. this allows the car to be moved in maintenance mode, having supplied only D4; 3. it is deactivated when the command is repeated. 32 / 52 MP2-NR/ND - Rev. 1.0...
  • Page 33: Diagnostics

    Connection to GND and thermistor resistance value and any other contact wired in series on the same circuit. • Direct wiring to GND (without thermistors). • Control cabinet ground connection of main line. 33 / 52 MP2-NR/ND - Rev. 1.0...
  • Page 34 No opening of the door closure limit switch. • With the operator power and running disconnect the door closure contact from input J11/3 (DRA, led IC) or, if double access, contact J11/4 (DRB, led ID). 34 / 52 MP2-NR/ND - Rev. 1.0...
  • Page 35 When the car arrives at the floor inputs UM (M2A/2) and DM (M2A/3 ) are missing on the board. Rope, 1 or 2 speeds: the car resets. Verify: • Brake regulation. • Magnetic strip position. • Slowdown distance. 35 / 52 MP2-NR/ND - Rev. 1.0...
  • Page 36 (m/s) by 20 seconds; if the result is greater, the timer t0 must be adjusted or a dummy floor must be created. • Operation of the UM / DM reed switches. • Magnetic strip position. 36 / 52 MP2-NR/ND - Rev. 1.0...
  • Page 37 • Variable speed drive: brake regulation (opening and compression). Other contact checks: • • Safety chain contacts between inputs J7/4 (D1, led D1) and J7/6 (D2, led D2): see control cabinet wiring diagram 37 / 52 MP2-NR/ND - Rev. 1.0...
  • Page 38 The up/down board control signals at outputs J8/2(S, led S) and J8/3(D, led D). • The reciprocal contacts in series with the up (S)/down(D) contactors. • The up (S) / down (D) contactor coils. 38 / 52 MP2-NR/ND - Rev. 1.0...
  • Page 39 For system in public service, the car, when reset after out of service, is moved to the top floor, in automatic, and executes all calls travelling downwards and monitors door opening. If the sequence does not complete successfully, an error is reported. (NR) Flash memory programming error Er-40 • Replace the MP2 board. 39 / 52 MP2-NR/ND - Rev. 1.0...
  • Page 40 Serial communication to car boards error Er-73 Communications error with MP8120 board Er-74 X-Door board/s communication error Er-75 Machine local temperature error (with serial system and overload input set on "XCAB and MP, Er-76 input J13-6) 40 / 52 MP2-NR/ND - Rev. 1.0...
  • Page 41 Landing door lock contacts. (NR) The bypass relay does not excite Er-88 No excitation of the jumper test relay/contactor on the car doors and door locks. Verify: • Operation of the PPCS contactor. 41 / 52 MP2-NR/ND - Rev. 1.0...
  • Page 42 RIDB STAYS CLOSED WITH CAR AT LOWEST FLOOR (bistable lowest floor inspection ramp down Er-E6 switch) Checking the operation of RIDB. (NR) RISB STAYS CLOSED WITH CAR AT HIGHEST FLOOR (bistable highest floor inspection ramp down Er-E7 switch) Checking the operation of RISB. 42 / 52 MP2-NR/ND - Rev. 1.0...
  • Page 43: Board Functions And Layout

    The two reed switch contacts (RZA / RZB) are contained in the same housing and, in combination with a single magnetic strip per floor, actuate the safety circuit which defines and enables: • Hydraulic: the releveling/door pre-opening zone. • Rope: the door pre-open and/or releveling zone. 43 / 52 MP2-NR/ND - Rev. 1.0...
  • Page 44: Dms / Dmd Reed Switch Contacts

    + 12 stops Collective down (simplex/duplex/triplex/quadruplex) + 12 stops EXP - D Complete collective manoeuvre (up and down) simplex/duplex/triplex/ + 8 stops quadruplex IMPORTANT The maximum number of available stops for the expansions is 32 44 / 52 MP2-NR/ND - Rev. 1.0...
  • Page 45: P2C Minirelay Position Boards (With Decimal Output - One Row Per Floor)

    Two versions existing: DUPLO - 20 For connection with a 20 pole cable to the MP2 board DUPLO - 16 For connection with a 16 pole cable to the EXP expansion boards 45 / 52 MP2-NR/ND - Rev. 1.0...
  • Page 46: Tpx Connection Diagram

    • Position Indicator outputs (Connector M19) • Direction Indicator outputs (Connector M5) • Overload signalling output (Connector M7) • Gong signalling output (Connector M9) • 4 outputs configurable via QuickUp APP (Connector M7) 46 / 52 MP2-NR/ND - Rev. 1.0...
  • Page 47 MP2-NR/ND USER, MAINTENANCE AND INSTALLATION MANUAL 1. Additional inputs 2. FLDISP or similar for Display 3. Other car calls 47 / 52 MP2-NR/ND - Rev. 1.0...
  • Page 48: X-Door Board

    • Limit switch input (connector M9) • Car doors auxiliary contact input EN 81.20 (connector M10) • Operator clean controls output (connector M2) • Nudging command output (connector M3) From XCAB board From XCAB board 48 / 52 MP2-NR/ND - Rev. 1.0...
  • Page 49: Mp8120 Board

    ▪ Lower floor emergency lock contact input (M1) ▪ BF1 pit maintenance control panel input (M2) ▪ Pit access memory reset key input (M3) ▪ Pit semaphore output (J4) OUT_RED LED OUT_GREEN LED 6.5. MP2-NR/ND board layout 8.8. 49 / 52 MP2-NR/ND - Rev. 1.0...
  • Page 50: Leds On Mp2-Nr/Nd Board

    MP2-NR/ND USER, MAINTENANCE AND INSTALLATION MANUAL 6.5.1. LEDs on MP2-NR/ND board Indication Description o u t p u t / Input board/program active indication J4/4 universal manoeuvre: floor calls common minirelay RL1 collective manoeuvre: down direction...
  • Page 51: Manoeuvres

    M2A/6 Bistable phase plugs J13/6 J13/5 J13/6 J13/1 Configurable outputs J13/ 3 Configurable outputs J13/2 Configurable outputs 6.6. Manoeuvres 6.6.1. Single call manoeuvre or collective down manoeuvre 6D 8D 1C 3C 7D 9D 51 / 52 MP2-NR/ND - Rev. 1.0...
  • Page 52: Collective Up/Down Manoeuvre

    • To facilitate routing the flat cables in Triplex and Quadruplex systems, the TPX boards are used (installed in cabinet B for Triplex systems and cabinets B and C in Quadruplex systems). IMPORTANT Manual The tests are detailed in Par. 7 "System Tests" in the for the system in question. 52 / 52 MP2-NR/ND - Rev. 1.0...
