Kathrein UFS 932 Operating Instructions Manual

Quick Links

Download this manual

Operating instructions part 1

Connection and Setup

Safety Instructions - Important Notes ....................................................................................................... 2

Scope of supply ........................................................................................................................................... 5

Connection and setup ................................................................................................................................. 6

Front/rear view of the receiver (front flap open) .......................................................................................... 6

Inserting batteries into the remote control ................................................................................................... 8

Connecting the receiver .............................................................................................................................. 9

TV connection ............................................................................................................................................. 9

Audio connection ....................................................................................................................................... 10

Digital .......................................................................................................................................................................... 10

Analogue ..................................................................................................................................................................... 10

Connecting up the Video/DVD recorder .................................................................................................... 10

First Installation ......................................................................................................................................... 11

Common Interface (CI) .............................................................................................................................. 20

Inserting the HD+ card in the smart card reader ......................................................................................................... 20

Inserting the smart card and the CA module ............................................................................................................... 21

Troubleshooting ........................................................................................................................................ 22

Service ........................................................................................................................................................ 23

Technical appendix ................................................................................................................................... 24

Advanced connection example ................................................................................................................. 24

Technical Specifications ............................................................................................................................ 25

Sat IF connection examples ...................................................................................................................... 26

Individual reception systems ....................................................................................................................................... 26

Community antenna network systems (4 x Sat IF) ...................................................................................................... 26

Community antenna network systems (8 x Sat IF), multi-feed .................................................................................... 27

Community antenna network systems (16 x Sat IF), multi-feed .................................................................................. 27

Single cable systems ................................................................................................................................................... 28

If you do not know the conﬁ guration of your satellite reception system, contact your

specialist dealer for the ﬁ rst installation of your receiver.

UFS 932

English

Need help?

Do you have a question about the UFS 932 and is the answer not in the manual?

Questions and answers

Summary of Contents for Kathrein UFS 932

Page 1: Table Of Contents
Operating instructions part 1 UFS 932 Connection and Setup English Safety Instructions – Important Notes ....................... 2 Scope of supply ............................5 Connection and setup ..........................6 Front/rear view of the receiver (front flap open) ..................6 Inserting batteries into the remote control ....................8 Connecting the receiver ..........................
Page 2: Safety Instructions - Important Notes
Safety Instructions – Important Notes These two pages contain important information about operation, installation location and connection of the unit. Read these instructions carefully before setting up the unit. Mains cable Moisture, direct sunlight, heat, naked ﬂ ames Make sure that the mains cable Protect the unit against moisture, (power supply cable) is not damaged.
Page 3 Safety Instructions – Important Notes Electronic equipment is not domestic Repairs waste - it must be disposed of properly Ensure that any repairs to your unit in accordance with directive 2002/96/EC are carried out by qualiﬁ ed personnel. OF THE EUROPEAN PARLIAMENT Opening the unit and attempting to Important AND THE COUNCIL dated 27...
Page 4: Switching The Receiver Off
(e.g. changes to the menus and/or functions), if we believe it necessary we will make available a new operating manual for download under “www.kathrein.de”. Make a note of the receiver's basic settings (these are set during the ﬁ rst installation), so you can restore...
Page 5: Scope Of Supply
Scope of supply ■ UFS 932 ■ 2 batteries AAA 1.5 V ■ Operating instructions (part 1 and part 2) ■ HD+ smartcard ■ Remote control RC 674 ■ Safety instructions (multi-lingual) ■ HDMI cable ■ HD+ ﬂ yer The accessories supplied may differ in appearance from those illustrated!
Page 6: Connection And Setup
Connection and setup Front/rear view of the receiver (front ﬂ ap open)
Page 7 Connection and setup Front: Rear view: On/Off (operation/stand-by) LNB loop-through input 4-character numeric display LNB input Channel selection button (-) Audio outputs (L/R) - cinch sockets Channel selection button (+) 3 x Cinch connections for component outputs YUV labelled = Y/Pb/Pr Card reader (Nagravision integrated - for HD+ card) Video output (composite colour)
Page 8: Inserting Batteries Into The Remote Control
Connection and setup Inserting batteries into the remote control Remove the cover on the rear of the remote control. Insert the two batteries supplied into the remote control. Ensure correct polarity of the batteries; the + and – markings as indicated inside the battery compartment. Slide the cover back onto the housing until it locks in place.
Page 9: Connecting The Receiver
Connection and setup Connecting the receiver If you do not know the conﬁ guration of your satellite reception system, contact your specialist dealer. Connect the Sat IF inputs on the receiver to the satellite reception system. Use coaxial cable with an F standard connector (see illustration on right). Conventional DiSEqC™...
Page 10: Audio Connection
Connection and setup Audio connection Digital There are two ways you can access the digital audio. HDMI The stereo audio is transmitted to your TV set via the HDMI interface. If your TV set also supports Dolby Digital, you can also receive the Dolby Digital audio via the HDMI interface (providing it is broadcast by the channel provider).
Page 11: First Installation
Always pay attention to the bar at the bottom of the on-screen display. This provides information on what to do next.  Use the buttons to select the desired menu language for your UFS 932 and conﬁ rm your selection  using the button.
Page 12 Connection and setup The following languages are available: German, English, French, Italian, Spanish, Czech, Dutch, Polish Turkish and Russian.  Press the (green) button to move to the next menu. The following on-screen display appears:  Here you can use the buttons to select the correct local time setting (e.g.
Page 13 Connection and setup TV Aspect Ratio Here you can select the TV picture format. Either - 4:3, - 16:9 or - Auto Scaling Method Here you can select the screen display mode: - TV Scale The format transmitted by the programme provider is used - Letterbox: The picture is reduced to suit the TV screen (there may be black bands above and below it) - Pan &...
Page 14 Connection and setup The following on-screen display appears: The settings for the tuner conﬁ guration should be perfo rmed by a specialist engineer for this reception system. Tipp! If your receiver is connected as in the connection example (see “Connecting the receiver” in this section), no changes are necessary for the remainder of the ﬁ...
Page 15 Connection and setup LNB only Select Satellite  Use the buttons here to select the satellite whose signal is present at the tuner. LNB Type  If your reception system does not have a Universal LNB, use the buttons to select the LNB types that are used in your reception system.
Page 16 Connection and setup LNB Power This is factory-set to “On”, but must be changed if your LNB has its own power supply. In most cases the LNB power supply is provided by the receiver. (Test) transponder (TP) Select the selection ﬁ eld “TP”. Here you can select a transponder for checking whether your settings are correct using the signal strength bar and signal quality bar.
Page 17 Connection and setup DiSEqC™1.0 Select satellite and port (satellite slot) Here you can select the satellites whose signals you wish to receive. Select only those satellites that are present in the signal at the tuner. You can set up a maximum of four satellites. ...
Page 18 Connection and setup Single Cable System If you use a UAS 481 (single cable LNB) in your reception system, you are only allowed to select one satellite. Select satellite and port (satellite slot) Here you can select the satellites whose signals you wish to receive. Select only those satellites that are present in the signal at the tuner.
Page 19 Connection and setup (Test) transponder (TP) Select the selection ﬁ eld “TP”. Here you can select a transponder for checking whether your settings are correct using the signal strength bar and signal quality bar.  When you have completed all settings, press the (green) button.
Page 20: Common Interface (Ci)
  The smart card reader (small slot) on the UFS 932 (Nagravision embedded) is intended to be used for the HD+ card. The smart card reader is behind the ﬂ ap on right on the front underneath the Common Interface (large slot).
Page 21: Inserting The Smart Card And The Ca Module
Inserting the CA module into the CI  The Common Interface (CI+) of the UFS 932 is suitable for insertion of a CI+ module (or CA module) and   is located on the front panel of the receiver (behind the ﬂ ap). The CA module accepts the smart card ...
Page 22: Troubleshooting
Troubleshooting In the event of a malfunction, ﬁ rst check all the cable connections and operating states: 1. Receiver and TV set power plugs are connected to wall socket 2. Antenna cables are connected to the receiver input 3. Receiver and TV set correctly connected by a HDMI or Scart cable 4.
Page 23: Service
Service If, despite studying this operating manual, you still have questions about getting started with the unit or using it correctly, or if unexpected problems occur, please contact your specialist dealer. The Kathrein customer hotline is also at your disposal.
Page 24: Technical Appendix
Technical appendix Advanced connection example Hi-ﬁ system External hard disk Cinch (YPbPr) Scart Dolby Digital system...
Page 25: Technical Specifications
Technical appendix Technical Speciﬁ cations Type UFS 932si/HD+ UFS 932sw/HD+ Order no./colour 20210188/silver 20210189/black RF section Sat IF band 950-2150 Input level band dBμV 44-83 TV system, video Modulation, FEC, demultiplexer DVB-S-/DVB-S2 standard CCIR 601 (720 x 576 lines), 576i, 576p, Video resolution 720p, 1080i, 1080p Video decryption...
Page 26: Sat If Connection Examples
Technical appendix Sat IF connection examples Individual reception systems UAS 571 ESD../ESC.. Signal 1 Signal 2 Position OPTION Sat IF Sat-ZF EXR 21 950-2150 MHz Community antenna network systems (4 x Sat IF) Sat IF Sat IF Overvoltage protection KAZ 11/KAZ 12...
Page 27: Community Antenna Network Systems (8 X Sat If), Multi-Feed
Technical appendix Community antenna network systems (8 x Sat IF), multi-feed Sat IF Community antenna network systems (16 x Sat IF), multi-feed Sat IF Sat IF Sat IF Sat IF Overvoltage protection KAZ 11/KAZ 12...
Page 28: Single Cable Systems
Technical appendix Single cable systems Sat IF Overvoltage protection KAZ 11/KAZ 12...
Page 29 Technical appendix Sat IF Sat IF Overvoltage protection KAZ 11/KAZ 12...
Page 30: For Your Notes
For your notes...
Page 31 For your notes...
Page 32 936.4068/-/ZWT/0311/d - Subject to changes! Internet: www.kathrein.de KATHREIN-Werke KG • Anton-Kathrein-Str. 1 - 3 • P.O. Box 100 444 • 83004 Rosenheim • GERMANY • phone +49 8031 184-0 • Fax +49 8031 184-385...
