Page 1 Virtuo Evolve 150 Virtuo Evolve 150/2 Virtuo Evolve 150/3 Installation manual Store this document in a safe place 959.143.01...
Page 2 This product is not suitable for use as primary heating.
Page 3 What could be more inviting than a glowing cosy real flame? Whether you prefer a classic or a sleek design, at DRU you will find your ideal gas fire. Thanks to our knowledge and expertise - we can rely on 270 years’ experi-...
Page 4 INSTALLATION MANUAL Index 1. Introduction 2. EU/UKCA - Declaration of conformity 3. Step-by-step installation plan 4. Technical data 5. Safety 5.1 General 5.2 Regulations 5.3 Safety instructions 6. Preparation 7. Installation 7.1 Placing the appliance 7.2 Placing the chimney breast 7.3 Additional installation options 7.3.1 Platform combined with lower decorative strip 7.3.2 Platform adjacent to the glass...
Page 5 INSTALLATION MANUAL Heating element Electric connection “10.2 Heating element” P. 48 “8.6 Electric connection” P. 32 Electrical control unit Front glass pane Side panes “8.1 Glass panes” P. 26 “8.1 Glass panes” P. 26 Projection plate Construction frame “8.2 Projection plate” P. 28 “7.
Page 6 1. Introduction 38D-0001 DRU, a manufacturer of gas-fired and electric stoves, develops and produces products that comply with the highest quality, performance and safety requirements. For that reason, this appliance has a CE label, which means that it complies with the essential requirements of the European directives. The appliance is supplied with a combined installation manual and user manual.
Page 7 This declaration loses its validity if changes are made to the appliance without written permission from DRU. The instructions in the manuals must also be observed at all times. A copy of the EU test certificate can be downloaded via druservice.com...
Page 8 INSTALLATION MANUAL 3. Step-by-step installation plan The major points of attention of the installation are described in the check list below. Perform these steps and tick them once they have been performed correctly. After ticking all the steps, the appliance will be ready for use. Carefully read the manual before the appliance is installed PREPARATION &...
Page 9: Technical Data
Ratio 8 | 6921 RW | Duiven, The Netherlands www.drufire.com PO Box 1021 | 6920 BA Duiven Item Virtuo Evolve 150 / Virtuo Evolve 150/2 / Virtuo Evolve 150/3 Heat output Type of heat output/ room temperature control Single stage heat output and no room...
Page 10: Safety Instructions
INSTALLATION MANUAL 5. Safety 38D-0002 5.1 General Observe the generally applicable regulations and precautions/safety instructions in this manual. - First check that the technical execution of the appliance to be installed is correct (table 4-1). - Read this manual carefully to ensure the proper and safe installation of the appliance. - Observe the regulations/instructions in this manual.
Page 11 INSTALLATION MANUAL 6. Preparation 38D-0003 Note the following items when removing the packaging: Remove all packaging and protective materials. Take away all supplied parts in, on and/or attached to the appliance. Check the appliance and accessories for (transport) damage. Contact the supplier if necessary. Never install an appliance that is damaged! Remove the screws and brackets that secure the device to the pallet.
Page 12: Installation
INSTALLATION MANUAL 7. Installation 38D-0010 7.1 Placing the appliance Separate sections describe different ways of placing the appliance. The general description below for placing the appliance applies to all these sections: Place the appliance on the location where it will be installed and take the following into account: - The construction dimensions of the appliance (fig.
Page 13: Placing The Chimney Breast
INSTALLATION MANUAL 7.2 Placing the chimney breast The appliance must be built in by means of a chimney breast. It is important to ensure that the appliance does not act as a supporting element and that the correct drying time of the used finishing materials are taken into account. Follow the instructions and warnings below: - The appliance must always be built in, by means of a chimney breast (see section 7).
Page 14 INSTALLATION MANUAL Virtuo Evolve 150 1515 1500 38C-2959 7 - 3 Virtuo Evolve 150 min. 1594 min. 240 ≤100 1519 min. 115 38C-2963 7 - 4...
Page 15 INSTALLATION MANUAL Virtuo Evolve 150 1519 1519 ≥20 1519 1519 ≥70 38C-2961 7 - 5...
Page 16 INSTALLATION MANUAL Virtuo Evolve 150/2 38C-3034 7 - 6 Virtuo Evolve 150/2 ≥1557 ≥240 ≤100 ≥115 38C-3034 7 - 7...
Page 17 INSTALLATION MANUAL Virtuo Evolve 150/2 1530 1530 1515 1515 38C-3035 7 - 8...
Page 18 INSTALLATION MANUAL Virtuo Evolve 150/3 1590 1650 1500 38C-2960 7 - 9 Virtuo Evolve 150/3 min. 1594 min. 240 ≤100 min. 115 38C-2963/3 7 - 10...
Page 19 INSTALLATION MANUAL Virtuo Evolve 150/3 1540 1540 1510 1510 38C-2962 7 - 11...
Page 20: Additional Installation Options
INSTALLATION MANUAL 7.3 Additional installation options 38D-0011 It is possible to finish the chimney breast in several ways. Use the instructions outlined in the following (sub)paragraphs in combination with their corresponding measurements. (Structural) materials that are adjacent to the glass pane should be able to resist temperatures of at least 85°C. 7.3.1 Platform combined with lower decorative strip Observe the instructions below for building a platform with visible lower decorative strip: Create a recess in the platform, in which the appliance will be placed:...
Page 21 INSTALLATION MANUAL 7.3.2 Platform adjacent to the glass To connect the platform to the glass pane, the decorative strip should be lowered. Take the following into account: - Do not allow the weight of the platform to rest on the appliance and/or lower decorative strip. - (Structural) materials that are adjacent to the glass pane should be able to resist temperatures of at least 85°C.
Page 22 INSTALLATION MANUAL 7.3.3 Side wall adjacent to the glass In case of a /1 and /2 appliance, it is possible to have the side wall of the chimney breast adjacent to the glass pane (fig. 7-16). For this, proceed with the following instructions: (Structural) materials that are adjacent to the glass pane should be able to resist temperatures of at least 85°C.
Page 23 INSTALLATION MANUAL 38C-2843-01 7 - 15 ≥5mm 38C-2847 7 - 16...
Page 24 INSTALLATION MANUAL 7.3.4 Back wall adjacent to the glass In case of a /2 and /3 appliance, it is possible to have the back wall of the chimney breast adjacent to the glass pane (fig. 7-19). For this, proceed with the following instructions: (Structural) materials that are adjacent to the glass pane should be able to resist temperatures of at least 85°C.
Page 25 INSTALLATION MANUAL 38C-2844 7 - 18 ≥5mm 38C-2848 7 - 19...
Page 26: Glass Panes
INSTALLATION MANUAL 8. The appliance 38D-0004 8.1 Glass panes The wood set and monitor(s) are supplied separately. These can be fitted after the glass panes and projection plate are removed. After placement of the wood set, projection plate and monitor(s) (see sections 8.2, 8.3 and 8.4), it is possible to place the glass panes: Avoid damaging the glass panes during removal/placing.
Page 27 INSTALLATION MANUAL 38C-2835 8 - 1...
Page 28 Wear the supplied cotton gloves during the cleaning process in order to prevent the introduction of new contamination. - Dust on the projection plate: a clean feather duster or oil-free compressed air. - Contamination on the projection plate: DRU Spray 2 with a clean microfibre cloth.
Page 29 INSTALLATION MANUAL 38C-2836 8 - 2...
Page 30 INSTALLATION MANUAL 8.3 Metal triangle The metal triangles are optional and are supplied with the three-sided appliances. These can be placed once the front glass pane and projection plate have been removed. Avoid damaging the glass panes and projection plate. 8.3.1 Placing the metal triangle Take the metal triangle and place it with the slanted side forwards.
Page 31 INSTALLATION MANUAL 8.4 Monitors 38D-0005 To prevent transport damage to the monitors, they are delivered separately in protective packaging. Follow these steps to install the monitors in the appliance: Always work on a voltage-free appliance to prevent damage to electronic components. Ensure that the appliance is voltage-free (See section 8.5).
Page 32: Main Switch
INSTALLATION MANUAL 8.5 Main switch 38D-0007 The appliance is provided with a main switch on the inside of the upper decorative strip (see fig. 8-5). This main switch can be used to switch off the entire electrical system of the appliance. The main switch does not make the appliance fully free from voltage.
Page 33 INSTALLATION MANUAL 0.1 - 0.5 M 38C-2834/02 8 - 5...
Page 34 INSTALLATION MANUAL 8.7 Log set The appliance comes with a log set consisting of: logs, wood chips, chips, coals and glowing embers. Place them exactly as described for an optimum operation of the appliance. - In the figures, the colour is not always shown correctly. - Only use the supplied log set, chips and glowing embers.
Page 35 INSTALLATION MANUAL P2081 KL04 P2082 KL12 P2083 KL12 P2084 KL11 P2078 KL04 P2067 KL04 Front Back Front Back (2x) P2085 KL13 P2078 KL04 P2086 KL04 P2064 KL04 P2066 KL04 38P-1041 8 - 8...
Page 36 INSTALLATION MANUAL Step 2 Take log A and place it on the three small positioning cams in the centre rear of the stove (fig 8-10 en 8-11A). Then take log B and place it diagonally on the positioning cams in the middle left rear and middle left front (fig.
Page 37 INSTALLATION MANUAL 38P-1049 8 - 11...
Page 38 INSTALLATION MANUAL Step 3 Place log D on the positioning cam on the left on the glow bed. The positioning cam at the bottom right on log D falls into the recess on log B (fig 8-13 and 8-14D). Place log E on the positioning cam on the right on the glow bed. The positioning cam at the bottom left on log E falls into the recess on log C (fig.
Page 39 INSTALLATION MANUAL ±40mm ±20mm 38P-1053 8 - 14...
Page 40 INSTALLATION MANUAL Step 4 Place log G on the positioning cam on the front right of the glow bed. The positioning cam at the bottom left on log G falls into the recess on log C (fig 8-16 and 8-17G). Place log H to the rear left, in back of log E as shown in (figure 8-16 and 8-17H).
Page 41 INSTALLATION MANUAL ±100mm ±25mm 38P-1054 8 - 17...
Page 42 INSTALLATION MANUAL Step 5 Place log K at the back to the right, between logs D and E (fig. 8-19 and 8-20 K). The end of this log is aligned with the raised section of the glow bed. Place log J at the back to the right, between logs D and K (fig. 8-19 and 8-20 J). The top of log J is parallel with log D. 38P-1052 8 - 18 38P-1046...
Page 43 INSTALLATION MANUAL ±100mm ±120mm ±70mm 38P-1055 8 - 20...
Page 44 INSTALLATION MANUAL Step 6 Spread out the complete set of glowing embers (L) across the glow bed of the appliance, covering the entire elevated transparent part of the bottom. Here, it is important that the glowing embers connect properly to the logs and completely cover the transparent part of the glow bed.
Page 45 INSTALLATION MANUAL Step 8 Take the coals (M) and spread them out in a playful and natural looking way between the glowing embers and chips. Divide a few coals on top of the glowing embers (fig. 8-23). Make sure that no chips or other materials protrude over the edge. This could make it impossible to place the projection plate or glass pane or cause damage to these items (fig.
Page 46 INSTALLATION MANUAL Step 9 Evenly spread out the wood chips across the glow bed. Ensure an optimum bottom covering, particularly by placing chips of different sizes next to one another at the front of the fire (fig. 8-25). 38P-1065 8 - 25 Step 10 After placing the log set and projection plate, check the flame picture and adjust the placement of the logs where necessary.
Page 47 INSTALLATION MANUAL...
Page 48: Final Check
INSTALLATION MANUAL 9. Final check 38D-0008 For a good and safe operation of the appliance, the following checks must be performed prior to commissioning. Familiarise the end user with the appliance. Instruct him about using it for the first time, the safety measures, how the remote control works and the recommended annual maintenance.
Page 49: End Of Life / Recycling
INSTALLATION MANUAL 10.3 Parts Components that have to be replaced are available at the supplier. For a proper execution of maintenance, some parts must be disassembled from the appliance. This should be done with the greatest care to prevent damage to electric and mechanic components as well as visible sections of the appliance. It is recommended to have the appliance checked, cleaned and, if necessary, repaired once per year by a skilled installer.
Page 50 INSTALLATION MANUAL 12. Malfunctions 38D-0009 In case of poor operation of the appliance, consult the following overview of malfunctions. Does it not contain your malfunction? Remove the plug from the socket and contact your dealer. Do not open the appliance yourself and do not make changes yourself. Always leave this to a recognised electrical installer.
Page 51 INSTALLATION MANUAL Table 12-1: Malfunctions Malfunction Solution(s) The appliance does switch on, but • Switch the appliance off and on by making it free from voltage using the main the heating does not switch on. switch. Switch the main switch as described in user manual section 3.3. •...
Page 52 DRU Verwarming B.V. BY APPOINTMENT OF PO Box 1021 | 6920 BA Duiven THE COURT OF THE NETHERLANDS Ratio 8 | 6921 RW Duiven The Netherlands +31 (0)26 - 319 5 319 www.drufire.com...
