- Page 1 18” OSCILLATING WALL FAN MODEL NO: CWFO18 PART NO: 3231546 OPERATION & MAINTENANCE INSTRUCTIONS ORIGINAL INSTRUCTIONS DL0125...
-
Page 2: Environmental Recycling Policy
GUARANTEE This CLARKE product is guaranteed against faulty manufacture for a period of 12 months from the date of purchase. Please keep your receipt as proof of purchase. -
Page 3: Safety Precautions
SAFETY PRECAUTIONS 1. ALWAYS read this manual before use. 2. DO NOT use outdoors. Suitable for indoor use only 3. DO NOT use in environments containing chemical fumes etc. 4. DO NOT use as an extractor fan or connect to a duct system. 5. -
Page 4: Electrical Connections
ELECTRICAL CONNECTIONS WARNING! READ THESE ELECTRICAL SAFETY INSTRUCTIONS THOROUGHLY BEFORE CONNECTING THE PRODUCT TO THE MAINS SUPPLY. This product may be fitted with a non-rewireable plug. If it is necessary to change the fuse in the plug, the fuse cover must be refitted. If the fuse cover becomes lost or damaged, the plug must not be used until a suitable replacement is obtained. -
Page 5: Overview - Components
OVERVIEW - COMPONENTS NO DESCRIPTION NO DESCRIPTION Motor Housing Rear Grill Fan Blade Hanging Wall Bracket Control Box Positioning Screw Front Grill Wall Bracket Fixings x 4 Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... -
Page 6: Installation
INSTALLATION CAUTION: USE THE FOLLOWING INFORMATION AS A GUIDELINE ONLY. IT IS THE USER’S RESPONSIBILITY TO BE SURE THE LOCATION AND THE WALL SURFACE CAN HANDLE THE WEIGHT OF THIS FAN. 1. Remove the four mounting screws from the motor housing (as shown). 2. - Page 7 8. Use the security screw and nut to tighten the fan grill in position. NOTE: DO NOT operate the fan without the guard being in place. 9. Confirm the wall fan height as needed, then mark the position of the hanging wall bracket will be located using the four screw holes, as shown.
- Page 8 15. Hang the control box on a screw using the hanging hole in the back of the box. NOTE: To prevent damage to the control box cord and motor, the distance between the control box and the wall bracket should be no more than 50cm.
-
Page 9: Maintenance
This fan has a thermal cut out safety device built in. If it activates, turn off the power and let the fan cool for 5 minutes. Once cooled, turn the power back on and resume operation. If the problem persists, contact your local CLARKE service centre. MAINTENANCE WARNING: NEVER OPERATE THE FAN WITH THE FRONT GRILL REMOVED. -
Page 10: Specifications
SPECIFICATIONS MODEL CWFO18 Operating Voltage and Frequency 230 V AC (50Hz) Rated Input Wattage 100 W Rated Input Ampage 0.43 A Electrical Insulation Class Class I Duty Cycle Classification S1 - Continuous Ingress Protection (IP) Rating IP20 Operating Temperature Range... -
Page 11: Declaration Of Conformity
DECLARATION OF CONFORMITY Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... - Page 12 Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
