TP2 DRYERS DOSING MANUAL
ELECTRICAL ANALYSIS
DRYERS
SR/SR-2-11-18-23-28-36 TP2 (PLUS)
September 2020
V1.0 09/2020

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TP2 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Fagor TP2 Series

Summary of Contents for Fagor TP2 Series

  • Page 1 TP2 DRYERS DOSING MANUAL ELECTRICAL ANALYSIS DRYERS SR/SR-2-11-18-23-28-36 TP2 (PLUS) September 2020 V1.0 09/2020...
  • Page 2 V1.0 09/2020...

  • Page 3: Table Of Contents

    Explanation of the dosing system ............4 1.1. What is it? ......................4 1.2. How does it work? ....................5 Installation of the kit ................. 6 2.1. General considerations ..................6 2.2. Which KIT do I need? ..................6 2.3. Tools required for the installation ..............

  • Page 4: Explanation Of The Dosing System

    EXPLANATION OF THE DOSING SYSTEM 1.1. What is it? The dryer dosing system is a kit which can be ordered from the factory or installed at a later date in any dryer with a touch programmer. It consists of a fragrance chamber, a drive pump and a spray. The system impregnates the laundry with a fragrance at the end of the cycle, allowing the customer to remove the clothing with the scent chosen by the owner.

  • Page 5: How Does It Work

    1.2. How does it work? The fragrance is sprayed through a spray nozzle above the drum so that is combines with the incoming air. As the air passes through the contents of the drum, the laundry is impregnated with the fragrance. Spray nozzle Cabinet with fragrance bag and drive pump...

  • Page 6: Installation Of The Kit

    2. INSTALLATION OF THE KIT 2.1. General considerations The kit should be installed leaving a space away from the wall at the rear for the replacement of the fragrance bag/bottle. 2.2. Which KIT do I need? The industrial dryers can be configured with different options. Therefore, different kits are available to suit all the models.

  • Page 7: Tools Required For The Installation

    2.3. Tools required for the installation The following are required for the installation: PE4 Allen key 13 mm drill bit 25 mm crown drill bit Pliers Flat-head and Phillips screwdrivers...

  • Page 8: Contents Of The Kits

    2.4. Contents of the kits 2.4.1. Kit for 10 to 80 kg TP2industrial dryers All the kits come with a rear dryer panel and a fragrance diffuser. The fragrance diffuser contains all the components necessary for the installation of the kit. Certain components are supplied pre-installed. The remaining components are included in a bag.
  • Page 9 Straight pipe fitting Spray 12269171 12257152 Connection strip + Cable Injector support Keys (included in dosing cabinet) 12135869 + 12149188 12269736 M5x15 Allen bolt 12149290 Plate bolt 12149216 5-litre dosing cabinet 12267576 Dispenser pump 12257131...

  • Page 10: Kit For Touch Ii Stack Industrial Dryers

    2.4.2. Kit for TP2 STACK industrial dryers The kits for stack dryers come with a rear dryer panel and a fragrance diffuser. The fragrance diffuser contains all the components necessary for the installation of the kit. Certain components are supplied pre-installed.
  • Page 11 Straight pipe fitting Spray 12269171 12257152 Connection strip + Cable Injector support Keys (included in dosing 12135869 + 12149188 12269736 cabinet) Plate bolt 12149216 M5x15 Allen bolt Connection plate 12149290 12268844 5-litre dosing cabinet 12267576 Dispenser pump 12257131...

  • Page 12: Installation In 10 To 18 Kg Tp2 Industrial Dryers

    2.5. Installation in 10 to 18 kg TOUCH II industrial dryers Remove the dryer panels. Remove the lid of the dryer. First turn the keys and then remove the bolts in the upper part of the panel.
  • Page 13 Mount the fragrance diffuser on the panel. It is necessary to drill holes in the upper part of the machine. Two holes are required. The first measures 25 mm and the second 13 mm. The holes are drilled as shown in the photos below: Ø13 Ø25...
  • Page 14 Now it is possible to install all the wiring and dosing pipes from the diffuser. The dosing pipe must be connected to the fragrance diffuser. The wiring of the dosing pump must be connected using the connection terminal strip supplied. This terminal strip can only be connected to IOS Full plates.
  • Page 15 The terminal strip is connected to the right of the fan contactor, together with the other strips already mounted. Install one end on the DIN rail. Install the other end on the plate. If you already have the connector, install the cable in the empty slot. Next connect the neutral and phase from the pump on the corresponding connectors.
  • Page 16 The earth wiring can be connected to any point of the existing connection. Once connected, it is possible to install the panel with the dosing system.

  • Page 17: Installation In 23 Kg Tp2 Industrial Dryers

    2.6. Installation in 23 kg TP2 industrial dryers Remove the dryer panels Remove the lid of the dryer. First turn the keys and then remove the bolts in the upper part of the panel. Mount the fragrance diffuser on the panel.
  • Page 18 It is necessary to drill holes in the upper part of the machine. Two holes are required. The first measures 25 mm and the second 13 mm. The holes are drilled as shown in the photos below: Ø13 Ø25...
  • Page 19 Now it is possible to install all the wiring and dosing pipes from the diffuser. The dosing pipe must be connected to the fragrance diffuser. The wiring of the dosing pump must be connected using the connection terminal strip supplied. This terminal strip can only be connected to IOS Full plates.
  • Page 20 The terminal strip is connected to the right of the fan contactor, together with the other strips already mounted. Install one end on the DIN rail. Install the other end on the plate. If you already have the connector, install the cable in the empty slot. Next connect the neutral and phase from the pump on the corresponding connectors.
  • Page 21 The earth wiring can be connected to any point of the existing connection. Once connected, it is possible to install the panel with the dosing system.

  • Page 22: Installation In 28 To 36 Kg Tp2 Industrial Dryers

    2.7. Installation in 28 to 36 kg TP2 industrial dryers Remove the upper dryer panel. Remove the door panel. The door is pressure-mounted. Just separate the door with the hinge by pulling on it. To mount it, proceed in the same way but insert it in the notches of the pin. Hinge 12165655...
  • Page 23 If the machine has a sprinkler system, it is necessary to remove the access plate to the solenoid valve.
  • Page 24 Mount the fragrance diffuser on the panel. It is necessary to drill holes at the rear of the dryer, at the separation point between the rear and front part. This is a 13 mm hole. Next install the injector with the support.
  • Page 25 Now it is possible to install all the wiring and dosing pipes from the diffuser. The dosing pipe must be connected to the fragrance diffuser. The wiring of the dosing pump must be connected using the connection terminal strip supplied. This terminal strip can only be connected to IOS Full plates.
  • Page 26 The terminal strip is connected to the right of the fan contactor, together with the other strips already mounted. Install one end on the DIN rail. Install the other end on the plate. If you already have the connector, install the cable in the empty slot. Next connect the neutral and phase from the pump on the corresponding connectors.
  • Page 27 The earth wiring can be connected to any point of the existing connection. Once connected, it is possible to install the panel with the dosing system.

  • Page 28: Installation In 45 To 80 Kg Tp2 Industrial Dryers

    2.8. Installation in 45 to 80 kg TP2 industrial dryers Remove the upper dryer panel. Remove the door panel. The door is pressure-mounted. Just separate the door with the hinge by pulling on it. To mount it, proceed in the same way but insert it in the notches of the pin. Hinge 12165655...
  • Page 29 If the machine has a sprinkler system, it is necessary to remove the access plate to the solenoid valve.
  • Page 30 Mount the fragrance diffuser on the panel. It is necessary to drill holes at the rear of the dryer, at the separation point between the rear and front part. This is a 13 mm hole. Next install the injector with the support. Now it is possible to install all the wiring and dosing pipes from the diffuser.
  • Page 31 The dosing pipe must be connected to the fragrance diffuser. The wiring of the dosing pump must be connected using the connection terminal strip supplied. This terminal strip can only be connected to IOS Full plates. Connection strip + Cable IOS FULL 12216475 plate 12135869 + 12149188 Only in Kit 12273766...
  • Page 32 The terminal strip is connected to the right of the fan contactor, together with the other strips already mounted. Install one end on the DIN rail. Install the other end on the plate. If you already have the connector, install the cable in the empty slot. Next connect the neutral and phase from the pump on the corresponding connectors.
  • Page 33 The earth wiring can be connected to any point of the existing connection. Once connected, it is possible to install the panel with the dosing system.

  • Page 34: Installation In Tp2 Stack Industrial Dryers

    2.9. Installation in TP2 STACK industrial dryers Remove the dryer panels. Mount the fragrance diffuser on the panel.
  • Page 35 It is necessary to drill holes at the rear of the dryer, at the separation point between the rear and front part. This is a 13 mm hole. Next install the injector with the support. Depending on the type of heating, this should be on the left or on the right. In gas-heated models, it is installed to the left of the battery.
  • Page 36 Now it is possible to install all the wiring and dosing pipes from the diffuser. The dosing pipe must be connected to the fragrance diffuser. wiring of the dosing pump must be connected using the connection terminal strip supplied. This terminal strip can only be connected to IOS Full plates. Connection strip + Cable IOS FULL 12216475 plate 12135869 + 12149188...
  • Page 37 The terminal strip is connected to the right of the fan contactor, together with the other strips already mounted. Install one end on the DIN rail. Install the other end on the plate. If you already have the connector, install the cable in the empty slot. Next connect the neutral and phase from the pump on the corresponding connectors.
  • Page 38 The earth wiring can be connected to any point of the existing connection. Once connected, it is possible to install the panel with the dosing system.

  • Page 39: Activation Of The Kit

    3. ACTIVATION OF THE KIT Once the kit has been installed, it must be activated in the programmer. This will enable the dosing stages and possible actions to be displayed. To do so, access the technical service menu. The method of access is different depending on whether the machine is in self-service mode or free mode (OPL).

  • Page 40: For Opl Mode

    When the key is turned, the dryer requests an access password. The factory setting for this code is 1234. If the code has been changed, consult the owner and/or person responsible for changing the code. From this point, proceed as shown below in For OPL mode.
  • Page 41 You will be asked to provide an access password. Enter the code 1357. Select the icon for the Kits. Activate the dosing kit.

  • Page 42: Bleeding The Pump

    4. BLEEDING THE PUMP Proceed as in point 3. Activation of the kit until reaching the technical service screen. Once in the menu, select the inputs and outputs icon. Select the output menu. Next: • Close the door • Close the filter If any of the above points are not completed, the next point will not function.
  • Page 43 Select the dose. If required, it is also possible to activate the fan to assist the extraction.

  • Page 44: Programmes For Dosage

    5. PROGRAMMES FOR DOSAGE 5.1. Description of the dosage cycle The dryer programmes are based on 3 different cycle types. • Drying cycle • Cooling cycle • Dosing cycle During the drying cycle, the laundry is dried using one or a combination of several cycles. Drying is possible in stages to ensure improved care of the laundry.
  • Page 45 The dosing cycle can be configured using 5 different parameters. Each parameter is described below. CYCLE EDITION SCREEN →Target dosing temperature (ºC/ºF). As soon as the temperature falls below this objective temperature, the dosage operation will take place. Min. 25 ºC, max. 60 ºC. →Dosing shake-up time (minutes).

  • Page 46: Standard Programmes Of The Dryer

    5.2. Standard programmes of the dryer By default, the dryer already has 7 programmes configured with the dosing cycle. These are identified with the termination “+ D” at the end of the programme. PROGRAMME WITHOUT DOSING PROGRAMME WITH DOSING The existing programmes are as follows: TYPE OF PROGRAMME NAME DOSAGE...

  • Page 47: Special Programmes

    5.3. Special programmes To improve the use of the dosing system, the personalised creation of programmes is recommended for each customer and type of use and the final fragrance strength required. Studies have been made in different working environments and certain guidelines have been established for each case as a reference for the creation of new programmes.

  • Page 48: Product Used

    6. PRODUCT USED 6.1. Product supplied by spare parts Spare parts supplies packs of 1.5-litre bags or packs of 4-litre bottles. One litre supplies approximately 80 drying cycles with a high degree of dosing. 1.5 litre bags (easy to insert in the compartment) PURCHASE Cardboard box with:...

  • Page 49: External Product

    The fragrances offered are as follows: ONNDRY SCENT 1 DESCRIPTION: Aqueous fabric fragrance for dryers. Floral fragrance with fruity notes. ONNDRY SCENT 2 DESCRIPTION: Aqueous fabric fragrance for dryers. Fresh fragrance with citrus and floral notes ONNDRY SCENT 3 DESCRIPTION: Aqueous fabric fragrance for dryers.

  • Page 50: Installation Of The Product

    6.3. Installation of the product The dosing cabinet comes with all the accessories necessary to connect the product either in the bottle or in the bag. To use the bottle, connect as shown in the photo below: To use the bag, connect as shown in the photo below:...
