TECHNICAL DATA
MODEL
SKU
OUTPUT
OUTPUT CURRENT
OUTPUT POWER
INPUT VOLTAGE
DIMENSION
REMOTE SIZE
CONNECTION MODE
NETWORK CONNECTION
WORKS WITH
INTRODUCTION & WARRANTY
Thank you for selecting and buying V-TAC LED CONTROLLER V-TAC will serve you the best. Please read
these instructions carefully before starting the installation and keep this manual handy for future reference.
If you have any other query, please contact our dealer or local vendor from whom you have purchased
the product. They are trained and ready to serve you at the best. The warranty is valid for 2 years from the
date of purchase. The warranty does not apply to damage caused by incorrect installation or abnormal
wear and tear. The company gives no warranty against damage to any surface due to incorrect removal
and installation of the product. The products are suitable for 10-12 Hours Daily operation. Usage of prod-
uct for 24 Hours a day would void the warranty. This product is warranted for manufacturing defects only.
NOTE
• This device requires Wi-Fi Frequency 2.4Ghz
• Operating frequency (maximum transmitted power) 2.412-2.484Ghz
INSTRUCTION MANUAL
SMART LED CONTROLLER
VT-2427
2902
2 Channels
<6A
72-144W
DC: 12V/24V
59.2x24x10mm
86x40x7mm
Common Anode
Powered on& o for
3 times and the light
flashes quickly
works with the
Google Assistant
WEEE Number: 80133970
Advertisement
Related Manuals for V-TAC VT-2427
Summary of Contents for V-TAC VT-2427
- Page 1 Google Assistant INTRODUCTION & WARRANTY Thank you for selecting and buying V-TAC LED CONTROLLER V-TAC will serve you the best. Please read these instructions carefully before starting the installation and keep this manual handy for future reference. If you have any other query, please contact our dealer or local vendor from whom you have purchased the product.
- Page 2 • Make sure before plugging in that the led light voltage is suitable for configuration with this product. • This product is suitable for products manufactured by the company V-TAC, when connected with products of other companies, V-TAC is not responsible for any adverse consequences for your health.
- Page 3 APP INSTALLATION INSTRUCTIONS Step 1: Turn the power button ON of the device. Then Smart Life follow the below instruction for the device. Step 2: Scan the given QR code, or download “Smart Life’ from the App Store (iOS) or the Google Play Store (Android).
- Page 4 Step 8: To pair the device with LED Smart Strip Light make sure the light is blinks rapidly. Once the light blinks rapidly, the light is in pairing mode. If the light is not blinking rapidly, you can do one of the following steps: A.
- Page 5 Step 11: A er successfully pairing the Wi-Fi receiver with the app, you can start controlling multiple features of the lamp through your mobile– on/o switch, timing & schedules, and more. GOOGLE ASSISTANT SETTINGS • Install the Google Assistant app via the App Store (iOS) or the Play Store (Android) and register. If you already have an existing account with Google Assistant, please proceed to logging in.
-
Page 6: Smart Life
• Once you are on the Google home page, tap on the Add “+” icon– to add a new device and skill. And then tap on Set up device as shown in below image. • Step 3: Make sure the Wifi Switch is paired with Smart Life app before starting, Tap on the arrow section as highlighted in the below image. - Page 7 Step 7 a. Account will now be linked, please stay on the page you will be redirected in few seconds to select the device to add to your home. b. Select the device and tap on Next as show in image b. Step 8: Select the Home where you would like to add the Smart Life under.
- Page 8 Step 10 a. You can turn the Lamp On/OFF by taping on On/O options as shown below. (OR) You can tap on the Smart Lamp. b. You will be redirected to page(as shown in image b) where you can control the lights “Power and Dimming functionality”.
- Page 9 Step 3: Tap on settings and tap on “skills and games” as shown below. Step 4: Search for ‘Smart Life’ on the “Skills & Games” page as shown below. Smart Life Step 5: Enable the Skill Step 6: Enter your Smart Life login ID and password and tap on “Link Now” Step 7: Once you tap on Link Now, you will be redirected to a new page requesting for authorization(Ref Im- age below).
- Page 10 3. Smart Device - Lamp 4. Stable Wifi network IN CASE OF ANY QUERY/ISSUE WITH THE PRODUCT, PLEASE REACH OUT TO US AT: SUPPORT@V-TAC.EU FOR MORE PRODUCTS RANGE, INQUIRY PLEASE CONTACT OUR DISTRIBUTOR OR NEAREST DEALERS. V-TAC EUROPE LTD. BULGARIA, PLOVDIV 4000, BUL.L.KARAVELOW 9B IN CASE OF ANY QUERY/ISSUE WITH THE PRODUCT, PLEASE REACH OUT TO US AT: SUPPORT@V-TAC.EU...
