TECHNICAL DATA
SKU
INPUT POWER
INPUT VOLTAGE
DC POWER
RATED INPUT CURRENT
POWER FACTOR
CHARGE CURRENT
CHARGE TIME
OPERATING MODE
LOAD POWER
LOADING TYPE
EMERGENCY DURATION
OUTPUT CURRENT
OUTPUT VOLTAGE
INTRODUCTION & WARRANTY
Thank you for selecting and buying V-TAC product. V-TAC will serve you the best. Please read these instructions
carefully before starting the installation and keep this manual handy for future reference. If you have any another
query, please contact our dealer or local vendor from whom you have purchased the product. They are trained
and ready to serve you at the best. The warranty is valid for 3 years from the date of purchase. The warranty
does not apply to damage caused by incorrect installation or abnormal wear and tear. The company gives no
warranty against damage to any surface due to incorrect removal and installation of the product. This product is
warranted for manufacturing defects only.
In case of any query/issue with the product, please reach out to us at: support@v-tac.eu
For More products range, inquiry please contact our distributor or nearest dealers.
V-TAC EUROPE LTD. Bulgaria, Plovdiv 4000, bul.L.Karavelow 9B
INSTRUCTION MANUAL
EMERGENCY LED DRIVER
23740
<4W@230Vac
198-264Vac, 50/60Hz
5.5W-8.0W
0.07A Max. @230Vac
≥0.4@230Vac
250mA (MAX)
24 hours (MAX)
Emergency
Max.200W
LED Driver/DOB light (input)
180min
20.0-400mA
10-400VDC (Recommended 20-
400Vdc)
MULTI-LANGUAGE
MANUAL QR CODE
Please scan the QR code
to access the manual in
multiple languages.
COMPATIBLE HIGHBAY
23736, 23737, 23738, 23739
(PURCHASE SEPARATELY)
BATTERY CAPACITY
6.4V, 6.0AH
BATTERY TYPE
LiFePO4
CLASSIFICATION
Class I
INSTALLATION
Hanging mounting
DIMENSION
182*90*49mm
TERMINALS
Press;wire diameter: 0.2-0.75mm²
EMERGENCY SWITCHING
Manually Test (Test Button)/Au-
TEST
to-test (Monthly/Annually)
Over-voltage, over current over
temperature short circuit, and
ABNORMAL PROTECTION
open circuit protection and lim-
itation
OPERATING TEMPERA-
0°C~45°C
TURE
40000 HOURS@Ta full load(not
LIFESPAN
include the battery)
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for V-TAC 23740
Summary of Contents for V-TAC 23740
- Page 1 INTRODUCTION & WARRANTY Thank you for selecting and buying V-TAC product. V-TAC will serve you the best. Please read these instructions carefully before starting the installation and keep this manual handy for future reference. If you have any another query, please contact our dealer or local vendor from whom you have purchased the product.
-
Page 2: Installation Diagram
WARNING Please make sure to turn off the power before starting the installation. 2. Installation must be performed by a qualified electrician. 3. Proper grounding should be ensured throughout the installation. This marking indicates that this product Caution, risk of electric shock. should not be disposed of with other household wastes. -
Page 3: Installation Instructions
INSTALLATION INSTRUCTIONS 1. Turn of the power. 2. Securely hang the chain onto the roof hook. 3. Attach the chain to the emergency ring. 4. Hang the LED Highbay fixture onto the emergency hook. 5. Connect the emergency power unit to the AC supply as outlined in the provided diagram. -
Page 4: Indicator Light Description
INDICATOR LIGHT DESCRIPTION Charging-Green light flashes slowly Full charged - Green light ON Analog Emergency Mode - Green light in breathing mode (On-off Alternation) Real Emergency Mode (AC cut off) - Red light ON Fault - Red light flashes quickly OPERATION •... - Page 5 FUNCTIONS FUNCTION DESCRIPTION Auto-test Function • When AC main power is in fault or blackout, Emer- gency power kits will switch to emergency mode automatically, and supply power to the load with a rated emergency power. Initially auto-test setting • When the power kits is connected to the AC main power correctly, it will conduct the initially test.
