Alfa-V ACV/ANV/VXD
Instruction manual
EN
ORIGINAL INSTRUCTIONS
30366473EN-09

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ALFA Alfa-V ACV and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for LU-VE ALFA Alfa-V ACV

  • Page 1 Available languages Alfa-V ACV/ANV/VXD Instruction manual ORIGINAL INSTRUCTIONS 30366473EN-09...
  • Page 3: Table Of Contents

    Start-up procedure ........................19 6.2 Shutdown ..........................19 Maintenance..........................20 7.1 Cleaning ..........................20 7.2 Fan replacement ........................20 7.3 Stepping on the unit .........................21 Spare parts..........................22 30366473EN-09 Alfa LU-VE is a trademark registered and owned by LU-VE Group. Alfa LU-VE reserves the right to change specifications without prior notification.
  • Page 4: Important Information

    • Dimensional drawings • Electrical wiring diagrams • Certificates Alfa LU-VE offers world-wide service and support. In case of any questions or uncertainty please contact your local Alfa LU-VE representative. Contact addresses are available at alfa.luvegroup.com. Alfa-V ACV Alfa-V ANV Alfa-V VXD 30366473EN-09 Alfa LU-VE is a trademark registered and owned by LU-VE Group. Alfa LU-VE reserves the right to change specifications without prior notification.
  • Page 5: Product Description

    - Separate connections allow independent operation of both coils. • Fans: -2 to 9 fan pairs (2 to 6 for VXD), available in three fan diameters (ø 800 mm, ø 910 mm & ø 1000 mm) and different noise levels. ErP compliant motors with dynamically and statically balanced external rotor, protection class IP 54 according to DIN 40050 and integrated thermo contacts to provide reliable protection against thermal overload. AC power supplies 400/50/3, 400/60/3 and 460/60/3. EC power supply 380-480/50-60/3. AC/EC Fan motors manufactured in accordance with VDE 530/12.84 • Casing, supports and frame made of corrosion resistant galvanized steel (class C4-H). Separated fan sections and removable fan rings. • Frame construction provides high rigidity for protection against vibration and thermal expansion. • Stickers indicate fan direction and refrigerant in/out. 30366473EN-09 Alfa LU-VE is a trademark registered and owned by LU-VE Group. Alfa LU-VE reserves the right to change specifications without prior notification.
  • Page 6: Options

    Fan diameter (80=800, 90=910, 100=1000 mm) Number of fan pairs (2 to 9 for ACV and ANV 2 to 6 for VXD) Alfa-V series II Tube rows code (A, B, C, D for ANV and ACV B, C, D, E for VXD) Fan motor connection (D=delta, Y=star) Number of circuits (VXD only) Packing (SK=container skid) Case material Electrical accessories Fin material (AL=aluminium, IF=industrial fins, SWR=AlMg, EP=epoxy coated aluminium, FC=F-coat, CU=copper) Fin spacing (2.0, 2.1, 2.3, 2.5, 3.0 mm) Tube material (CU=copper, SS=stainless steel, K65= K65 copper) Connection dimensions (VXD only) Options 30366473EN-09 Alfa LU-VE is a trademark registered and owned by LU-VE Group. Alfa LU-VE reserves the right to change specifications without prior notification.
  • Page 7: Product Labels

    Power Supply: 400V/T /50 Test pressure Test date Date on which the coil has been pressure tested in Product the factory S/N 1296016 Serial nr. MADE IN ITALY 30366473EN-09 Alfa LU-VE is a trademark registered and owned by LU-VE Group. Alfa LU-VE reserves the right to change specifications without prior notification.
  • Page 8 Immediate report to manufacturer and note on VERLADTER KÄLTEMITTELKREISLAUF MIT STICKSTOFF ATTENTION! bill of delivery. CIRCUIT FRIGORIFIQUE PRE-CHARGE AVEC AZOTE BHИМАНИЕ! СИСТЕМА ЗАПРАВЛНА АЗОТОМ 5.307 30366473EN-09 Alfa LU-VE is a trademark registered and owned by LU-VE Group. Alfa LU-VE reserves the right to change specifications without prior notification.
  • Page 9 Use all marked lifting lugs when lifting from above. 11. & 12. In/Out Refrigerant connections inlet and outlet. Grounding Whenever electrical components supplied by Alfa LU-VE have this sticker, is mandatory to ground them. The yellow/green grounding wire must be left longer than the others, to ensure that it is the last one to be detached from the terminals in the event of the cable being pulled off. Grounding is designed for the electrical equipment supplied with the unit and is not to be intended as protection from external sourc- 30366473EN-09 Alfa LU-VE is a trademark registered and owned by LU-VE Group. Alfa LU-VE reserves the right to change specifications without prior notification.
  • Page 10: Unpacking And Lifting

    Unit delivered in a container In case of container delivery, container skid option is to be selected in order to facilitate the loading and unloading operations. In case of 9 modules unit, skid is installed by default. Follow the proce- dure below to unload the unit: • Remove any obstacle to allow the skid sliding out of the container. • Ensure the truck is stopped. 30366473EN-09 Alfa LU-VE is a trademark registered and owned by LU-VE Group. Alfa LU-VE reserves the right to change specifications without prior notification.
  • Page 11 2-5 fan pairs unit With forklift A, support the unit weight and pull it slowly out of the container. The unit must remain on the container floor for at least 1 m. The space between the unit and the roof of the container is reduced. Contact with the roof can cause damage to the unit. With a second forklift (identified by letter B), insert the forks (under the centre of gravity) and slightly lift the unit. Remove hooks and chains and drive away with forklift A. Slowly drive forward with the truck until the unit is completely outside the container. 30366473EN-09 Alfa LU-VE is a trademark registered and owned by LU-VE Group. Alfa LU-VE reserves the right to change specifications without prior notification.
  • Page 12: Lifting From Above

    Lifting from above Verify that lifting lugs are safely fixed to the unit and have no signs of damage. Attach the belts 90° 90° or hooks only to the lifting lugs as shown in the drawing on the next page. Angle of chains as shown for all models. Load on the lifting chains shall be equally distrib- uted on all the lifting points. If one chain is not fully loaded another chain will be extra loaded. This is not allowed. DETAIL A 30366473EN-09 Alfa LU-VE is a trademark registered and owned by LU-VE Group. Alfa LU-VE reserves the right to change specifications without prior notification.
  • Page 13 6 MOD 10 FANS 12 FANS 7 MOD 8 MOD 14 FANS 16 FANS 9 MOD 18 FANS 30366473EN-09 Alfa LU-VE is a trademark registered and owned by LU-VE Group. Alfa LU-VE reserves the right to change specifications without prior notification.
  • Page 14: Installation

    Installation Always follow guidelines and instructions as given in the condenser & gas cooler product manual AHE00049. Container skid removal (if present) Container skid option is selected in order to facilitate loading and unloading operations. Container skid shall be removed before installation. Container skid components are connected to the unit by means of screws. To remove the skid it is needed to slightly lift the unit. 30366473EN-09 Alfa LU-VE is a trademark registered and owned by LU-VE Group. Alfa LU-VE reserves the right to change specifications without prior notification.
  • Page 15: Mounting Dimensions

    To avoid oxidation of the equipment feet, it is strongly recommended to mount the heat exchanger on concrete mounting bases. One base for each foot. Base minimum dimensions are 100 mm height and 260 mm width. Expansion joints (only for condensers) Alfa LU-VE recommends the installation of expansion joints on both inlet and outlet con- nections. Expansion joints are elastic elements which, if properly installed, absorb the thermal expansions of the tubing. Expansion joints are also helpful in order to reduce vibrations in the piping. 30366473EN-09 Alfa LU-VE is a trademark registered and owned by LU-VE Group. Alfa LU-VE reserves the right to change specifications without prior notification.
  • Page 16: Vibration Dampers

    Vibration dampers M 16 Isolating material natural rubber, hardness 60° Sha. Picture shows an installation example using threaded bar, nut, grower washer, washer and locknut (not supplied). This way vibration dampers can be used to make the cooler level adjusting the locknut. This is particularly useful with long units or irregular basement. 30366473EN-09 Alfa LU-VE is a trademark registered and owned by LU-VE Group. Alfa LU-VE reserves the right to change specifications without prior notification.
  • Page 17: Installation Layout Guideline

    Bolt the product directly onto a firm base, or with vibrationsdämpare i stativets förborrade fästhål. vibration dampers, through the pre-drilled mounting holes. 30366473EN-09 Alfa LU-VE is a trademark registered and owned by LU-VE Group. Alfa LU-VE reserves the right to change specifications without prior notification.
  • Page 18: Pipework Layout

    Heat exchanger model indication • Fan motor type • Electrical accessories Electrical connection diagrams are available for download on alfa.luvegroup.com. When in doubt always contact your local Alfa LU-VE representative for assistance. Electrical connections Electrical connections Electrical connections Alfa-V ACV Alfa-V ANV Alfa-V VXD 30366473EN-09 Alfa LU-VE is a trademark registered and owned by LU-VE Group. Alfa LU-VE reserves the right to change specifications without prior notification.
  • Page 19: Operation

    • Switch on fan power supply. • Start the fans and verify fan direction. • After some operating time, verify that current absorbtion does not exceed the value as given in the technical specifications. Shutdown If the unit requires emptying for maintenance, system shutdown or dismounting, proceed as follows: • Stop refrigerant supply and switch off electrical power supply. • Make sure neither refrigerant nor power supply can be resumed accidentally or unexpectedly. • Drain all liquid refrigerant into a suitable vessel. • Evacuate the coil to remove any remaining refrigerant gas. 30366473EN-09 Alfa LU-VE is a trademark registered and owned by LU-VE Group. Alfa LU-VE reserves the right to change specifications without prior notification.
  • Page 20: Maintenance

    90° 80-100 bar 90° Fan replacement • Open the connection box. Disconnect fan cabling. • Unscrew fixing bolts and remove old fan. • Mount new fan assembly in identical position. Remount fasteners. Use an anti-corrosion coating like Geomet or comparable when remounting using new fixing bolts. • Restore the electric connections (water trap as shown). • Check for correct fan direction. 30366473EN-09 Alfa LU-VE is a trademark registered and owned by LU-VE Group. Alfa LU-VE reserves the right to change specifications without prior notification.
  • Page 21: Stepping On The Unit

    Stepping on the unit If for maintenance purposes it is required to step on the on the unit, always wear safety shoes. It is not allowed to step on the unit while it is working. Proper protection against falling shall be arranged with railings and safely fixed ladders. If the units do not have railings a safety device that prevents falling shall be used. Never step on the fan grids and on the liquid connections. It is not allowed to step outside the areas highlighted in the example below. = Walkable areas 30366473EN-09 Alfa LU-VE is a trademark registered and owned by LU-VE Group. Alfa LU-VE reserves the right to change specifications without prior notification.
  • Page 22: Spare Parts

    ④ ⑤ Spare parts for Alfa-V ACV/ANV/VXD ① Switch on/off ② Switchboard ③ Vibration damper ④ Protection grids (available on request) ⑤ Contact your local Alfa LU-VE representative for spare parts order and assistance. 30366473EN-09 Alfa LU-VE is a trademark registered and owned by LU-VE Group. Alfa LU-VE reserves the right to change specifications without prior notification.
