IMPULSE
FIRMWARE UPDATE
USER GUIDE
Last updated on Feb 12, 2025

Advertisement

loading
Need help?

Need help?

Do you have a question about the IMPULSE and is the answer not in the manual?

Questions and answers

Summary of Contents for Sena IMPULSE

  • Page 1 IMPULSE FIRMWARE UPDATE USER GUIDE Last updated on Feb 12, 2025...
  • Page 2: Status Led

    Status LED Mesh Intercom button Taillight Status LED WiFi Status Charging Fully Charged Not connected to WiFi network Searching for WiFi network FAST BLINKING FAST BLINKING Connected to WiFi network SLOW BLINKING SLOW BLINKING Note: • Fast blinking: 0.5 seconds interval •...
  • Page 3 1. Connect the IMPULSE with your smartphone and open the Sena Motorcycles app. • Continue to Setting on the top right corner of the screen, then Firmware Update. 2. Connect the IMPULSE to a wall charger or power source using the provided magnetic cable.
  • Page 4 3. Check the Status LED. a. Solid Red or Blue: A Solid red LED or blue LED indicates that the built-in WiFi must be configured before proceeding with the update. Continue to step 4 to configure the built-in WiFi. Solid b.
  • Page 5 4. Open the WiFi settings on your smartphone, find the built-in WiFi (identified as SENA Impulse-xxxxxx), and select it. 5. Open the Sena Motorcycles app. 6. Select WiFi network and enter the password. Note: Only 2.4 GHz network is supported.
  • Page 6 Firmware Update via WiFi 1. Connect the IMPULSE to a wall charger or power source using the provided magnetic cable. 2. Check the Status LED for slow blinking red or blue. Slow Blinking 3. The update will start automatically, and the taillight will move repeatedly from left to right during the update.
