StyleWell 3371015HD Assembly Instruction Manual

25" closet tower with drawers

Advertisement

Quick Links

ASSEMBLY INSTRUCTIONS GUIDE
We appreciate the trust and confidence you have placed in StyleWell through the purchase of this closet tower kit. We strive to continually
create quality products designed to enhance your home.Visit us online to see our full line of products available for your home improvement
25" CLOSET TOWER
WITH DRAWERS
Questions, problems, missing parts?
Before returning to the store, call Customer Service
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
Phone Number: 1-877-527-0313
needs. Thank you for choosing StyleWell!
ITEM# xxxxxxxxxx
ITEM# xxxxxxxxxx
ITEM# xxxxxxxxxx
ITEM# xxxxxxxxxx
HOMEDEPOT.COM
THANK YOU
MODEL# 3371015HD
MODEL# 3371341HD
MODEL# 3371342HD
MODEL# 3371356HD

Advertisement

loading
Need help?

Need help?

Do you have a question about the 3371015HD and is the answer not in the manual?

Questions and answers

Summary of Contents for StyleWell 3371015HD

  • Page 1 THANK YOU We appreciate the trust and confidence you have placed in StyleWell through the purchase of this closet tower kit. We strive to continually create quality products designed to enhance your home.Visit us online to see our full line of products available for your home improvement...
  • Page 2: Pre-Assembly

    More than one person may be required to assemble this product. TOOLS REQUIRED Phillips Claw hammer screwdriver HARDWARE INCLUDED NOTE: Hardware not shown to actual size. ITEM# xxxxxxxxxx MODEL# 3371015HD Description Quantity Part Code Part Number A23030 CONFIRMAT QUICKLOC CONNECTOR, WHITE A22770...
  • Page 3 Pre-assembly PLANNING ASSEMBLY ITEM# xxxxxxxxxx MODEL# 5607341HD Part Part Description Quantity Code Number A23030 CONFIRMAT QUICKLOCK CONNECTOR, WHITE A22770 A21670 DOWEL WOOD 6MM X 30 MM ADJUSTABLE GLIDE 1/4"-20X32 A43020 1/4-20 PROPELL NUT P14208F10 A20330 A80250 SHELF SUPPORT A84050 WALL ANCHOR KIT SCREW 8 X 1-1/4 PH PN, ZINC A13020 SCREW 8 X 7/8 PH PN, ZINC...
  • Page 4: Package Contents

    Pre-assembly (continued) PACKAGE CONTENTS ITEM# xxxx MODEL# 5607015HD ITEM# xxxx MODEL# 5607341HD PARTS LIST PARTS LIST ITEM PART NUMBER DESCRIPTION ITEM PART NUMBER DESCRIPTION 35607341010 LEFT PANEL LOWER 35607015010 LEFT PANEL LOWER 35607341020 RIGHT PANEL LOWER 35607015020 RIGHT PANEL LOWER 38583341030 LEFT PANEL UPPER 38583015030...
  • Page 5 Pre-assembly (continued) PACKAGE CONTENTS ITEM# xxxx MODEL# 5607356HD PARTS LIST ITEM PART NUMBER DESCRIPTION 35607356010 LEFT PANEL LOWER 35607356020 RIGHT PANEL LOWER 38583356030 LEFT PANEL UPPER 38583356040 RIGHT PANEL UPPER 38583356050 38583356060 BOTTOM 38583356070 MIDDLE SHELF 38583356080 ADJ SHELF 38583356090 APRON 38583356100 KICK...
  • Page 6 Pre-assembly (continued) PACKAGE CONTENTS RIGHT LEFT SIDE BACK SIDE HOMEDEPOT.COM : # 1-877-5270313 Please contact for further assistance.
  • Page 7 Disassembling slides (A56900): Extend each section as shown. Press the black lever upward and separate the two parts of the slide. Lever Outer slide section will attach to the Left Side (A) and Right Side (B). Use holes marked with arrows to fasten. Inner slide section will attach to the drawer sides.
  • Page 8 Assembly Arrange Left Panel (A) and Right Panel (B) as shown. In the unfinished edge, insert the nuts (5) into the holes with a hammer. Thread adjustable leveling feet into the nuts. 2 - x6 4 - x4 5 - x4 Insert connectors as shown.
  • Page 9 Assembly Arrange the Left Panel (C) and the Right Panel (D) as shown. In the unfinished edge, insert wood dowels as shown. Insert connectors as shown. 2 - x4 3 - x4 Lightly tap with hammer if necessary. C - x1 D - x1 Note: Edge of quickloc to be flush with edge of board.
  • Page 10 Assembly Insert connectors into Bottom (F) as shown. Lightly tap with hammer if necessary. 2 -x6 F - x1 Note: Edge of quickloc to be flush with edge of board. HOMEDEPOT.COM : # 1-877-5270313 Please contact for further assistance.
  • Page 11 Assembly Insert wood dowels and connectors into Back Panels (K & L) as shown. Lightly tap with hammer if necessary. 2 - x14 3 - x4 Note: Edge of quickloc to be flush with edge of board. HOMEDEPOT.COM : # 1-877-5270313 Please contact for further assistance.
  • Page 12 Assembly Connect Back Panels (L) together by inserting dowels into the mating panel. Connect Back Panels (K) together by inserting dowel into the mating panel. Note: Take care not to bend or twist assembled Back Panels when moving. Insert connectors into Apron (I) as shown. 2 - x2 Note: Edge of quickloc to be flush with edge of board.
  • Page 13 Assembly Connect Bottom (F) to Left Panel (A) by inserting connectors as shown. Turn connector screws clockwise to lock in place. finished edge Turn clockwise to lock in place Inlist a helper and carefully lift both Back Panels (K) together, insert connectors as shown.
  • Page 14 Assembly Attach Right Panel (B) by carefully inserting connectors as shown. Turn connector screws clockwise to lock in place. finished edge Turn clockwise to lock in place Attach Kick (J) to Left Panel (A) and Right Panel (B) by inserting connectors as shown.
  • Page 15 Assembly Attach Apron (I) to Top (E) by inserting connectors as shown. Turn connector screws clockwise to lock in place. Turn clockwise to lock in place finished edge Inlist a helper and carefully move both Back Panels (L) into place. Attach Left Panel (C) and Right Panel (D) as shown by inserting connectors as shown.
  • Page 16 Assembly While your helper holds the Left Panel (C) and Right Panel (D) upright, attach Middle Shelf (G) using two screws. 1 - x2 finished edge Attach Top (E) to Left Panel (C) and Right Panel (D) by inserting connectors as shown.
  • Page 17 Assembly With a helper attach the bottom unit to the top unit by inserting connectors as shown. Turn connector screws clockwise to lock in place. Turn clockwise to lock in place HOMEDEPOT.COM : # 1-877-5270313 Please contact for further assistance.
  • Page 18 Assembly Warning All units MUST be fastened to the wall. Place unit inside closet (allow 30" to 48" on each side for clothing rod). Use a level and adjust adjustable leveling feet to be sure it is square. Place L-bracket on top of the unit with bracket screw using existing hole location. Mark hole location on wall.
  • Page 19 Assembly Position the Left Drawer Side and Right RIGHT DWR LEFT DWR Drawer Side as shown. 2 - x12 SIDE- x3 SIDE- x3 Insert connectors (2) into each Drawer Side as shown. RIGHT SIDE Note: Edge of quickloc to be flush with edge of board.
  • Page 20 Assembly Make sure the orientation of the parts are as LEFT DWR RIGHT DWR DRAWER shown (Grove towards bottom). SIDE- x3 BACK - x3 SIDE- x3 Engage the connector on Drawer back to the Left and Right Drawer sides. Turn the screws on connectors (2) clockwise to lock in place.
  • Page 21 Assembly Engage the connector on Left and Right Drawer side into the the Drawer front. Z- x3 Turn the screw on connectors clockwise to lock in place. Turn clockwise to lock in place SIDE BACK SIDE Install the Inner slide using Screw (14) as shown. Refer page 7 for Slide disassembly details.
  • Page 22 Assembly Engage the inner slides (17b) of the drawer with the outer slide (17a), and push firmly in. HOMEDEPOT.COM : # 1-877-5270313 Please contact for further assistance.
  • Page 23 Assembly Insert Wire Rail (13) into holes in Adjustable Shelf (H). 13 - x2 H - x2 HOMEDEPOT.COM : # 1-877-5270313 Please contact for further assistance.
  • Page 24 Assembly Select the desired shelf heights and insert shelf supports into the Left and Right panels (C & D). Ensure that each is positioned so that both the left and right shelf supports are evenly placed. Insert Adjustable Shelves (H) into the unit. H - x2 6 - x8 12 - x4...
  • Page 25 Assembly Choose "double hang" and "single hang" side. If the pre-drilled hole locations are not suitable for your needs, you can mark and drill pilot holes at your desired location. Please use a 1/16" drill bit and be careful not to drill too deep. Double hanging rod: We suggest placing top rod at 77"...
  • Page 26 Assembly Secure each Adjustable Rod with two screws. 9 - x6 11 - x3 HOMEDEPOT.COM : # 1-877-5270313 Please contact for further assistance.
  • Page 27 Assembly Extend rod to the wall and hold in place. Be sure rod is level and mark hole locations on wall. Repeat for all bracket locations. Screw in wall anchors at marked locations and secure each rod to the wall with screws. 8 - x6 10 - x6 wall...
  • Page 28: Maximum Loads

    Maximum Loads This unit has been designed to support the maximum loads shown. Exceeding these load limits could cause sagging, instability, product collapse, and/or serious injury. 50 lbs 22.7 kg 10 lbs 4.5 kg 50 lbs 22.7 kg 25 lbs 11.4 kg 30 lbs 13.6 kg...
  • Page 29 Questions, problems, missing parts? Before returning to the store, call StyleWell Customer Service 8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday PHONE NUMBER 1-877-527-0313 HOMEDEPOT.COM Retain this manual for future use. HOMEDEPOT.COM...
