original operating instructions
Hydraulic firewood processor SSA-500GHPRO
Model: SSA-500GHPRO
Both the model number and serial number can be found on the rating plate on the
machine. You should keep both numbers in a safe place for future reference.
FOR YOUR SAFETY, READ THE ENTIRE INSTRUCTIONS BEFORE OPERATING
SSA-500GHPRO
Serial number:
OPERATING INSTRUCTIONS
Art. No.: SSA500GHPRO
www.lumag-maschinen.de
_____________________________
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Lumag SSA-500GHPRO
Summary of Contents for Lumag SSA-500GHPRO
- Page 1 Translated from German to English - www.onlinedoctranslator.com SSA-500GHPRO Art. No.: SSA500GHPRO www.lumag-maschinen.de original operating instructions Hydraulic firewood processor SSA-500GHPRO Model: SSA-500GHPRO Serial number: _____________________________ Both the model number and serial number can be found on the rating plate on the machine.
-
Page 2: Table Of Contents
CONTENT / GENERAL TABLE OF CONTENTS GENERAL 1. General 2. Information on the operating instructions 3. Intended use 4. Scope of delivery 5. Environment DANGER! 6. Technical data Read all safety warnings and 7. Symbols instructions. 8. Security 9. Transport Use this manual to familiarize yourself with the 10. -
Page 3: Information On The Operating Instructions
GENERAL / INFO / INTENDED USE name machine The term “machine” is the commercial name of the replaced item to which this operating manual - see cover page - refers. operating instructions beginning before Please read the instructions carefully before using the device for the first time! They are part of the product and must be kept in a known place that is accessible to all users at all times. -
Page 4: Scope Of Delivery
SCOPE OF DELIVERY / ENVIRONMENT / TECHNICAL DATA TECHNICAL DATA SCOPE OF DELIVERY After unpacking, check the contents of the box/ Model SSA-500GHPRO transport box for completeness and possible transport damage. 9.2 kW / 420 cm³ Engine / Drive (petrol) max. -
Page 5: Symbols
SYMBOLS SYMBOLS Check engine oil! Check the oil level before each use and after at least 8 operating hours (BTS). There are symbols on the machine. These represent important information about the product or instructions for use. Warning of hot surfaces. Danger of burns! DANGER! Do not touch hot engine parts. - Page 6 SYMBOLS / SAFETY Do not use the machine in enclosed spaces. Danger moving tools Chainsaw! Danger of slipping and enough For one person operation only tripping! In the work area on Pay attention to free space. Clutter can lead to accidents. Warning, do not remove jammed logs with your hands.
-
Page 7: Security
SECURITY SECURITY Oil level in the hydraulic oil tank. Do not use your firewood processor if repairs are required or the machine is in poor condition. safety and warning instructions Familiarize yourself with the firewood processor Wear appropriate protective clothing Read and understand the operating instructions Do not wear loose clothing, loose gloves, scarves, and the labels on the machine. - Page 8 SAFETY / TRANSPORT are cut as squarely as possible. This prevents the To split logs whose size exceeds the size specified in split material from slipping out under pressure. the specifications table. Use the firewood processor Branches must be cut flush with the tree trunk. only for the purpose of processing wood and not any other materials or objects.
-
Page 9: Transport
PART NAME-ENGINE TRANSPORT 10. PART NAME-ENGINE Before each transport, the following steps gasoline engine must be completed: ■ Switch off the machine's motor and allow it to cool down to avoid burns and to eliminate the risk of fire. ■ Disconnect the spark plug connector. ■... -
Page 10: Refueling
FUEL choke lever 11. REFUELLING The choke lever opens and closes the carburetor DANGER! choke valve. The choke lever is only used to start a You may only carry out the work described in this cold engine. chapter after you havesafety instructionsread and understood. -
Page 11: Gasoline
FUEL / COMMISSIONING 11.2 GASOLINE DANGER petrol flammable extremely Health and explosion hazards from combustion explosive. You may suffer burns or other serious engines injuries when handling fuel. ■ The engine's exhaust contains When refilling fuel, please note: poisonous carbon monoxide. Staying in an environment containing carbon monoxide can lead to ■... -
Page 12: Preparation For Use
COMMISSIONING 12. COMMISSIONING ■ Check the condition of the air filter, the fuel lines and connections for leaks and mechanical damage, and the fuel tank for cracks and leaks. 12.1 PREPARATION FOR USE ■ Lubricate the machine regularly depending on DANGER how often it is used. -
Page 13: Turn Off The Engine
COMMISSIONING 12.3 STOPPING THE ENGINE (FIG. 1-3) Before stopping the engine, allow all wood residues in the splitting area to split. 1. Set the throttle lever on the engine to the MIN. (idle) position. 2. Turn the engine switch to OFF. 3. -
Page 14: 13Th Operation
OPERATION 13. OPERATION X4: Control lever “eg log lifter 1” Tilted up = runs forward Tilted down = runs backward Think carefully about where you will work. Work safely and save time by planning your work in advance. X5: Operating lever “eg log lifter 2” Tilted upwards = lift Tilted downwards = lower Store your logs where they are easy to reach. -
Page 15: Operation Of The Machine
OPERATION 13.3 OPERATION OF THE MACHINE (Image similar) (e) Conveyor belt (not fully shown) (f) Hydraulic conveyor belt (g) Control lever for wood splitter (h) Hydraulic system & hydraulic system accessories (not shown) (i) Split cross locking (j) Splitting cross adjustment (k) Hydraulic oil temperature indicator (l) feet (m) support wheel... - Page 16 OPERATION 1. Make sure that all components of the firewood as described in point 12.3. Now open the safety processor are firmly screwed together and that gate and position the material to be split no loose parts could cause dangerous injuries. accordingly.
-
Page 17: Procedure For A Jammed Piece Of Wood
PROCEDURE FOR A BENT PIECE OF WOOD / MAINTENANCE 14. PROCEDURE FOR A BENT PIECE OF 15. MAINTENANCE WOOD 15.1 MAINTENANCE Turn off the engine and disconnect the spark plug connector from the engine. Constant maintenance of the firewood processor ensures a long service life of all components. -
Page 18: Change / Check Hydraulic Oil
MAINTENANCE File each tooth very carefully. Use a suitable container of sufficient size to completely drain the oil. First remove the drain Clean the chainsaw after filing. plug (B1), which is located below the filler neck (A1). Unscrew the filter cartridge on the hydraulic filter Check the chain very carefully after grinding. -
Page 19: Sharpening The Splitting Cross
MAINTENANCE 15.6 CLEANING / CHANGING THE AIR FILTER 15.3 SHARPENING THE SPLITTING CROSS The splitting machine is equipped with a Cleaning the air filter frequently will prevent reinforced splitting wedge that has been carburetor malfunctions. If the engine starts to specially treated. -
Page 20: Checking / Replacing The Spark Plug
MAINTENANCE 15.7 CHECKING / REPLACING THE 15.8 DRAINING OF OPERATING MATERIALS SPARK PLUG Change the engine oil while the engine is still warm. Check the spark plug and the gap between the Warm oil drains quickly and completely. electrodes regularly. ATTENTION! Environmental damage. -
Page 21: October 15Th Cleaning
MAINTENANCE / STORAGE 16. STORAGE 15.10 CLEANING Store the machine in a horizontal position on level ground in a dry and well-ventilated building. Maintenance and cleaning work should only be carried out when the drive is switched off and at a standstill. The machine should always be cleaned. -
Page 22: Troubleshooting
TROUBLESHOOTING 17. TROUBLESHOOTING Observe safety instructions! Any faults in the machine or engine that require major intervention should always be repaired by your LUMAG specialist workshop or an authorized specialist workshop. Improper intervention will void the warranty. Caused remedy Disturbance... -
Page 23: Warranty/Guarantee/Customer Service
Warranty work is carried out exclusively by our defects resulting from negligent assembly, faulty LUMAG service workshop. Defects that occur within connection, incorrect fuel/fuel mixture, installation, the warranty period due to material or operation, maintenance, lubrication or force. -
Page 24: Ec Declaration Of Conformity
Telephone: +49 / (0)8571 / 92 556-0 Fax: +49 / (0)8571 / 92 556-19 that the product Designation: Wood splitter Type designation: SSA-500GHPRO meets the essential protection requirements of the above-mentioned EC directives. Conformity is based on the following standards: EN ISO 12100:2010... -
Page 25: Components Of The Machine
COMPONENTS OF THE MACHINE 20. COMPONENTS OF THE MACHINE... -
Page 26: Hydraulic Diagram
NOTE 21. HYDRAULIC DIAGRAM:... -
Page 27: Notes
NOTE 22. NOTES: _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________... - Page 28 LUMAG GmbH Rudolf-Diesel-Str. 1a D-84375 Kirchdorf am Inn Telephone: +49 (0)85 71 / 92 556 - 0 Fax: +49 (0)85 71 / 92 556 - 19 www.lumag-maschinen.de Status: 01/2024 - SSA500GHPRO_V2...
