- Page 1 Manual Manual aura-t™ TP726/EU aura-t™ SMART TP746/EU MVHR (Mechanical Ventilation with Heat Recovery) Controllers Product Manual...
-
Page 2: Warnings, Safety Information And Guidance
Warnings, Safety information and Guidance Warnings, Safety information and Guidance Important Information Read instructions fully before the installing this appliance. This manual covers the operation of the MVHR control system only, it must therefore be read in conjunction with the relevant heat recovery unit Product Manual. - Page 3 10. This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
-
Page 4: Table Of Contents
Contents Contents Warnings, Safety information and Guidance Installation Important Information � � � � � � � � � � � � � � � � � � � � � � � � � 2 Location � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 15 Fixing�... -
Page 5: Product Overview
Product Overview Product Overview Description Features The aura-t™ is a programmable touch screen The following gives an outline description for each of controller which monitors and displays the status of the product features of the aura-t™ & aura-t™ SMART. a MVHR unit. It allows the unit to be commissioned, 24 Hour Clock and gives the user both manual and timed control of fan speeds. -
Page 6: Programmable Speeds
Programmable Speeds 0-10V Inputs (Room Sensors) The unit has 4 programmable speed settings, all The sensor type, 0V reading, 10V reading for each of speeds are variable between 14-100% and allow the 4 room sensors can be adjusted. Additionally the independent speed setting of both supply and extract range over which proportional control is active can ventilation rates... -
Page 7: Wifi Aurasmart
WiFi auraSMART® The aura-t SMART units have WiFi connectivity; either WiFi Direct or connection to a WiFi router that enables smartphone control of the ventilation system using the auraSMART® app. Run Mode Fan Commissioning Within this section the user can control the speed of When installing any MVHR unit, it’s important to the MVHR Unit. -
Page 8: User Interface
User Interface User Interface Menu Tabs The aura-t™ screen has three interactive menu screens which are selected via tabs at the bottom of the touchscreen. Function Monitor & Control Setup Timer Fan Commission Name Run Mode Timer Mode Setup (Tap) Setup Menu Option Displays:... -
Page 9: Run Mode
Gives access to: Eco Mode, Switch setup, Summer Bypass, 0-10v Inputs (Room Sensors), Passcode settings, MVHR handing settings, Frost setup. Run Mode The aura-t™ controls the MVHR unit’s 4 programmable speed settings. The passcode is always required to edit fan speeds and is optional for protection of the Setup-Sub-Menu settings. -
Page 10: Status Icons
Status Icons If the fan speed is being controlled by an external switch, a sensor or the timer this is indicated by an icon beneath the speed selection buttons being visible. The icons are as follows: An external switch is active and is controlling a function of the unit. MVHR The timer is active and is keeping the at Speed 1. -
Page 11: Timer Mode
WiFi Full Connection Not Connected to Server (link bar flashing) Not Connected to router (no link bar) Local network, searching for connection Connected to Local network; internet or server unavailable MVHR When the Backlight is flashing along with the Speed 3 button the has been held at Boost, Speed 3 for more than 2 hours;... -
Page 12: Aurasmart® Wifi Timers
MVHR When the timer has automatically switched the to Speed 1 this can be manually overridden by tapping [2-4] keys. Tap the Speed 1 key to return to timer control. When the next timed event occurs the unit will revert to timer control. Manual override is not possible if Boost Inhibit is in operation. -
Page 13: Aurasmart® Connection Guides
auraSMART® Connection Guides auraSMART® Connection Guides WiFi/Internet - Option One In your phone WiFi settings, ensure your phone is connected to the same WiFi router as the aura-t™ will be connected (not a 3G/4G mobile connection). Note this needs to be a 2.4GHz network. -
Page 14: Wifi Direct - Option Two
Once paired the aura-t™ will display the full WiFi Press then using the arrow symbol (not flashing), The status of the module in the app will show as “Online”. WiFi functions of the buttons select to create a WiFi direct app are now available via the internet and 3G/4G hotspot, pressing to select. -
Page 15: Installation
Installation Installation Location The aura-t™ should be mounted in position convenient for the householder and where the supplied control cable will reach. Fixing Holes Wiring Access Hole aura-t Backplate Fixing Un-clip the front of the aura-t™ case from the Back Plate. Thread the control cable through the hole in the Back Plate. - Page 16 aura-t™ must be connected using the communication cable provided, this can be extended up to 30m. Control & Communication cable - Unshielded 4 Core 18-24AWG Stranded, Tinned Copper. MVHR Connection to MVHR Connection to aura-t™...
-
Page 17: Fan Commission
Fan Commission For constant volume (AR) units the fan speeds will be displayed as either: • m3/hr • • l/s to 0.1 resolution Fan Commission Mode is entered by pressing the Fan Button for 5 seconds whilst in Run Mode. A flashing item on the screen indicates it is being edited. -
Page 18: Cloning
Cloning Cloning allows the commissioned fan speeds to be copied from one unit to another the using an external aura-t. Saving Fan Speeds to the aura-t To save the current fan speed to the aura-t™ press and hold the Supply or Extract buttons whilst on the fan commission screen. -
Page 19: Timer Setup
Timer Setup Timer setup is achieved in three steps 1 Day Selection 1. Tap the Timer Mode tab to enter the Timer Mode menu. 2. Tap the Timer Setup Key to commence setup. 3. A ring around the day selected will blink. Change the day that the timers are to be edited by using the Arrow Keys. - Page 20 3 Copy Timers or Exit Timer Setup 1. The flashing Copy icon indicates the option to copy just edited settings to another day. 2. Tap the Enter Key to commence copy procedure. 3. Tap the Exit key to start editing another day’s times or press a second time to exit to Run Mode. 4.
-
Page 21: Timer Defaults
Timer Defaults Event timings: The Speed 2 cannot be set earlier than Speed 1. Events where Speed 1 and Speed 2 are identical are ignored by the timer. By default the timers are paused, consult the Timer Mode section for details of how to set them running. Event Days Speed 1... - Page 22 ƒ Arrow keys are used to select a setting, the setting will flash. ƒ Tapping the Enter key will allow the setting to edited. ƒ Tap the Exit button to return to Run Mode. Setting Editing ƒ Arrow keys are used to change setting value. ƒ...
-
Page 23: Setup Sub Menu
Setup Sub Menu Enter key. Exit Key. Long Press the Setup Menu tab to enter the Setup Sub Menu, if the Pass code is enabled enter the passcode. The order in which editable settings are displayed is as follows. 1. Eco Mode 2. -
Page 24: Switch Setup Menu
Switch Setup Menu In this menu the installer can configure the function of the MVHR unit’s switch inputs S1, S2, S3, LS1 & LS2 (see MVHR Product Manual for details) Enter key. Exit Key. Switch Setup menu active. All switch inputs to the MVHR unit; S1, S2, S3, LS1 & LS2 can be assigned any of the following functions. Kitchen Boost, Speed 3. -
Page 25: 0-10V Inputs (Room Sensors)
0-10V Inputs (Room Sensors) The 0-10V inputs control fan speed. High Speed Low speed Sensor Set Point Set Point Sensor Min Point High Max Point There are 4 room sensors connections available; each Sensor has two configuration screens, each pair of screens is displayed sequentially. -
Page 26: Passcode Enable / Disable
Passcode Enable / Disable Tap Enter key to edit state. Use to enable / disable Passcode. - - - - indicates Passcode is disabled. 3 3 3 3 indicates Passcode is enabled. Enabling the Passcode only protects the menu items in the Setup Sub Menu. The passcode is permanently enabled on the fan commission screen Unit Handing This menu item changes the handing of the unit;... -
Page 27: Frost Setup
Frost Setup This screen is used to select between unbalanced Frost Protection, where only the supply fan stops (default) or balanced where both fans stop. Balanced Frost Protection is for use in properties with an open flue fireplace. Use the Arrow buttons to select between supply fan or both fans. -
Page 28: Appendix
Appendix Appendix aura-t™ Configurable Defaults The table below details the default values and the range of available settings, plus any additional information about those settings the aura-t™ can configure. The installer should record all configuration settings in the space available. Configurable Range Default... - Page 29 Configurable Range Default Configured Additional Item Value information Summer Bypass Extract 17°C 35°C 25°C Supply 10°C 20°C 18°C In order for the Summer Bypass to operate the temperatures of both the air being extracted from the property and supplied from outside must be above their individual thresholds� If the temperature of the Supply air is less than 1°C cooler than the Extracted air the Summer Bypass does not operate to prevent the warmer air being supplied directly to the property�...
- Page 30 Configurable Range Default Configured Additional Item Value information Room Sensor 1 Enable/Disable Enabled Disabled Enabled Sensor Type Lower threshold Upper threshold 100% Room Sensor 2 Enable/Disable Enabled Disabled Enabled Sensor Type 0PPM Lower threshold 800PPM Upper threshold 1400PPM 2000PPM Room Sensor 3 Enable/Disable Enabled Disabled...
-
Page 31: Maintenance
This unit should be returned to your distributor or to a local recycling service. Respect the local environmental rules. Manufacture TITON Hardware Limited 894 The Crescent, Colchester Business Park, Colchester, Essex, CO4 9YQ United Kingdom ©2024 TITON... -
Page 32: Supplied By
Supplied by: Installed by: In the event of any queries please contact the system installer. Ensure this booklet is passed to the householder once installation & commissioning of the ventilation system is complete. This Product Manual must be kept in the Home Information Pack. DO 5807 Issue 02 CN3960...
