MODEL PW2300
2300 PSI ELECTRIC
PRESSURE WASHER
Instruction Manual
NEED HELP? CONTACT US!
Have product questions? Need technical support? Please feel free to contact us:
1-847-429-9263 (M-F 8AM-5PM CST)
TECHSUPPORT@WENPRODUCTS.COM
IMPORTANT: Your new tool has been engineered and manufactured to WEN's highest standards for dependability,
ease of operation, and operator safety. When properly cared for, this product will supply you years of rugged,
trouble-free performance. Pay close attention to the rules for safe operation, warnings, and cautions. If you use
your tool properly and for its intended purpose, you will enjoy years of safe, reliable service.
WENPRODUCTS.COM
For replacement parts and the most up-to-date instruction manuals, visit

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PW2300 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Wen PW2300

Summary of Contents for Wen PW2300

  • Page 1 1-847-429-9263 (M-F 8AM-5PM CST) TECHSUPPORT@WENPRODUCTS.COM IMPORTANT: Your new tool has been engineered and manufactured to WEN’s highest standards for dependability, ease of operation, and operator safety. When properly cared for, this product will supply you years of rugged, trouble-free performance. Pay close attention to the rules for safe operation, warnings, and cautions. If you use your tool properly and for its intended purpose, you will enjoy years of safe, reliable service.

  • Page 2: Table Of Contents

    CONTENTS WELCOME Introduction ......................3 Specifications ....................3 SAFETY General Safety Rules ..................4 Pressure Washer Safety Warnings ..............6 Electrical Information ..................8 BEFORE OPERATING Unpacking & Packing List .................9 Know Your Pressure Washer ................10 Assembly & Adjustments ................11 OPERATION & MAINTENANCE Operation ......................13 Transportation &...

  • Page 3: Welcome

    INTRODUCTION Thanks for purchasing the WEN Electric Pressure Washer. We know you are excited to put your tool to work, but first, please take a moment to read through the manual. Safe operation of this tool requires that you read and un- derstand this operator’s manual and all the labels affixed to the tool.

  • Page 4: Safety

    GENERAL SAFETY RULES WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Safety is a combination of common sense, staying alert and knowing how your item works. The term “power tool” in the warnings refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool.

  • Page 5: California Proposition 65 Warning

    GENERAL SAFETY RULES WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Safety is a combination of common sense, staying alert and knowing how your item works. The term “power tool” in the warnings refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool.

  • Page 6: Important Safety Instructions

    PRESSURE WASHER SAFETY WARNINGS WARNING! Do not operate the power station until you have read and understood the following instructions and the warning labels. IMPORTANT SAFETY INSTRUCTIONS 6. Malfunctioning Switch. Do not use the tool if the switch does not turn on and off. Any electrical appliance SAVE THESE INSTRUCTIONS that cannot be controlled by the switch is not safe to use and must be repaired.

  • Page 7: Operating The Pressure Washer

    PRESSURE WASHER SAFETY WARNINGS WARNING! Do not operate the power station until you have read and understood the following instructions and the warning labels. OPERATING THE PRESSURE WASHER 7. Avoid Accidental Start-ups. Make sure the power switch is in the OFF position before connecting the plug 1.

  • Page 8: Electrical Information

    ELECTRICAL INFORMATION DOUBLE-INSULATED TOOL The tool’s electrical system is double-insulated where two systems of insulation are provided. This eliminates the need for the usual three-wire grounded power cord. Double-insulated tools do not need to be grounded, nor should a means for grounding be added to the product. All exposed metal parts are isolated from the internal metal components with protecting insulation.

  • Page 9: Before Operating

    UNPACKING & PACKING LIST UNPACKING Carefully remove the electric pressure washer from the packaging and place it on a sturdy, flat surface. Make sure to take out all contents and accessories. Do not discard the packaging until everything is removed. Check the packing list below to make sure you have all of the parts and accessories.

  • Page 10: Know Your Pressure Washer

    KNOW YOUR PRESSURE WASHER TOOL PURPOSE Put the stains and unwanted buildup in your life under pressure with your WEN Electric Pressure Washer. Refer to the following diagrams to become familiarized with all the parts and controls of your pressure washer. The compo- nents will be referred to later in the manual for assembly and operation instructions.

  • Page 11: Assembling The Spray Gun

    ASSEMBLY & ADJUSTMENTS WARNING! To avoid injury from accidental startups, be sure that the tool is switched OFF and disconnected from the power supply before performing assembly, inspection, or adjustments. Fig. 1 ASSEMBLING THE SPRAY GUN 1. Insert the quick-connect end of the adjustable spray lance (Fig. 1 - 1) into the spray gun (Fig. 1 - 2) as shown in Fig.

  • Page 12: Installing The Wheels

    ASSEMBLY & ADJUSTMENTS WARNING! To avoid injury from accidental startups, be sure that the tool is switched OFF and disconnected from the power supply before performing assembly, inspection or adjustments. INSTALLING THE WHEELS Fig. 4 1. Fit the wheels (Fig. 4 - 1) into the wheel mounting holes on the back of the pressure washer until they “click”...

  • Page 13: Operation & Maintenance

    OPERATION WARNING! To prevent serious injury, make sure all the warnings and instructions have been read and understood before operating this tool. CAUTION! Do not connect the pressure washer to a potable water system without a backflow prevention method installed, if required by your local jurisdiction. CAUTION! The water supply must not exceed 170 PSI.
  • Page 14 OPERATION SELECTING THE PROPER NOZZLE SETTING FOR YOUR OPERATION 0º Nozzle Setting: Fine spot spray means delivering a high-pressure jet stream. It is used to cut heavy dirt deposits in a small,concentrated area. It is ideal for dissolving stubborn substances, like tar and grease spots on concrete, or for removing caked mud from equipment.
  • Page 15 7. When pressure washing surfaces that may come in contact with food, flush surfaces with plenty of drinking water after pressure washing. However, WEN does not recommend eating off of your driveway. TURNING OFF THE PRESSURE WASHER 1.

  • Page 16: Transportation & Storage

    TRANSPORTATION & STORAGE STORING THE PRESSURE WASHER 1. Make sure that the pressure washer is stored on a secure, level surface. 2. Disassemble the spray gun. 3. Neatly wrap and store the high pressure hose to avoid any damage. When storing the pressure washer for extended periods of time: 1.

  • Page 17: Cleaning & Maintenance

    CLEANING & MAINTENANCE WARNING! To avoid injury from accidental startups, be sure that the tool is switched OFF and disconnected from the power supply before performing assembly, inspection or adjustments. HIGH PRESSURE HOSE The high pressure hose can easily be damaged and should be stored carefully. Do not kink the hose. Do not drive vehicles over the hose.

  • Page 18: Troubleshooting Guide

    TROUBLESHOOTING GUIDE WARNING! Stop using the tool immediately if any of the following problems occur. Repairs and replace- ments should only be performed by an authorized technician. For any questions, please contact our customer service at 1-847-429-9263, M-F 8-5 CST or email us at techsupport@wenproducts.com. PROBLEM CAUSE SOLUTION...

  • Page 19: Exploded View & Parts List

    EXPLODED VIEW & PARTS LIST NOTE: Not all parts may be available for purchase. Parts and accessories that wear down over the course of normal use are not covered under the warranty.
  • Page 20 EXPLODED VIEW & PARTS LIST Part No. Description Qty. Part No. Description Qty. PW2000-026 Lance PW2300-018 Wheel Seat PW2300-002 Accesory holder PW2300-019 Rear Housing PW2300-003 Power Switch Knob PW2300-020 Upper Motor Plate Spray Gun Connection Motor & Pump PW2300-004 PW2300-021...

  • Page 21: Warranty Statement

    WARRANTY STATEMENT WEN Products is committed to building tools that are dependable for years. Our warranties are consistent with this commitment and our dedication to quality. LIMITED WARRANTY OF WEN PRODUCTS FOR HOME USE GREAT LAKES TECHNOLOGIES, LLC (“Seller”) warrants to the original purchaser only, that all WEN consumer power tools will be free from defects in material or workmanship during personal use for a period of two (2) years used for professional or commercial use.
  • Page 22 NOTES...
  • Page 23 NOTES...
  • Page 24 THANKS FOR REMEMBERING V. 2024.09.26...
