234350
For replacement parts visit
WENPRODUCTS.COM
Your new tool has been engineered and manufactured to WEN's highest standards for dependability,
ease of operation, and operator safety. When properly cared for, this product will supply you years
of rugged, trouble-free performance. Pay close attention to the rules for safe operation, warnings,
and cautions. If you use your tool properly and for intended purpose, you will enjoy years of safe,
reliable service.
2030 PSI ELECTRIC
PRESSURE WASHER
IMPORTANT:
NEED HELP? CONTACT US!
Have product questions? Need technical support?
Please feel free to contact us at:
800-232-1195
techsupport@wenproducts.com
WENPRODUCTS.COM
Model # PW21
bit.ly/WENvideo
(M-F 8AM-5PM CST)
Advertisement
Related Manuals for Wen PW21
Summary of Contents for Wen PW21
- Page 1 IMPORTANT: Your new tool has been engineered and manufactured to WEN’s highest standards for dependability, ease of operation, and operator safety. When properly cared for, this product will supply you years of rugged, trouble-free performance. Pay close attention to the rules for safe operation, warnings, and cautions.
- Page 2 Get to Know Your Pressure Washer Assembly Operation Maintenance & Storage Troubleshooting Exploded View and Parts List Warranty Statement TECHNICAL DATA Model Number: PW21 120V, 60Hz, 14.5A Motor: 1450 PSI Rated Pressure: 2030 PSI Max Pressure: 1.76 GPM Max Flow Rate: Rated Water Temperature: 32°...
- Page 3 IMPORTANT SAFETY INSTRUCTIONS Safety is a combination of common sense, staying alert and knowing how your tool works. SAVE THESE SAFETY INSTRUCTIONS. WARNING: To avoid mistakes and serious injury, do not plug in your tool until the following steps have been read and understood. 1.
- Page 4 SPECIFIC RULES FOR PRESSURE WASHERS WARNING: Risk of injection or injury to persons - do not direct discharge stream at persons or animals. CAUTION: Misuse of this pressure washer can damage it and shorten its life. Only use the pressure washer for its intended purposes.
- Page 5 ELECTRICAL INFORMATION WARNING: DO NOT MODIFY THE PLUG PROVIDED. If it will not fit the outlet, have the proper outlet installed by a licensed electrician. EXTENSION CORDS WARNING: Do not immerse the pressure washer in water. Do not expose power plug or outlet to rain or water.
- Page 6 GET TO KNOW YOUR PRESSURE WASHER Use the illustrations below to become familiar with the locations and functions of the various components and controls of this electric pressure washer. Trigger Gun Hose Reel Trigger with Safety Lock High Pressure Hose High Pressure Hose Connector High Pressure Hose Coupler Gun Holder...
- Page 7 ASSEMBLY WARNING: Do not attempt to assemble or operate this pressure washer until you have read and understood this entire manual. If you have any problems assembling or operating this unit, please call (800) 232-1195 M-F 8-5 CST for customer service or email us at techsupport@wenproducts.com. PACKING LIST •...
- Page 8 OPERATION USING THE SPRAY GUN 1. To apply safety, flip open the safety lock behind the trigger until it clicks into the slot (Fig. 6). To release safety, return the safety lock until it snaps onto the trigger. 2. Pull back the trigger to begin operating the pressure washer. Release trigger to stop the water flow. Fig.
- Page 9 OPERATION PREPARING AND RUNNING THE PRESSURE WASHER 1. Make sure that the washer is standing on a secure, stable surface to prevent it from tipping during operation. 2. Check that all connections are secure: • The water supply hose is properly fastened to the pressure washer’s water inlet adapter. •...
- Page 10 OPERATION SHUTTING DOWN THE UNIT 1. Turn the power switch to the OFF position (Fig 10). 2. Unplug the power plug from the outlet. 3. Turn off the water source. 4. Pull the trigger to relieve all the built-up pressure in the pressure washer. Fig.
- Page 11 MAINTENANCE & STORAGE STORING THE PRESSURE WASHER FOR EXTENDED PERIODS: 1. Clean the spray nozzle and water inlet adapter before preparing for storage. 2. Only store your pressure washer indoors where the temperature will stay above freezing (32°F/0°C). 3. Always keep the pressure washer upright on a level surface. Cover the machine to protect it from dust. 4.
- Page 12 EXPLODED VIEW AND PARTS LIST...
- Page 13 EXPLODED VIEW AND PARTS LIST Part No. Description Part No. Description PW21-044 Three Way Valve PW20-021 Spray Spigot PW21-045 O-Ring7.5X2/80Hs/Rohs PW21-002 Spray Plug PW21-046 Screw M8*10 PW21-003 Screw ST4.8*20 PW21-047 Left Flange PW20-008 Screw ST3.5*13F PW21-048 Hose Reel Hub PW21-005...
- Page 14 EXPLODED VIEW AND PARTS LIST PUMP:...
- Page 15 EXPLODED VIEW AND PARTS LIST Part No. Description Qty. PW21-101 Induction Motor PW21-102 Peach Shape Ring PW21-103 Pump Assembly PW21-104 Gear Box Assembly PW21-105 Wobble Plate PW21-106 Washer PW21-107 Inner Hexagon Screw PW21-108 Bearing PW21-109 ST Screw PW21-110 Pump Head Assembly...
- Page 16 LIMITED TWO YEAR WARRANTY WEN Products is committed to building tools that are dependable for years. Our warranties are consistent with this commitment and our dedication to quality. LIMITED WARRANTY OF WEN CONSUMER POWER TOOLS PRODUCTS FOR HOME USE GREAT LAKES TECHNOLOGIES, LLC (“Seller”) warrants to the original purchaser only, that all WEN con- sumer power tools will be free from defects in material or workmanship for a period of two (2) years from date of purchase.
