4002910
For replacement parts visit
WENPRODUCTS.COM
Your new tool has been engineered and manufactured to WEN's highest standards for dependability, ease
of operation, and operator safety. When properly cared for, this product will supply you years of rugged,
trouble-free performance. Pay close attention to the rules for safe operation, warnings, and cautions. If
you use your tool properly and for its intended purpose, you will enjoy years of safe, reliable service.
NOTICE: Please refer to wenproducts.com for the most up-to-date instruction manual.
2000 PSI ELECTRIC
PRESSURE
IMPORTANT:
NEED HELP? CONTACT US!
Have product questions? Need technical support?
Please feel free to contact us at:
800-232-1195
techsupport@wenproducts.com
WENPRODUCTS.COM
WASHER
Model # PW19
bit.ly/wenvideo
(M-F 8AM-5PM CST)
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Wen PW19
Summary of Contents for Wen PW19
- Page 1 WENPRODUCTS.COM IMPORTANT: Your new tool has been engineered and manufactured to WEN’s highest standards for dependability, ease of operation, and operator safety. When properly cared for, this product will supply you years of rugged, trouble-free performance. Pay close attention to the rules for safe operation, warnings, and cautions. If you use your tool properly and for its intended purpose, you will enjoy years of safe, reliable service.
-
Page 2: Table Of Contents
Know Your Pressure Washer Assembly & Adjustments Operation Maintenance & Storage Troubleshooting Exploded View and Parts List Warranty Statement TECHNICAL DATA Model Number: PW19 Motor: AC 120V, 60Hz, 13A Rated Pressure: 1300 PSI Maximum Pressure: 2000 PSI Maximum Flow Rate: 1.6 GPM Rated Water Temperature: 32°... -
Page 3: Safety Introduction
SAFETY INTRODUCTION Thanks for purchasing the WEN Pressure Washer. We know you’re excited to put your machine to work, but first, please take a moment to read through the manual. This manual provides information regarding potential safety con- cerns, as well as helpful assembly and operating instructions. Safety is a combination of common sense, staying alert, and knowing how your tool works. -
Page 4: Pressure Washer Safety Rules
PRESSURE WASHER SAFETY RULES WARNING: To avoid mistakes and serious injury, do not plug in your tool until you have read and understood the following safety rules. Learn the tool’s applications, limitations, and possible hazards to maximize your safety and the lifetime of the tool. BEFORE OPERATION 1. - Page 5 PRESSURE WASHER SAFETY RULES OPERATING THE PRESSURE WASHER 1. STAY ALERT. Watch what you are doing and use common sense when operating your tool. Do not use the tool while you are tired or under the influence of drugs, alcohol, or medication. A moment of inattention during operation may result in serious bodily injury.
-
Page 6: Electrical Safety Rules
ELECTRICAL SAFETY RULES DOUBLE-INSULATED TOOLS Your pressure washer electrical system is double insulated, where two systems of insulation are pro- vided instead of grounding. Double insulated tools do not need to be grounded, nor should a means for grounding be added to the product. IMPORTANT: Servicing a double-insulated product requires extreme care and knowledge of the system, and should be done only by a qualified service personnel using identical replacement parts. -
Page 7: Know Your Pressure Washer
KNOW YOUR PRESSURE WASHER Carefully unpack the tool from the packaging. Check all components and compare against the diagram below. If any part is damaged or missing, please contact our customer service at (800) 232-1195, M-F 8-5 CST or email us at techsupport@wenproducts.com. -
Page 8: Assembly & Adjustments
ASSEMBLY & ADJUSTMENTS WARNING: To avoid injury from accidental startups, be sure that the tool is switched off and discon- nected from the power supply before performing assembly, inspection or adjustments. ASSEMBLING THE HIGH PRESSURE HOSE (Fig. 1 & 2) 2. - Page 9 ASSEMBLY & ADJUSTMENTS USING THE SPRAY GUN (Fig. 7) 1. The spray gun is equipped with a safety lock on the bottom of the handle. To engage safety, push out the safety lock. To release safety, push in the safety lock. To prevent risk from accidental startups, always engage the safety lock when not using the pressure washer.
-
Page 10: Operation
OPERATION WARNING: To prevent serious injury, make sure all the warnings and instructions have been read and understood before operating this tool. PREPARING THE PRESSURE WASHER 1. Place the pressure washer on a secure, stable surface to prevent it from tipping during operation. 2. - Page 11 7. When pressure washing surfaces that may come in contact with food, flush surfaces with plenty of drinking water after pressure washing. However, WEN does not recommend eating off of your driveway. SHUTTING DOWN THE UNIT When the pressure washing task has been completed, follow the steps below to shut down the unit.
-
Page 12: Maintenance & Storage
HIGH PRESSURE HOSE The high pressure hose (PW19-016) can be damaged easily and should be carefully stored. Do not kink the hose. Do not drive vehicles or place heavy objects over the hose. Do not expose the hose to sharp objects. Don’t chew on it either. -
Page 13: Troubleshooting
TROUBLESHOOTING WARNING: Stop using the tool immediately if any of the following problems occur or risk serious per- sonal injury. Repairs and replacements should only be performed by authorized personnel. If you have any questions, please contact our customer service at (800) 232-1195, M-F 8-5 CST. PROBLEM CAUSE SOLUTION... -
Page 14: Exploded View And Parts List
EXPLODED VIEW & PARTS LIST... - Page 15 EXPLODED VIEW & PARTS LIST Part No. Description Qty. PW19-001 Screw ST3.5x32 PW19-002 Housing (Left & Right) PW19-003 Motor Cover A (Right) PW19-004 Support Ring PW19-005 Motor Cover B (Right) PW19-006 Motor Case PW19-007 Motor PW19-008 Pump PW19-009 Housing (Back) PW19-010 Screw ST3.5x16...
- Page 16 LIMITED TWO YEAR WARRANTY WEN Products is committed to build tools that are dependable for years. Our warranties are consistent with this commitment and our dedication to quality. LIMITED WARRANTY OF WEN CONSUMER POWER TOOLS PRODUCTS FOR HOME USE GREAT LAKES TECHNOLOGIES, LLC (“Seller”) warrants to the original purchaser only, that all WEN con- sumer power tools will be free from defects in material or workmanship for a period of two (2) years from date of purchase.
