TUB/ SHOWER MIXER BODY
HOT IN
Max Temp : 85°C/185°F
Recommended
Working Pressure:
Min 1bar/15psi
Max 5bar/75psi
Ideal performance obtained with equal hot & cold pressures.
The Georgian Bathroom Collection
Installation & User Guide
• U.3018L
• U.3019X
COLD IN
TUB MIXER BODY
HOT IN
COLD IN
For instalation with
U6387
U6386
U6380
U6381
• U.3021L
• U.3022X
Advertisement
Related Manuals for Perrin & Rowe Georgian Bathroom U.3018L
Summary of Contents for Perrin & Rowe Georgian Bathroom U.3018L
- Page 1 The Georgian Bathroom Collection Installation & User Guide TUB/ SHOWER MIXER BODY • U.3018L • U.3019X HOT IN TUB MIXER BODY COLD IN • U.3021L • U.3022X HOT IN COLD IN Max Temp : 85°C/185°F Recommended For instalation with Working Pressure: Min 1bar/15psi U6387 U6386...
- Page 2 The Georgian Bathroom Collection Installation & User Guide Congratulations on the purchase of your Perrin & Rowe Bathroom Product. Correctly installed and with sensible care, this product will give you many years of trouble free service. IMPORTANT INFORMATION Before you proceed... We recommend you engage the services of a registered plumber to install this product.
-
Page 3: Before Use
U.3018 Extended Pillar Unions U.3019 U.3021 U.3022 Remove backnut and fiber washer from union. From top pass shank through hole in surface ensuring that the base seal remains position. Replace backnut and fibre washer onto shank Union nut and tighten by hand only so that unions can still 'O' Seal rotate. -
Page 4: Spare Parts & Service
ROHL WARRANTY POLICY All products supplied by ROHL carry warranties against manufacturing defects. Perrin & Rowe products carry a Limited Lifetime Warranty. ROHL LLC will provide free of charge, as its options, replacement part(s) or product (or a comparable alternative product) to replace those which have proven defective in materials or workmanship. - Page 5 Floor Legs For Tub/Shower Mixer Floor Legs - U6388 71 Cntrs G 3/4" Temp Range: Min 1°C/34°F Max 85°C/185°F Ø 85 Recommended Working Pressure: Min 1bar/15psi Max 5bar/75psi Ideal performance obtained with equal hot & cold pressures.
- Page 6 The Traditional Kitchen Collection Installation & User Guide Congratulations on the purchase of your Perrin & Rowe Kitchen Product. Correctly installed and with sensible care, this product will give you many years of trouble free service. IMPORTANT INFORMATION Before you proceed... We recommend you engage the services of a registered plumber to install this product.
- Page 7 Union Slide union into outer taking care not to damage sealing rings once union has located on inner tube. Grub Screw Fully secure assembly to Slide outer tube over inner mounting surface. tube assembly with access slot aligned with stop Outer The mixer can now be valve operating screw,...
- Page 8 ROHL WARRANTY POLICY All products supplied by ROHL carry warranties against manufacturing defects. Perrin & Rowe products carry a Limited Lifetime Warranty. ROHL LLC will provide free of charge, as its options, replacement part(s) or product (or a comparable alternative product) to replace those which have proven defective in materials or workmanship.
