• U.4308LS - C-SPOUT W/RINSE
• U.4310LS - U-SPOUT W/RINSE
• U.4312LS - C-SPOUT W/RINSE
• U.4314LS - U-SPOUT W/RINSE
1. 3/8"
HOLE
HOT IN
1/2"
Temp Range:
Min 1°C/34°F
Max 85°C/185°F
Recommended
Working Pressure:
Min 1bar/15psi
Max 5bar/75psi
Ideal performance obtained with equal
hot & cold pressures.
The Contemporary Kitchen Collection
Installation & User Guide
COLD IN
1/2"
• U.4208LS - C-SPOUT ONLY
• U.4210LS - U-SPOUT ONLY
• U.4212LS - C-SPOUT ONLY
• U.4214LS - U-SPOUT ONLY
1. 3/4"
MAX
1. 3/8"
HOLE
1. 1/8"
HOLE
HOT IN
1/2"
47.1.4"
HOSE LENGTH
1. 3/4"
MAX
COLD IN
1/2"
Advertisement
Related Manuals for Perrin & Rowe U.4308LS-C-SPOUT W/RINSE
Summary of Contents for Perrin & Rowe U.4308LS-C-SPOUT W/RINSE
- Page 1 The Contemporary Kitchen Collection Installation & User Guide • U.4308LS - C-SPOUT W/RINSE • U.4208LS - C-SPOUT ONLY • U.4310LS - U-SPOUT W/RINSE • U.4210LS - U-SPOUT ONLY • U.4312LS - C-SPOUT W/RINSE • U.4212LS - C-SPOUT ONLY • U.4314LS - U-SPOUT W/RINSE •...
- Page 2 The Contemporary Kitchen Collection Installation & User Guide Congratulations on the purchase of your Perrin & Rowe Kitchen Product. Correctly installed and with sensible care, this product will give you many years of trouble free service. IMPORTANT INFORMATION These are instructions for rinse and non-rinse version of the model you are installing. Please read carefully to ensure correct installation.
- Page 3 Ensure black rubber washer is in place before securing rinse to flexible hose. Holding the rinse, screw the flexible hose onto the end of rinse and place into rinse unit socket. Make sure that the orientation of the rinse is correct. Attach the flexible hose end to the G3/8"...
- Page 4 ROHL WARRANTY POLICY All products supplied by ROHL carry warranties against manufacturing defects. Perrin & Rowe products carry a Limited Lifetime Warranty. ROHL LLC will provide free of charge, as its options, replacement part(s) or product (or a comparable alternative product) to replace those which have proven defective in materials or workmanship.
