Perrin & Rowe Armstrong U.1833HT Installation & User Manual

LIMITED WARRANTY
Most products or parts carry "Limited Warranties" against manufacturing defects.
For full WARRANTY information please contact House of Rohl or visit: houseofrohl.com
Please contact the local retailer or showroom where you purchased this product for all warranty related claims.
CARE & MAINTENANCE
The finishing touch of every faucet is its exquisite surface. Each finish conveys the experience of luxury through a distinctively soft, warm,
genuine feel in comparison to other products made with synthetic coatings.
No matter which finish you select, please visit:
https://houseofrohl.com/perrin-and-rowe/support/care-and-cleaning/ for complete care guide.
• SPARES •
9.201229*
9.01835*
9.13847
9.18633*
9.26400
9.28620
9.28323
1M SIlicone tube
* Where indicated please specify finish
Spares & Service
Perrin & Rowe products are manufactured in England using quality materials, the latest
technology and built to the highest standards.
We would like to thank you for purchasing this Perrin & Rowe product and invite you to view
the comprehensive range of Perrin & Rowe tapware, shower fittings, bathroom accessories,
3 Parker
820 rue Nobel
soap dispensers and bathroomware.
Irvine
Saint-Jérome
CA 92618
QC, J7Z 7A3
Please contact us to receive our latest product catalogues or view them online at
1-(800)-777-9762
1-866-473-8442
www.houseofrohl.com
www.houseofrohl.com www.houseofrohl.ca
Perrin and Rowe is a registered trademark.
U.1998
U.PRFH1
(Replacment Filter Housing
& Cartridge (U.PRF1))
(Replacement
Nano Filter
9001833U Issue 1
IMPORTANT WARNING!!
PLEASE ENSURE THAT THE RECOMMENDED HEATER TANK UNIT (U.1998) AND FILTER KIT (U.1408) IS USED.
TO AVOID PRESSURISED BOILING WATER AND TO COMPLY WITH US REGULATIONS THIS IS AN OPEN VENTED PRODUCT.
DO NOT PLUG IN THE UNIT UNTIL ALL WATER CONNECTIONS HAVE BEEN MADE AND THE TANK HAS FILLED COMPLETELY THEN
FLUSHED TO REMOVE AIR.
INSTANT HOT WATER TEMPERATURES CAN REACH 210°F. THE FAUCET IS DESIGNED WITH FEATURES TO MINIMISE RISK AND
POTENTIAL INJURY; TWO ACTION OPERATION, SPRING BACK VALVE AND DELAYED DELIVERY; BUT SHOULD BE OPERATED OR
SUPERVISED BY A RESPONSIBLE ADULT.
THIS PRODUCT REQUIRES A PRESSURE REDUCING VALVE (PRV) TO BE FITTED IN-LINE WITH THE COLD INLET AND SET TO A MAXIMUM
OF 43.5PSI (3BAR). FILTER CARTRIDGES MUST BE CHANGED 6 MONTHLY & FILTER HOUSING 3 YEARLY. FAILIURE TO COMPLY WITH
THE ABOVE WILL VOID ALL WARRENTY OFFER BY YOUR DISTRIBUTOR OR THE HOUSE OF ROHL.
PLEASE READ AND FULLY UNDERSTAND THE HEATER TANK INSTRUCTIONS BEFORE USE.
• U.1833HT - Instant Hot & Filtered Dispener
4"
U.PRF1
Cartridge)
1 3/4"
O
NOTE: Diagram shows faucet set up with
u.1998 (heater tank) and u.1408 (filter Kit).
Temp Range:
Min (34°F) 1°C
Max ( 158°F ) 70°C
Recommended
Working Pressure:
Min 15psi ( 1bar)
Max 43.5psi (3 bar)
THIS PRODUCT REQUIRES A PRESSURE REDUCING VALVE (PRV) TO BE FITTED IN-LINE WITH THE COLD INLET AND SET TO A
MAXIMUM OF 43.5PSI (3BAR). FILTER CARTRIDGES MUST BE CHANGED 6 MONTHLY & FILTER HOUSING 3 YEARLY. FAILIURE TO
COMPLY WITH THE ABOVE WILL VOID ALL WARRENTY OFFER BY YOUR DISTRIBUTOR OR THE HOUSE OF ROHL.
The Armstrong Kitchen Collection
•
Installation & User Guide
5 1/2"
5 I.D
O
Silicone Tube
from tank
•
2 5/8"
MIN
Flow Regulator
TO BE FITTED TO
COLD INLET 9/16"-24
ENSURE 43.5psi INLET PRESSURE
