Quick Start Guide
MPTL Cat6a STP Toolless
RJ45 Plug, PoE++ Compliant
Este manual está disponible en español en la página de Eaton:
Tripplite.Eaton.com/support
Ce manuel est disponible en français sur le site Web de Eaton :
Tripplite.Eaton.com/support
Dieses Handbuch ist in deutscher Sprache auf der Eaton-Website verfügbar:
Tripplite.Eaton.com/support
Questo manuale è disponibile in italiano sul sito web di Eaton:
Tripplite.Eaton.com/support
Model:
N238-P01-MPTL-A
Purchased product
may differ from image.
PRODUCT
REGISTRATION
Register your product today for a
chance to win an ISOBAR
protector in our monthly drawing!
Tripplite.Eaton.com/warranty
surge
®
1

Advertisement

Table of Contents
loading
Need help?

Need help?
