Technical Data

Code
Description
Voltage
Frequency
Power
Maximum Pressure
Air Continuous Flow
Tank Capacity
Conductors
Insulation
WARNING
Avoid the risk of electric shock or severe injury. When the power cable gets damaged
it should only be replaced by the manufacturer or at a
The build quality of the electric insulation is altered if spills or liquid gets into the tool while in use.
Do not expose to rain, liquids and/or dampness.
Before gaining access to the terminals all power sources should be disconnected.
WARNING

Power Requirements

WARNING This tool is equipped with a grounded 3-part
power cord or to a grounded electric power system.
CAUTION
A power extension cord is not recommended to use with a compressor. Using an extension causes voltage
drop, power loss in the motor and overheating. Instead of using an extension cord, increase the compressor's action scope
connecting a longer length of hose into the outlet. Connect additional hose lengths as required. Likewise, if needing to use
a pneumatic tool outdoors in humid environment or even when raining, operate the compressor from the inside keeping it
guarded from humidity. Operate the pneumatic tool connected to the compressor through additional lengths of hose
without the risk of electric shock.
• In the event of connecting the compressor into a circuit protected with fuses, use delay action fuses type "D".
WARNING
This tool SHALL BE USED with
220 V ˜ feed. Using a DIFFERENT
VOLTAGE WILL SEVERELY
DAMAGE the product.
COMP-25LT-260
11836
Lubricated air compressor
Rated: 2 Hp Maximum: 3 Hp
6.6 Gallons
16 AWG x 3C with 221 °F Insulation Temperature
Power cord grips used in this product: Type "Y".
Build quality: Basic insulation
Thermal insulation on motor winding: Class F
COMP-50LT-260
220 V
60 Hz
Rated: 2-1/2 Hp Maximum: 3-1/2 Hp
116 PSI
4.4 CFM - 40 PSI
3.4 CFM - 90 PSI
13.2 Gallons
Class I
Authorized Service Center.
11837
