- Page 1 Manual Oil - Free 135 PSI Air Compressor Pressure Applies for: Code Model 13830 COMP-24S COMP-24S Read the user’s manual thoroughly CAUTION before operating this tool.
-
Page 2: Table Of Contents
Manual before using the tool. Parts Start Up Keep this manual for future references. Maintenance The illustrations in this manual are for reference only. They might be different from the real tool. Troubleshooting Notes Authorized Service Centers Warranty Policy COMP-24S ENGLISH... -
Page 3: Technical Data
Technical Data COMP-24S Code 13830 Description Oil-free air compressor Voltage Frequency 60 Hz 127 V Current Motor Power 1-2/3 Hp Measurements Weight 28.6 lb 15.9” x 17.3” Air Connections 1/4” fast coupling Maximum Pressure 135 PSI Air Flow 3.4 CFM - 40 PSI 2.4 CFM - 90 PSI... -
Page 4: General Power Tool Safety Warnings
General Power Tools Safety Warnings WARNING! Read carefully all safety warnings and instructions listed below. Failure to comply with any of these warnings may result in electric shock, fire and / or severe damage. Save all warnings and instructions for future references. -
Page 5: Safety Warnings For Using Air Compressors
Safety Warnings for Using Air Compressors Before using the compressor While operating the compressor CAUTION CAUTION • The equipment, when operated, may be • Do not aim the nozzles, sprinklers or the an ignition source. Keep the equipment away at least 18 ft air jet towards people or animals. -
Page 6: Parts
Parts • The air compressor is useful to supply energy for pneumatic tools, as versatile as power tools. It can be used for drilling, screwing, hammering, riveting, Switch ON / OFF Air vents stapling, chiseling, polishing, blasting, cleaning, painting, etc. Air outlets (quick connectors) Pressure... -
Page 7: Start Up
Start Up Turning ON and operation CAUTION • Before operating the compressor, set it in a flat, level and solid surface, good ventilation and away of flammable object, for example, curtains or drapes. Leave 12” free space around the compressor to allow air to circulate. •... -
Page 8: Maintenance
Maintenance Cleaning and care Air filter • Disconnect the equipment from the power supply and • Check the air filter frequently. Double check it is clean. release all the pressure from the system before trying to • To service the filter, remove the filter cover. install, servicing, relocate or carry out maintenance. -
Page 9: Troubleshooting
Troubleshooting Problem Cause Solution The motor is not • There is no power. • Make sure the power cable is connected. Check the fuse – circuit working. breaker. • Blown fuse. • Replace the blown fuse. • Thermal switch activated. •... -
Page 10: Notes
Notes ENGLISH... -
Page 11: Authorized Service Centers
Authorized Service Centers In the event of any problem contacting a Truper Authorized Service Center, please see our webpage www.truper.com to get an updated list, or call our toll-free numbers 800 690-6990 or 800 0187-8737 to get information about the nearest Service Center. -
Page 12: Warranty Policy
. Transportation costs resulting from compliance of this warranty will be covered by For questions or comments, call 800-690-6990. Made in China. Imported by Truper S.A. de C.V. Parque Industrial 1, Jilotepec, Edo. de Méx. C.P. 54240 Stamp of the business.
