Summary of Contents for Truper COMP-25LT-260
- Page 1 Manual Lubricated air 116 PSI compressor Pressure Applies for: Codes Models 11836 COMP-25LT-260 11837 COMP-50LT-260 COMP-50LT-260 COMP-25LT-260 Read this manual thoroughly CAUTION before using the tool.
-
Page 2: Table Of Contents
Parts Preparation Keep this manual for future references. Start Up The illustrations in this manual are for reference only. They might be different from the real tool. Maintenance Troubleshooting Authorized Service Centers Warranty Policy COMP-50LT-260 COMP-25LT-260 ENGLISH... -
Page 3: Technical Data
Technical Data COMP-25LT-260 COMP-50LT-260 Code 11836 11837 Description Lubricated air compressor Voltage 220 V Frequency 60 Hz Power Rated: 2 Hp Maximum: 3 Hp Rated: 2-1/2 Hp Maximum: 3-1/2 Hp Maximum Pressure 116 PSI Air Continuous Flow 4.4 CFM - 40 PSI 3.4 CFM - 90 PSI... -
Page 4: General Power Tool Safety Warnings
General power tool safety warnings WARNING! Read carefully all safety warnings and instruction listed below. Failure to comply with any of these warnings may result in electric shock, fire and / or severe damage. Save all warnings and instructions for future references. -
Page 5: Safety Warnings For Pneumatic Compressors
Safety Warnings for Pneumatic Compressors Before using the compressor When using the compressor CAUTION CAUTION • The pressurestat produces sparks when • Do not aim nozzles, sprayers or the air working. If sparks make contact with gasoline vapors or jet towards people or animals. WARNING other solvents they can ignite causing fire or explosion. -
Page 6: Parts
Parts Switch Pressurestat Transportation Handle Regulated Pressure Gauge Outlet Regulated Air Outlet Valve Oil Drain Oil Level Spy Window Check Valve Pressure Release Valve Pressure Air Outlet Valve Gauge Outlet (Quick Connection) Tank Drain Valve Transportation Out Pressure Filter Handle Motor Regulator Thermal... -
Page 7: Preparation
Preparation • The air compressor is used to supply energy to pneumatic tools as versatile as power tools are. The tools can be used to drill, screw, hammer, rivet, staple, chisel, polish, blowtorching, cleaning, painting etc. • The compressor functions are completely automatic and controlled with the pressurestat. It stops the motor when the tank’s pressure has reached the maximum level. -
Page 8: Start Up
Start Up Switch ON and OFF Operation • Before operating the compressor set it onto a flat, • Connect one end of the air hose into any of the leveled and solid surface, well ventilated and away from compressors outlets (H). flammable objects like curtains, etc. -
Page 9: Maintenance
Maintenance Oil Change • After the first 5 hours’ operation change oil. Remove the drain cap (A). Set the cap back and fill-up with oil as indicated in page 7 (Oil). The later oil changes shall be carried out every 150 hours’ work. Cleaning and Care •... -
Page 10: Troubleshooting
Troubleshooting Problem Cause Solution The motor is not • No power. • Be sure the cable is connected. Check the fuse-circuit switch. working. • Fuse is blown . • Replace the blown fuse. • Thermal switch is • Press the thermal switch button to restart. activated. -
Page 11: Authorized Service Centers
Authorized Service Centers In the event of any problem contacting a Truper Authorized Service Center, please see our webpage www.truper.com to get an updated list, or call our toll-free numbers 800 690-6990 or 800 018-7873 to get information about the nearest Service Center. -
Page 12: Warranty Policy
It includes the costs of transportation of the product that derive from its fulfillment of its service network. Phone number 800-018-7873. Made in China. Imported by Truper, S.A. de C.V. Parque Industrial 1, Parque Industrial Jilotepec, Jilotepec, Edo. de Méx. C.P. 54257, Phone number 761 782 9100.
