Technical Support and E-Warranty Certificate
www.vevor.com/support
Inverted machine
MODEL:QD001,QD002,QD003
We continue to be committed to provide you tools with competitive price.
"Save Half", "Half Price" or any other similar expressions used by us only
represents an estimate of savings you might benefit from buying certain tools
with us compared to the major top brands and does not necessarily mean to
cover all categories of tools offered by us. You are kindly reminded to verify
carefully when you are placing an order with us if you are actually saving half
in comparison with the top major brands.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for VEVOR QD001
Summary of Contents for VEVOR QD001
- Page 1 Technical Support and E-Warranty Certificate www.vevor.com/support Inverted machine MODEL:QD001,QD002,QD003 We continue to be committed to provide you tools with competitive price. "Save Half", "Half Price" or any other similar expressions used by us only represents an estimate of savings you might benefit from buying certain tools with us compared to the major top brands and does not necessarily mean to cover all categories of tools offered by us.
- Page 2 This is the original instruction, please read all manual instructions carefully before operating. VEVOR reserves a clear interpretation of our user manual. The appearance of the product shall be subject to the product you received. Please forgive us that we won't inform you again if...
- Page 3 Preface First, let us express our heartfelt thanks to our customers who purchased our equipment.This manual is for customer service to make better Written with this equipment.Hope the company's products and services to bring you the canal courtesy. Pay attention This product must be used in strict accordance with the use method of this manual, misuse of any other methods caused by misuse The Company does not give any...
- Page 4 Manufacturing process and raw materials: The Company guarantees that the Equipment(except parts) is in regular use and repair condition, free of manufacturing process and raw materials faults for one year from the date of shipment. None of our inspections is perfect 1.
- Page 5 Product pipe fitting parameters product name Inverted machine Model QD001 Max load 300ilb Product size L x W x H 1200X690X1640mm 19.6 kg Product weight Blue Black Double Pinyin/Orange Black Double Pinyin/Black Red Colour Double Pinyin Product breakdown diagram...
-
Page 6: Parts List
PARTS LIST DESCRIPTION QUANTITY NUMBER Support Support Connecting pipe Handle Back connection elbow pad Leg adjustment(long) Leg cushion tube Footing Leg adjustment(short) Connect Neck cushion Backing Foam Circular plug Foam Spring latch M20 Spring latch M16 Ring locking pin Ring locking pin BOLT M10*30 WASHERS M1O BOLT M8*50... -
Page 7: Installation Steps
Installation steps 1.Assemble component 1 and component 2 using M8 screws (24), M8 washers (26), and M8 locking nuts (27). 2. Use the circular pin (20) to assemble components 1 and 2. 3. Use M8 * 20 screws (25) and a φ 8 washer (28) to connect component 11 to component 2. - Page 8 4. Fix the 5th and 11th components with M8 * 20 screws (25), 2 * 8 washers (26), and 1 M8 locking nut (27). 5. Insert component 7 into component 5, adjust the appropriate length, and then fix it with a circular pin (19) and a spring pull pin (18). 6.
- Page 9 10. Assemble component 9 and component 7 using M8 * 50 screws (23), 2 M8 washers (26), and 1 M8 (27) locking nut. 11. Assemble component 4 with M8 * 40 screws (23), M8 washers (26), and M8 locking nuts (27) onto component 2. 12.
- Page 10 14. Assemble component 5 and component 12 using M8 * 20 screws (25) and φ 8 washers (26). 15. Assemble parts 13, 5, and 29 using M8 * 20 screws (25) and a φ 8 washer (28).
- Page 11 16. Assemble component 30 with components 1 and 3.
- Page 12 Imported to USA: Sanven Technology Ltd. Suite 250, 9166 Anaheim Place, Rancho Cucamonga, CA 91730 YH CONSULTING LIMITED. C/O YH Consulting Limited Office 147, Centurion House, London Road, Staines-upon-Thames, Surrey, TW18 4AX E-CrossStu GmbH Mainzer Landstr.69, 60329 Frankfurt am Main. Technical Support and E-Warranty Certificate www.vevor.com/support...
