Modulating, variable-speed ecm gas furnace 97% afue

Advertisement

Heating Input: 60,000-120,000 BTU/h
Standard Features
• Integrated communicating ComfortBridge
• Commissioning and diagnostics via on board Bluetooth
with the CoolCloud phone and tablet application
• Heavy-duty aluminized-steel tubular heat exchanger
• Stainless-steel secondary heat exchanger
• Self-calibrating modulating gas valve
auto-configure for each installation
• Durable Silicon Nitride igniter
• Quiet variable-speed induced draft blower
• Self-diagnostic control board with constant memory
fault code history output to a dual 7-segment display
• Color-coded low-voltage terminals with provisions
for electronic air cleaner
• Efficient and quiet variable-speed airflow system gently
ramps up or down according to heating or cooling demand
• Multiple continuous fan speed options offer quiet air circulation
• Auto-Comfort and enhanced dehumidification modes available
• All models comply with California 40 ng/J
Low NOx emissions standard
• Can not be installed in California's South Coast
Air Quality Management District (SCAQMD)
and San Joaquin Valley Air Pollution Control
District (SJVAPCD).
• AHRI Certified; ETL Listed
ENERGY STAR® and the ENERGY STAR mark are registered trademarks
owned by the U.S. Environmental Protection Agency. ENERGY STAR
products are third-party certified by an EPA-recognized Certification
Body. Products that earn the ENERGY STAR prevent greenhouse
gas emissions by meeting strict energy efficiency guidelines set by
the U.S. Environmental Protection Agency.
SS-GRVM97_GDVM97-R32
GRVM97 / GDVM97
Cabinet Features
Technology
• Designed for multi-position installation -
GRVM97: upflow, horizontal left or right
GDVM97: downflow, horizontal left or right
• Certified for direct vent (2-pipe)
or non-direct vent (1-pipe)
• Easy-to-install top venting with optional side venting
• Convenient left or right connection
for gas and electrical service
• Cabinet air leakage (Q
• Heavy-gauge steel cabinet with durable finish
• Fully insulated heat exchanger and blower section
• Airtight solid bottom or side return with
easy-cut tabs for effortless removal
in bottom air-inlet applications
* Complete warranty details available from your local dealer or at www.goodmanmfg.com. To receive
the Lifetime Heat Exchanger Limited Warranty (good for as long as you own your home), 10-Year
Unit Replacement Limited Warranty and 10-Year Parts Limited Warranty, online registration must be
completed within 60 days of installation. nline registration and some of the additional requirements are
not required in Florida, California, or Québec. The duration of warranty coverage in Texas and Florida
differs in some cases. Other limitations and exclusions apply; refer to complete warranty details for a full
list of limitations and exclusions.
www.goodmanmfg.com
Modulating, Variable-Speed
ECM Gas Furnace
Contents
Nomenclature ........................................ 2
Product Specifications ........................... 3
Dimensions ............................................ 4
Airflow Specifications ............................ 6
Wiring Diagram ...................................... 9
Accessories .......................................... 10
) ≤ 2%
Leak
97% AFUE
12-24

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GRVM97 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Goodman GRVM97

  • Page 1: Table Of Contents

    • Designed for multi-position installation — ™ • Commissioning and diagnostics via on board Bluetooth GRVM97: upflow, horizontal left or right with the CoolCloud phone and tablet application GDVM97: downflow, horizontal left or right • Heavy-duty aluminized-steel tubular heat exchanger •...
  • Page 2: Nomenclature

    Nomenclature 0,6,0 7, 8, 9 Brand Minor Revision G - Goodman A - Initial Release B - 1st Revision Configuration R Upflow/Horizontal Major Revision D Downflow/Horizontal A - Initial Release B - 1st Revision Motor N - Natural Gas ≥ 40 NG/J NOx 9 Nine Speed ECM N - Low NOx (90%+) ≤...
  • Page 3: Product Specifications

    Product Specifications GRVM97 GRVM97 GRVM97 GRVM97 GRVM97 GDVM97 GDVM97 GDVM97 GDVM97 0603BN 0803BN 0804CN 1005CN 1205DN 0603BN 0803BN 0804CN 1005CN Heating Data High Fire Input¹ 60,000 80,000 80,000 100,000 120,000 60,000 80,000 80,000 100,000 High Fire Output¹ 58,200 77,600 77,600...
  • Page 4: Dimensions

    GRVM97 Dimensions Discharge Discharge 28¾ 6½ ¾ 2¾ 6½ ¾ Air Intake 2⅝ 1⅞ 2" Pipe 19½ Center Dimple Vent/ Flue Pipe Left-Side Alternate For Alternate 2" PVC Drain Trap Vent/ Flue Air Intake Pipe ¾ Exterior Holes 3" Location...
  • Page 5 GDVM97 Dimensions 1½ 18¼ Vent/Flue Pipe 6½ 2" PVC 1½ Return 3⅝ Air Intake Pipe 2” PVC Top View 6½ 2⅝ 2½ 18¼ 1⅝ 1⅞ 1⅜ 1⅞ Alternate Vent/ Low-Voltage 1½ Electrical Outlet Low-Voltage Electrical Outlet Alternate Gas Alternate Gas Supply High-Voltage Electrical Outlet 25⅛...
  • Page 6: Airflow Specifications

    GRVM97 Airflow Data MODEL/TEMP RISE RANGE GRVM970603BNA* GRVM970803BNA* GRVM970804CNA* GRVM971005CNA* GRVM971205DNA* (MID RISE) 35-65 (50) 30-60 (45) 25-55 (40) 35-65 (50) 35-65 (50) RISE RISE RISE RISE RISE Recommended cfm for 100% firing rate 1080 1450 1750 1800 2150 & expected temperature rise...
  • Page 7 GDVM97 Airflow Data MODEL/TEMP RISE RANGE GDVM970603BNA* GDVM970803BNA* GDVM970804CNA* GDVM971005CNA* (MID RISE) 35-65 (50) 35-65 (50) 35-65 (50) 35-65 (50) RISE RISE RISE RISE Recommended cfm for 100% firing rate 1100 1400 1450 1800 & expected temperature rise Lowest recommended cfm for 100% 1100 1100 1380...
  • Page 8 Temperature Rise Range Chart www.goodmanmfg.com SS-GRVM97_GDVM97-R32...
  • Page 9: Wiring Diagram

    Wiring Diagram 115 VAC/ 1 ⌀ /60 HZ POWER SUPPLY WITH ID BLOWER TWO-STAGE PRESSURE OVERCURRENT SWITCH ASSEMBLY PROTECTION DEVICE HIGH FIRE PRESSURE SWITCH LOW FIRE SURFACE PRESSURE IGNITER SWITCH WARNING: 2 CIRCUIT DISCONNECT CONNECTOR DISCONNECT POWER BEFORE SERVICING. WIRING TO UNIT MUST BE MODULATING PROPERLY...
  • Page 10: Accessories

    Accessories GRVM97 GRVM97 GRVM97 GRVM97 GRVM97 Model Description 0603BN 0803BN 0804CN 1005CN 1205DN 72950 Concentric Vent Kit (2") ― √ √ √ √ 72951 Concentric Vent Kit (3") √ √ √ √ √ RF000142 Drain Kit Horizontal Left Vertical Flue √...
  • Page 11 Notes SS-GRVM97_GDVM97-R32 www.goodmanmfg.com...
  • Page 12 Notes Our continuing commitment to quality products may mean a change in specifications without notice. ©2024 • Houston, Texas • Printed in the USA. www.goodmanmfg.com SS-GRVM97_GDVM97-R32...
